The Allen-Bradley 8500-1746I is a specialized adapter interface module designed for the 8500 series. This module serves as a high-speed communication bridge, enabling Bulletin 1746 SLC I/O modules to be deployed in remote locations, physically separated from the main controller. Acting as a dedicated microcomputer, the module manages the exchange of control data between the SLC-500 PLC and distributed field devices, providing the flexibility required for complex industrial system architectures.
Features
- Facilitates remote I/O communication for SLC-500 systems.
- Utilizes the I/O RING protocol for high-speed, reliable data transmission.
- Enables local processing of I/O signals to reduce latency in distributed applications.
- Designed for integration with Bulletin 1746 I/O hardware.
Applications
This module is ideal for large-scale industrial environments where sensors, actuators, and other field devices are located at a significant distance from the main electrical cabinet. It is commonly used in distributed control systems where centralized processing is required but physical I/O distribution is necessary for cabling efficiency.
Technical Specifications
| Brand |
Allen-Bradley |
| Product Line |
8500 Motors / SLC 500 |
| Module Type |
Adapter Interface |
| Communication Protocol |
I/O RING |
| Operating Voltage |
5V DC (via backplane) |
| Current Consumption |
470 mA |
| Thermal Dissipation |
2.49 Watts (8.4962 BTU/hr) |
| Operating Temperature |
Max 60 degC (140 degF) |
| Environmental Rating |
IP20 |
Installation Guidelines
- Ensure the system power is disconnected before installing or removing the module from the backplane.
- Verify that the module is securely seated in the chassis slot to ensure proper backplane connection.
- Follow standard ESD (Electrostatic Discharge) handling procedures when touching internal components.
- Ensure adequate ventilation in the cabinet to maintain operating temperatures below 60 degC.
- Route communication cables away from high-voltage lines and sources of electromagnetic interference (EMI) to maintain signal integrity.
FAQ
What is the primary function of the 8500-1746I?
The 8500-1746I acts as a communication adapter that allows SLC-500 I/O modules to operate in remote locations, effectively extending the reach of the PLC system using the I/O RING protocol.
Can this module be used with standard SLC-500 processors?
Yes, it is designed to bridge communication between the SLC-500 PLC and distributed 1746 I/O modules.
