Description
The Bently Nevada 3300/05 Rack System serves as the foundational mechanical housing and backplane for the 3300 series monitoring system. Engineered for industrial reliability, this rack provides the necessary structural support, electrical backplane connectivity, and slot capacity required to integrate various vibration, thrust, and I/O monitoring modules. It is essential for protecting critical rotating machinery, including turbines, compressors, and pumps, by ensuring consistent module alignment and stable electrical communication across the monitoring architecture.
Features
- Robust mechanical housing designed for industrial protection environments.
- Integrated backplane for reliable power distribution and signal communication between installed modules.
- Supports a wide range of 3300 series monitoring and I/O cards.
- Designed for standard panel mounting configurations.
- Ensures mechanical stability and electrical continuity for high-availability monitoring.
Ordering Information
| Model Code |
Description |
| 3300/05 |
Base Rack System |
| 22 |
Rack Size Configuration |
| 00 |
Standard Mounting Option |
| 00 |
Standard Agency Approval |
Technical Specifications
| Model |
3300/05-22-00-00 |
| Brand |
Bently Nevada |
| Series |
3300 |
| Product Type |
Rack System |
| Operating Temperature |
0 to 60 deg C |
| Power Supply Compatibility |
Standard 3300 series power supplies |
Installation Guidelines
- Ensure the rack is mounted in a clean, dry, and vibration-dampened environment.
- Verify that the mounting surface is rigid and capable of supporting the weight of the fully populated rack.
- Use proper grounding techniques to connect the rack to the system common to minimize EMI/RFI interference.
- Power down the system before inserting or removing any monitoring modules to prevent electrical damage.
- Ensure adequate airflow around the rack to maintain operating temperatures within the specified 0 to 60 deg C range.
- Follow standard ESD (Electrostatic Discharge) handling procedures when installing or servicing modules within the rack.
FAQ
What is the primary function of the 3300/05 rack?
The 3300/05 rack acts as the central chassis for the Bently Nevada 3300 monitoring system, providing the physical slots, power distribution, and data backplane required for the operation of vibration and thrust monitoring modules.
Is this rack compatible with all 3300 series modules?
Yes, the 3300/05 is designed to house standard 3300 series monitoring and I/O modules, provided the specific rack size and power configuration requirements are met.
