ABB TK853V020 Modem Cable

Configured for serial modem communication between TC562 and TP830, the ABB 3BSC950201R1 (TK853V020 Modem Cable) provides a prefabricated 2 m physical connection for the TP830 serial interface.

Hardware Specifications

Parameter	Specification
Model	3BSC950201R1
ABB Type Designation	TK853V020
Brand	ABB
Product Type	Prefabricated Cable
Cable Function	Modem cable for serial interfaces on TP830
Connection	TC562 modem to TP830
Cable Length	2 m
Product Length	2000 mm
Product Width	7 mm
Product Height	7 mm
Weight	0.14 kg
Operating Temp	Not specified in supplied data
Power Consumption	Not applicable
HS Code	854442
Customs Tariff Number	85444210
WEEE Category	Product Not in WEEE Scope

ABB Industrial Serial Interface Characteristics

The TK853V020 provides a fixed physical connection between the TC562 modem and the TP830 serial interface. Therefore, installation should preserve the cable routing and connector orientation specified for the associated ABB hardware.

Because the supplied documentation identifies this item as a prefabricated cable, the cable itself does not provide programmable communication functions, protocol conversion, or independent power processing. Instead, it carries the serial interface connection between the designated devices.

Frequently Asked Questions

Q: What equipment does the TK853V020 connect?
A: The cable connects the TC562 modem to the serial interface on the TP830.

Q: What is the specified cable length?
A: The cable length is 2 m, with a listed product length of 2000 mm.

Q: Does the cable have a specified power consumption?
A: No. The supplied data identifies it as a prefabricated modem cable, so no independent power consumption is specified.

Field Installation Guidelines

• Verify the cable identification before installation and confirm the required TC562 and TP830 connection points.
• Route the cable without excessive mechanical tension, sharp bends, or compression.
• Keep the serial cable separated from high-current power conductors where practical to reduce electrical interference.
• Ensure connectors are fully seated before commissioning the serial communication path.
• Do not modify the prefabricated cable or alter its connector termination.
• Inspect the cable jacket and connectors for mechanical damage before installation.
• Confirm serial communication after connection using the applicable TP830 and TC562 commissioning procedure.
