Bently Nevada 3300/50 Tachometer Monitor
TheBently Nevada 3300/50also cataloged asthe3300/50 Tachometer Monitor, operates as a dedicated hardware component for shaft speed acquisition and dual-transducer signal validation within the Bently Nevada 3300 Proximity Transducer System.
Configured for rotational speed processing in 3300 rack-based monitoring architecture,theBently Nevada 3300/50 Tachometer Monitor(3300/50 Tachometer Monitor) provides direct electrical execution of rpm conversion, zero-speed detection, and acceleration rate calculation from proximity probe or magnetic pickup inputs.
Suffix Breakdown & Model Matrix
The 3300/50 module is a fixed functional tachometer platform. No additional functional decoding is defined beyond base model identification.
Hardware Specifications
| Parameter |
Specification |
| ModelBrand |
Bently Nevada 3300/50 Tachometer Monitor |
| Origin |
USA |
| Dimensions |
3300 rack plug-in module format |
| OperatingTemp |
-20 degC to +65 degC |
| PowerConsumption |
2.5 W nominal |
| Input Channels |
Dual independent transducer inputs |
| Input Impedance |
10 kOhm nominal |
| Zero Speed Detection |
Below 100 rpm |
| Output Type |
Proportional voltage or current output |
Eddy Current Probe Scaling and Signal Validation Logic
The 3300/50 performs dual-channel input validation using independent transducer excitation paths. In eddy-current probe configurations, signal amplitude and gap voltage stability are continuously evaluated against internal scaling references. The module applies cross-input comparison logic to suppress transient deviations caused by probe instability or electrical noise coupling, ensuring consistent rpm derivation under varying shaft dynamic conditions.
Frequently Asked Questions
Q: Does the 3300/50 support hot-swap operation in the 3300 rack?
A: The module is designed for rack insertion, but signal stability requires channel isolation before physical removal to avoid transient output states on the backplane.
Q: How is dual-input voting implemented internally?
A: The module compares both transducer inputs and applies internal selection logic to reject invalid or inconsistent frequency-derived rpm values.
Q: Can magnetic pickup and proximity probe be used simultaneously?
A: Yes, but magnetic pickup usage is limited in low-speed or zero-speed detection due to reduced signal resolution at low frequency.
Field Installation Guidelines
The module shall be installed in a compatible Bently Nevada 3300 rack slot with correct backplane alignment. Transducer wiring must maintain shield continuity to a single-point ground reference to minimize induced noise loops. Signal cables shall be routed away from high-voltage switching conductors to reduce electromagnetic interference. Terminal tightening must ensure stable mechanical contact under vibration conditions typical of rotating machinery environments.
