Yokogawa AEA4D-01 Terminal Board
The Yokogawa AEA4D-01, also cataloged as the AEA4D Terminal Board, operates as a dedicated hardware component for analog signal interfacing within CENTUM and ProSafe-RS systems. It provides physical termination and routing for field instruments to Yokogawa FIO modules, supporting both single and dual-redundant I/O configurations.
Hardware Specifications
Parameter
Specification
ModelBrand
Yokogawa AEA4D-01
Origin
Japan
Weight
1.5 kg
Dimensions
Dual-row vertical terminal block, standard panel mount
OperatingTemp
-20 degC to +70 degC
AmbientHumidity
5% to 95% RH (non-condensing)
TerminalScrewType
M4 Screw Terminals
ChannelCapacity
16 channels (8 points x 2 blocks)
SignalConfiguration
Single or dual-redundant analog
InsulationResistance
≥ 100 MOhm at 500 VDC
WithstandingVoltage
500 VAC for 1 minute
ConnectionCable
Yokogawa KS1 signal cable
MountingMethod
19-inch rack or panel with 4 x M5 screws
Process Control DCS Features
The AEA4D-01 supports 4-20 mA HART loop protocol and maintains channel-to-channel isolation for noise suppression. Cold junction compensation (CJc) is applied internally to reduce temperature-induced drift. Dual-redundant port architecture enables uninterrupted signal routing during FIO module replacement or failure, maintaining DCS operational integrity.
Frequently Asked Questions
Q: VnA: Can the AEA4D-01 support hot-swap of FIO modules? A: Yes, field wiring remains undisturbed, and module replacement can be conducted without powering down the I/O rack.
Q: VnA: What is the maximum cable length for connecting field instruments? A: Standard Yokogawa KS1 cable specifications should be followed; length is determined by analog signal attenuation and noise margin.
Q: VnA: Is surge protection integrated? A: No, the standard suffix (-0/-1) models are supplied without surge absorbers; external protection must be implemented if required.
Field Installation Guidelines
Mount the terminal board on a standard 19-inch rack or panel using 4 x M5 screws.
Connect field instrument cables using M4 screw terminals ensuring torque per industrial standards to maintain gas-tight contact.
Maintain separation of analog signal cables from power lines to prevent electromagnetic interference.
Ground shielding at one end only to avoid ground loops.
Verify dual-redundant port connections when configuring for hot-standby operation.
Avoid mechanical stress on cables during installation to prevent signal degradation.
