Bently Nevada 16710-08 Armored Interconnect Cable
Configured for vibration signal transmission in Bently Nevada 3500 and 3300 series machinery protection systems, the Bently Nevada 16710-08 (base model 16710) provides direct physical and electrical execution between accelerometers and monitoring racks. It carries conditioned dynamic signals from transducers to input modules without intermediate conversion.
Hardware Specifications
|
Parameter
|
Specification
|
|
Brand
|
Bently Nevada
|
|
Model
|
16710-08
|
|
Origin
|
United States
|
|
Weight
|
0.824 kg
|
|
Dimensions
|
2.4 m length
|
|
Operating Temp
|
-40 degC to 85 degC
|
|
Power Consumption
|
Passive component; no power draw
|
|
Conductor Count
|
3
|
|
Wire Gauge
|
22 AWG (0.5 mm²)
|
|
Shielding
|
Foil and braid
|
|
Insulation Material
|
PVC
|
|
Operating Voltage
|
600 V
|
|
Current Rating
|
10 A
|
Eddy-Current Probe Scaling and Gap Voltage Validation
The 16710-08 supports eddy-current probe scaling by preserving linear signal amplitude over the full transducer operating range. When interfaced with proximity probes, it maintains stable gap voltage validation targets near -10 VDC, ensuring rotor dynamics measurements remain consistent under varying shaft displacement. Full shielding suppresses cross-talk between adjacent signal pairs in high-density machinery monitoring cabinets.
Frequently Asked Questions
Q: Can the 16710-08 be hot-swapped while the monitoring system is powered?
A: No. Disconnect power from the associated monitoring module before connecting or disconnecting the cable to prevent transient surges.
Q: Is the armor electrically bonded to the shield?
A: Yes. The stainless-steel armor is bonded to the overall shield to ensure continuous EMI protection and ground reference integrity.
Q: What is the maximum continuous current rating for signal conductors?
A: Conductors are rated for up to 10 A, though typical vibration signal currents are well below this limit.
Field Installation Guidelines
Route the cable separately from high-voltage power conductors to minimize inductive coupling. Maintain minimum bend radius of 10× cable diameter. Terminate the shield at the monitoring rack end using the designated grounding point; do not ground at the transducer end to avoid ground loops. Verify connector seating by applying slight axial force after locking the 3-socket plug. Inspect armor continuity during annual preventive maintenance.
