The Allen-Bradley 1734-OB4E is a compact, four-channel digital DC output module belonging to the POINT I/O family. Designed for high-density distributed I/O applications, this module provides reliable switching for 24V DC loads. It features electronic protection to safeguard against short circuits and overloads, ensuring operational continuity in industrial control environments.
Features
- Four independent sourcing output channels.
- Nominal operating voltage of 24V DC.
- Integrated electronic protection for output circuitry.
- Compact, modular design suitable for space-constrained control cabinets.
- DIN-rail mountable for quick installation and removal within the POINT I/O system.
Applications
This module is commonly utilized in automated manufacturing, process control, and machine-level monitoring systems. It is ideal for interfacing with actuators, relays, and indicators that require a 24V DC sourcing signal from a PLC or distributed control node.
Technical Specifications
| Model |
1734-OB4E |
| Module Type |
Digital DC Output |
| Number of Channels |
4 |
| Output Type |
Current Sourcing |
| Voltage Rating |
24V DC |
| Protection |
Electronic |
| Mounting |
DIN Rail |
| Enclosure Type |
Open Style |
Installation Guidelines
- Ensure the system power is disconnected before installing or removing the module from the POINT I/O base.
- Mount the module on a standard 35mm DIN rail.
- Verify that the module is fully seated and locked into the communication interface or adjacent terminal base.
- Maintain proper clearance around the module to allow for adequate airflow and heat dissipation.
- Use shielded cabling for I/O signals to minimize electromagnetic interference (EMI) in high-noise industrial environments.
- Adhere to local electrical codes for grounding and wiring practices.
FAQ
Is the 1734-OB4E protected against short circuits?
Yes, the module includes electronic protection features to prevent damage from short circuits and overloads on the output channels.
What is the mounting method for this module?
The 1734-OB4E is designed for DIN-rail mounting, allowing it to integrate seamlessly into standard POINT I/O rack configurations.
