Bently Nevada 330130-080-03-05 3300 XL Standard Extension Cable

Configured for signal transmission between proximity probes and signal conditioning electronics in the 3300 XL Proximity Transducer System, the Bently Nevada 330130-080-03-05 (330130 3300 XL Standard Extension Cable) provides direct electrical connection with armored cable protection, connector protection, and agency-certified installation compatibility.

Hardware Specifications

Parameter	Specification
Model	330130-080-03-05
Brand	Bently Nevada
Product Type	3300 XL Standard Extension Cable
Origin	USA
Weight	0.15 kg
Dimensions	20.5 x 22.4 x 3.3 cm (estimated shipping size)
Operating Temp	Not specified
Power Consumption	Passive cable component, no external power consumption
Cable Length	8.0 meters (26.2 feet)
Cable Construction	Armored cable with connector protector
Output Resistance	50 ohm
Connector Protection	Included
Agency Approvals	CSA, ATEX, IECEx
Tariff Code	8537101190

Eddy-Current Signal Transmission and Rotor Dynamics Interface

The 330130-080-03-05 extension cable transfers eddy-current probe signals between the 3300 XL proximity probe and compatible Proximitor Sensor modules. Therefore, the cable maintains the electrical characteristics required for vibration displacement measurement and shaft position monitoring.

The cable uses a 50 ohm output resistance design to support stable signal transmission within the proximity measurement circuit. In addition, the armored construction improves mechanical protection in industrial routing environments where cable exposure may occur.

The 3300 XL system requires correct probe-cable-sensor matching because eddy-current measurement accuracy depends on cable electrical length and impedance characteristics. Furthermore, proper installation helps maintain gap voltage validation performance and rotor dynamics monitoring accuracy.

Frequently Asked Questions

Q: What is the function of the Bently Nevada 330130-080-03-05 cable in the 3300 XL system?
A: The cable connects a 3300 XL proximity probe to the compatible Proximitor Sensor while transmitting eddy-current displacement signals.

Q: Does the 330130-080-03-05 require an external power supply?
A: No. The extension cable is a passive component and does not consume electrical power.

Q: What protection features are included in this cable version?
A: This model includes armored cable construction and a connector protector for mechanical protection during field installation.

Field Installation Guidelines

• Install the 330130-080-03-05 cable according to the 3300 XL system wiring requirements.
• Maintain correct probe, extension cable, and Proximitor Sensor combinations to preserve calibration characteristics.
• Avoid routing the cable parallel to high-current power conductors to reduce electromagnetic interference.
• Connect cable shielding according to the equipment grounding practice specified for the monitoring system.
• Protect connectors from mechanical stress, moisture exposure, and excessive bending during installation.
• Verify cable continuity and physical condition before commissioning the vibration monitoring circuit.
