Schneider Electric 140XBE10000 Modicon Quantum Backplane Expander

The Schneider Electric 140XBE10000, also cataloged as the 140XBE10000 Backplane Expander, operates as a dedicated hardware component for backplane expansion within the Modicon Quantum automation platform. It provides the physical interconnection required to extend compatible 12-slot to 16-slot Quantum backplanes while maintaining backplane bus continuity between connected rack segments.

Suffix Breakdown & Model Matrix

The available documentation identifies 140XBE10000 as a single catalog number. No official suffix variants or ordering matrix are specified for this model.

Hardware Specifications

Parameter	Specification
Model	140XBE10000
Brand	Schneider Electric
Origin	Not specified
Product Line	Modicon Quantum
Product Type	Backplane Expander
Application	Backplane expansion for Modicon Quantum systems
Compatible Backplanes	12-slot to 16-slot Modicon Quantum backplanes
Product Compatibility	140XBP01600
Mounting Type	Rack mountable
Weight	0.91 kg (2.00 lb)
Dimensions	Approx. 310 mm x 165 mm x 50 mm (shipping dimensions)
Operating Temp	0 degC to 60 degC
Storage Temp	-40 degC to 85 degC
Power Consumption	Not specified
Spare/Accessory	Yes
EAN	3595860026040

Backplane Bus Communication Characteristics

The 140XBE10000 is intended for physical expansion of the Modicon Quantum backplane architecture. The unit preserves electrical continuity of the backplane communication path between compatible rack sections. Proper installation requires mechanical alignment with the supported Quantum backplane assembly and the designated expansion interface. No firmware configuration or communication parameter adjustment is specified for the expander itself.

Frequently Asked Questions

Q: Does the 140XBE10000 require firmware configuration after installation?
A: No firmware configuration is specified for the backplane expander. Installation consists of mechanical mounting and connection to the supported Quantum backplane hardware.

Q: Is hot-swapping supported for the backplane expander?
A: The supplied documentation does not specify hot-swap capability. Installation or replacement should be performed with the system powered down unless Schneider Electric documentation for the complete system explicitly states otherwise.

Q: Can the expander be installed on any Modicon Quantum rack?
A: No. The published compatibility identifies use with compatible 12-slot to 16-slot Modicon Quantum backplanes, including compatibility with the 140XBP01600 backplane.

Field Installation Guidelines

• Verify compatibility between the expander and the installed Modicon Quantum backplane before mounting.
• Remove system power before installing or replacing the expander unless the complete system documentation specifies an approved energized maintenance procedure.
• Secure the rack hardware according to the mechanical mounting requirements of the Quantum platform.
• Route communication and power wiring separately to reduce electromagnetic coupling.
• Maintain protective grounding of the rack assembly in accordance with site electrical standards.
• Confirm that all backplane connectors are fully seated before system startup.
• After installation, inspect the rack for correct module alignment and verify normal controller diagnostics during power-up.
