ABB CI868K01-eA Communication Interface Module

Configured for industrial communication data exchange in ABB System 800xA and AC 800M controller networks, the ABB CI868K01-eA (CI868K01-eA Communication Interface Module) provides direct hardware execution for protocol communication and controller interface tasks.

Hardware Specifications

Parameter	Specification
Model	CI868K01-eA
Brand	ABB
Product Type	Communication Interface Module
System Compatibility	ABB System 800xA / AC 800M controller platforms
Communication Function	Industrial network interface and controller communication handling
Communication Protocols	Firmware-dependent industrial communication protocols
Mounting Type	DIN rail mounting within ABB controller hardware configuration
Power Supply	24 VDC system power supply via controller infrastructure
Operating Temp	0 deg C to +55 deg C (standard industrial operating range)
Power Consumption	Not specified by available technical data
Protection Class	IP20

ABB Industrial Communication Interface Characteristics

The CI868K01-eA operates as a dedicated communication interface component within ABB automation architectures. It manages data transmission between controller resources, communication networks, and connected field-level devices.

The module uses ABB backplane bus communication technology to exchange configuration data and process information with the host controller. Therefore, system firmware compatibility and controller configuration determine supported network functions.

In addition, the module supports industrial network integration where deterministic communication timing and controlled data transfer are required. The hardware design follows ABB controller platform standards for I/O density scaling and modular system expansion.

Diagnostic indicators provide local status information for power condition, module operation, communication activity, and fault identification. These indicators assist maintenance personnel during commissioning and troubleshooting procedures.

Frequently Asked Questions

Q: Is the CI868K01-eA compatible with ABB AC 800M controllers?
A: The CI868K01-eA is designed for ABB controller environments including AC 800M systems. Exact compatibility depends on controller firmware version, System 800xA release, and installed communication software.

Q: Does the module support hot-swap replacement during controller operation?
A: Hot-swap capability depends on the configured ABB system architecture. Field replacement procedures must follow the applicable ABB hardware installation manual.

Q: How does the module handle communication diagnostics?
A: The module provides LED-based diagnostic indications for power status, module condition, and communication activity. Detailed diagnostic functions depend on firmware and engineering configuration.

Field Installation Guidelines

Install the CI868K01-eA on the designated ABB DIN rail mounting position according to the controller hardware configuration.

Verify that the module seating mechanism is fully engaged before applying system power. Ensure that the backplane connection remains clean and free from contamination.

Route communication cables separately from high-voltage power wiring to reduce electrical interference. Use proper cable shielding and connect shield layers according to ABB grounding recommendations.

Confirm firmware compatibility before commissioning. After installation, check module diagnostics, communication status, and controller recognition through the engineering tool.
