ABB TP854 3BSE025349R1 Module Termination Unit

Configured for DP-V1 communication interface baseplate installation in ABB AC 800M systems, the ABB TP854 3BSE025349R1 (TP854 Module Termination Unit) provides direct physical mounting and electrical connection support for CI854 communication interfaces.

Hardware Specifications

Parameter	Specification
Model	TP854 3BSE025349R1
Brand	ABB
Product Type	Module Termination Unit
Function	Baseplate for CI854, CI854A and CI854B PROFIBUS DP-V1 Interface
Origin	Sweden / Germany
Weight	0.234 kg
Dimensions	216 mm x 72 mm x 49.5 mm
Estimated Shipping Size	18.7 x 6.7 x 4.8 cm
Operating Temp	Not specified by manufacturer
Power Consumption	Passive termination unit, no external power consumption
Compatible Modules	CI854K01, CI854AK01, CI854BK01
Mounting Type	AC 800M controller system module termination mounting
Product Status	New
Customs Tariff Number	85369095

ABB Industrial Backplane and Interface Integration

The TP854 is a dedicated termination and mounting base unit designed for ABB CI854 communication interfaces. It provides the mechanical support structure and electrical interface connection between the CI854 module and the AC 800M control platform.

Furthermore, the unit supports ABB industrial backplane bus integration, allowing the installed communication interface to exchange control data through the controller hardware architecture. The TP854 does not operate as an active communication processor and does not contain independent firmware functions.

The module supports ABB PROFIBUS DP-V1 interface assemblies through compatible CI854 series communication modules. Therefore, system configuration depends on the installed CI854 communication unit and controller firmware compatibility.

Frequently Asked Questions

Q: What ABB communication modules can be installed with the TP854?
A: The TP854 is specified for CI854, CI854A and CI854B communication interfaces, including CI854K01, CI854AK01 and CI854BK01 assemblies.

Q: Does the TP854 require an external power supply?
A: No. The TP854 is a passive Module Termination Unit and does not include active electronics or independent power input requirements.

Q: Is firmware stored inside the TP854?
A: No. The TP854 does not contain firmware. Communication functions are provided by the installed CI854 interface module.

Field Installation Guidelines

• Install the TP854 according to ABB AC 800M hardware configuration requirements.
• Verify that the CI854 interface module is correctly seated before system power application.
• Maintain proper cabinet grounding and follow ABB control system wiring practices.
• Keep communication wiring separated from high-voltage power cables to reduce electrical interference.
• Inspect mechanical locking components before commissioning the installed communication interface.
• Confirm compatibility between the TP854 base unit and the selected CI854 module version before replacement
