ABB CI830 3BSE013252R1 PROFIBUS DP Communication Interface

Configured for PROFIBUS DP-V1 communication in ABB S800 I/O systems, the ABB CI830 3BSE013252R1 (CI830 communication module) provides the physical and electrical interface between the control system and PROFIBUS DP network. It operates at communication speeds up to 12000 kbit/s and uses a 24 V DC supply.

Hardware Specifications

Parameter	Specification
Model	CI830 3BSE013252R1
Spare Model	3BSE013252R1
Brand	ABB
Product Type	PROFIBUS DP Communication Interface Module
Origin	Sweden
Product Function	PROFIBUS DP-V1 Communication Interface
Protocol Type	PROFIBUS-DP
Communication Speed	Up to 12000 kbit/s
Supply Voltage	24 V DC +/-20 %
Current Consumption	<= 50 mA
Power Consumption	Approximately 1.2 W
Isolation	500 V DC field-to-bus
Operating Temp	-20 deg C to +55 deg C
Weight	0.45 kg
Estimated Shipping Dimensions	16.8 x 8.3 x 12 cm
Tariff Code	8537101190

ABB PROFIBUS DP Communication Characteristics

The CI830 provides PROFIBUS DP-V1 communication for distributed I/O data exchange. The interface supports communication speeds up to 12000 kbit/s, allowing the module to exchange process data with PROFIBUS DP field devices.

The module operates from a 24 V DC supply with a specified tolerance of +/-20 %. Its stated current consumption is no more than 50 mA, corresponding to approximately 1.2 W.

Furthermore, the 500 V DC field-to-bus isolation separates the field-side electrical domain from the communication bus. This isolation should be maintained during system wiring and commissioning.

For ABB control architectures, PROFIBUS DP communication complements the backplane and I/O communication structure by providing an external fieldbus interface. Therefore, installation should follow the applicable ABB hardware configuration and PROFIBUS network rules.

Frequently Asked Questions (FAQ)

Q: What PROFIBUS communication speed does the CI830 support?
A: The supplied specification lists a maximum communication speed of 12000 kbit/s for the PROFIBUS-DP interface.

Q: What supply voltage does the CI830 require?
A: The module requires 24 V DC with a specified tolerance of +/-20 %. The stated current consumption is <= 50 mA.

Q: What operating temperature range is specified for the CI830?
A: The supplied specification states an operating range from -20 deg C to +55 deg C.

Field Installation Guidelines

• Install the CI830 on the designated ABB mounting and base-unit arrangement specified for the system.
• Verify the 24 V DC supply polarity and voltage range before energizing the module.
• Route PROFIBUS communication wiring separately from high-current and high-noise power conductors where practical.
• Maintain the specified PROFIBUS cable shielding and termination arrangement throughout the network.
• Connect cable shields according to the applicable ABB installation instructions and site grounding design.
• Inspect connectors for correct seating before commissioning the communication interface.
• Confirm PROFIBUS node addressing and network configuration before starting process communication.
• Check the module status indicators after power-up and investigate communication faults before placing the network into service.
