ABB TK851V010 Connection Cable

Configured for RCU link and BC810 interconnection functions, the ABB TK851V010 (TK851V010 Connection Cable) provides a prefabricated 1 m physical connection between compatible ABB system components.

Hardware Specifications

Parameter	Specification
Model	TK851V010
Product ID	3BSC950262R1
Brand	ABB
Product Type	Prefabricated Cable
Function	RCU Link Cable; BC810 Interconnection Cable
Cable Length	1 m
Dimensions	1000 mm x 10 mm x 10 mm
Weight	0.45 kg
Product Net Depth / Length	1000 mm
Product Net Height	10 mm
Product Net Width	10 mm
HS Code	854442
Customs Tariff Number	85444210
WEEE Category	Product Not in WEEE Scope
SCIP	No SVHC present Switzerland

ABB Industrial Interconnection Characteristics

The TK851V010 provides a dedicated cable path for RCU link and BC810 interconnection functions. Therefore, installation should preserve the specified cable routing and connector orientation for the connected ABB hardware.

Because the supplied documentation does not state conductor assignment, shielding construction, connector pinout, or electrical ratings, these parameters should be verified against the applicable ABB system documentation before installation.

For industrial control cabinets, route the cable separately from high-energy power conductors where practical. Also, avoid excessive bending, tensile loading, crushing, or mechanical stress at the connector ends.

Frequently Asked Questions (FAQ)

Q: What equipment functions does the TK851V010 support?
A: ABB specifies the cable for RCU Link Cable and BC810 Interconnection Cable applications.

Q: What is the physical cable length?
A: The specified cable length is 1 m, with a product net length of 1000 mm.

Q: Is power consumption applicable to the TK851V010?
A: No. The product is a passive prefabricated connection cable, so power consumption is not specified as an operating parameter.

Field Installation Guidelines

1. Confirm that the installed cable is ABB TK851V010, Product ID 3BSC950262R1, before connection.
2. Verify the mating interfaces and connector configuration against the applicable ABB hardware documentation.
3. Install the cable without excessive bending, pulling, twisting, or compression.
4. Keep the cable routing clear of mechanical interference from cabinet doors, mounting rails, and adjacent hardware.
5. Separate the cable from high-current or high-voltage wiring where the cabinet layout permits.
6. Do not modify the cable, connector, shielding, or conductor arrangement unless ABB documentation specifically permits the modification.
7. Inspect connector seating before system commissioning and verify that no connector is mechanically stressed by cable routing.
