Bently Nevada 330704-000-050-10-02-CN | Bently Nevada | Proximity Probes
Bently Nevada 330704-000-050-10-02-CN 3300 XL 8 mm Proximity Probe The Bently Nevada 330704-000-050-10-02-CN, also cataloged as the 330704 Proximity Probe, operates as a dedicated eddy-current sensing component for shaft displacement measurement within Bently Nevada 3300 XL monitoring systems. Hardware Specifications Parameter Specification Model 330704-000-050-10-02-CN Brand Bently Nevada Product Type Proximity Probe Series 3300 XL 8 mm Proximity Probe Origin USA Weight Not specified Dimensions Overall case length: 50 mm; Total length: 1.0 m Power Consumption Passive probe element; powered by compatible proximity sensor interface Sensing Technology Eddy-current non-contact displacement measurement Probe Tip Diameter 8 mm Cable Length 1.0 m (3.3 feet) Connector Type Miniature coaxial ClickLoc connector Cable Type Standard coaxial cable Agency Approval CN country-specific approval option Certificate Of Origin Available upon request Eddy-Current Measurement and Rotor Dynamics Interface The 330704-000-050-10-02-CN uses eddy-current sensing technology to convert shaft movement into electrical displacement signals. The probe operates with a compatible driver and monitoring module to provide vibration, radial position, and axial displacement measurements. Furthermore, Bently Nevada 3300 XL proximity systems apply probe scaling characteristics to maintain consistent displacement output across the operating range. The system verifies probe gap conditions through gap voltage validation, with typical monitoring references including -10 VDC target gap settings for correct installation checks. The probe assembly supports rotor dynamics analysis by providing non-contact shaft motion data. In addition, the miniature coaxial ClickLoc connector maintains signal integrity between the probe and extension cable interface while reducing connection-related signal disturbances. Frequently Asked Questions Q: What measurement principle does the Bently Nevada 330704-000-050-10-02-CN use?A: The probe uses eddy-current technology to measure shaft displacement without physical contact between the probe tip and rotating target surface. Q: What connector configuration does this model include?A: This model uses a miniature coaxial ClickLoc connector with a standard cable configuration. Q: How is the probe gap condition verified during installation?A: Technicians verify installation by checking the probe gap voltage output. Bently Nevada systems typically use a -10 VDC target gap reference for correct probe positioning. Field Installation Guidelines Install the probe perpendicular to the measured shaft surface to maintain accurate displacement sensing. Confirm the target material compatibility before commissioning the monitoring circuit. Route the coaxial cable away from high-voltage power conductors and strong electromagnetic interference sources. Maintain proper shielding practices and connect cable shields according to the monitoring system grounding requirements. Verify probe gap voltage after mechanical installation and before system calibration. Use the specified ClickLoc connector interface to prevent signal instability caused by improper cable connections. Check mechanical mounting tightness and ensure the probe tip does not contact the rotating shaft during operation.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330707-00-62-10-01-00 3300 XL 11 mm Proximity Probe
Bently Nevada 330707-00-62-10-01-00 3300 XL 11 mm Proximity Probe The Bently Nevada 330707-00-62-10-01-00, also cataloged as the 330707 3300 XL 11 mm Proximity Probe, operates as a dedicated hardware component for shaft displacement and vibration measurement within Bently Nevada 3300 XL Proximity Transducer System installations. Hardware Specifications Parameter Specification Model 330707-00-62-10-01-00 Brand Bently Nevada Product Series 3300 XL 11 mm Proximity Probe Product Type Eddy Current Proximity Sensor Origin USA Weight 0.16 kg Dimensions Estimated shipping size: 2.6 x 2.3 x 123 cm Operating Temp Not specified in supplied data Power Consumption Supplied through compatible Bently Nevada Proximity System driver, not specified Probe Thread Type 5/8-18 UNF thread Probe Construction Without armor Unthreaded Length Option 0.0 in Overall Case Length Option 6.2 in Total Length Option 1.0 meter (3.3 feet) Connector Type Miniature coaxial ClickLoc connector with connector protector Cable Type Standard cable Eddy Current Measurement and Rotor Dynamics Monitoring The 330707-00-62-10-01-00 uses eddy-current sensing technology to measure shaft movement without physical contact between the probe tip and the rotating target. Therefore, the probe provides direct measurement of radial vibration, axial displacement, and shaft position signals when connected with a compatible 3300 XL Proximitor module. The 3300 XL 11 mm probe design supports extended measurement applications where larger target motion ranges are required. Additionally, the system uses calibrated probe scaling and gap voltage validation principles to maintain measurement accuracy. The typical operating setup verifies probe gap voltage conditions around -10 VDC targets to confirm correct shaft-to-probe positioning. Furthermore, the probe signal path supports rotor dynamics analysis by providing displacement information required for vibration phase, orbit analysis, and machinery condition monitoring functions. The miniature coaxial ClickLoc connector reduces installation time while maintaining signal connection integrity in industrial monitoring assemblies. Frequently Asked Questions Q: What measurement technology does the 330707-00-62-10-01-00 use?A: The probe uses eddy-current sensing technology to measure shaft displacement and vibration without mechanical contact. Q: What connector configuration does this probe include?A: The probe includes a miniature coaxial ClickLoc connector with a connector protector and standard cable configuration. Q: Can the probe operate independently without a Proximitor module?A: No. The probe requires a compatible Bently Nevada 3300 XL Proximitor system module to provide excitation, signal conditioning, and output processing. Field Installation Guidelines Install the 330707-00-62-10-01-00 probe using the specified 5/8-18 UNF threaded mounting interface and maintain proper mechanical alignment with the rotating shaft target surface. Verify the probe gap setting before commissioning and confirm the gap voltage remains within the expected operating range for the connected Proximitor system. The cable routing should avoid high-current power conductors, strong electromagnetic interference sources, and excessive mechanical stress. Maintain proper shielding practices during installation. Connect cable shields according to the monitoring system grounding requirements to reduce electrical noise and prevent unwanted signal interference. Before operation, inspect the ClickLoc connector engagement and ensure the connector protector remains correctly installed for environmental protection.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330709-000-050-50-02-00 3300 XL 11 mm Proximity Probe
Bently Nevada 330709-000-050-50-02-00 3300 XL 11 mm Proximity Probe The Bently Nevada 330709-000-050-50-02-00, also cataloged as the 330709 3300 XL 11 mm Proximity Probe, operates as a dedicated hardware component for shaft displacement and vibration measurement within 3300 XL Proximity Transducer System installations. Hardware Specifications Parameter Specification Model 330709-000-050-50-02-00 Brand Bently Nevada Product Series 3300 XL 11 mm Proximity Probe Product Type Eddy Current Proximity Sensor Origin USA Weight Approx. 0.2 kg Dimensions 50 mm case length, 5.0 m total system length Operating Temp -35 deg C to +177 deg C Power Consumption Powered by compatible 3300 XL Proximitor Sensor module Measurement Principle Eddy current non-contact displacement measurement Probe Tip Diameter 11 mm Thread Size M16 x 1.5 metric thread Linear Range 4.0 mm Average Scale Factor 3.94 V/mm (100 mV/mil) +/- 5% Frequency Response 0 Hz to 8 kHz (+0 dB, -3 dB) Cable Type 75 ohm coaxial cable with FEP insulation Cable Length 5.0 meters (16.4 feet) Connector Type Miniature coaxial ClickLoc connector Case Material AISI 304 stainless steel Probe Tip Material Polyphenylene sulfide (PPS) Pressure Resistance Up to 34 bar differential pressure at probe tip sealing interface Eddy Current Measurement and Rotor Dynamics Characteristics The 330709-000-050-50-02-00 uses eddy-current probe scaling to convert shaft target movement into proportional electrical output signals. The probe operates with a 3300 XL Proximitor Sensor to provide a calibrated displacement signal for vibration monitoring and shaft position analysis. The system uses gap voltage validation methods with typical -10 VDC target gap settings to confirm probe installation condition and measurement range. Therefore, technicians can verify mechanical clearance before commissioning rotating equipment monitoring loops. Furthermore, the 11 mm probe geometry supports rotor dynamics analysis by providing displacement measurements required for shaft orbit monitoring, axial position detection, and Keyphasor speed reference applications. The probe design also minimizes signal distortion during dynamic shaft movement. Frequently Asked Questions Q: What measurement signals does the Bently Nevada 330709-000-050-50-02-00 provide?A: The probe provides eddy-current displacement signals for radial vibration, axial position, differential expansion, and speed reference measurement when paired with a compatible 3300 XL Proximitor Sensor. Q: Can this probe operate without a 3300 XL Proximitor Sensor?A: No. The probe requires a compatible Proximitor Sensor to supply excitation power, process the eddy-current signal, and output the conditioned measurement signal. Q: What installation factors affect measurement accuracy?A: Probe gap setting, target material condition, cable routing, connector integrity, and proper shielding practices directly affect signal stability and measurement accuracy. Field Installation Guidelines Install the probe with the M16 x 1.5 threaded mounting interface according to the mechanical drawing requirements of the machine assembly. Maintain correct probe-to-shaft target spacing during installation. Verify the gap voltage after mounting to confirm that the probe operates within the calibrated measurement range. Route the coaxial cable away from high-current power conductors and strong electromagnetic interference sources. Avoid sharp cable bends and mechanical stress at the ClickLoc connector area. Connect the cable shield according to the system grounding design. Improper grounding practices may introduce electrical noise into the vibration monitoring circuit. Before operation, confirm probe polarity, cable connection integrity, Proximitor Sensor compatibility, and channel configuration within the monitoring system.
$200.00 $100.00
-
Bently Nevada 330709-000-060-50-02-00 3300 XL 11 mm Proximity Probe Bently Nevada
Bently Nevada 330709-000-060-50-02-00 3300 XL 11 mm Proximity Probe The Bently Nevada 330709-000-060-50-02-00, also cataloged as the 330709 3300 XL 11 mm Proximity Probe, operates as a dedicated hardware component for shaft displacement and vibration signal measurement within the 3300 XL Proximity Transducer System. Hardware Specifications Parameter Specification Model 330709-000-060-50-02-00 Brand Bently Nevada Product Series 3300 XL 11 mm Proximity Probe Product Type Eddy Current Proximity Sensor Origin USA Weight Approx. 0.7 kg Dimensions 11 mm probe tip diameter, 60 mm case length, 5.0 m total probe length Operating Temp -52 deg C to +177 deg C Power Consumption Maximum 12 mA Measurement Technology Eddy current non-contact displacement measurement Probe Tip Diameter 11 mm Thread Type M16 x 1.5 metric thread Unthreaded Length 0 mm Connector Type Miniature coaxial ClickLoc connector Cable Type Standard cable Linear Range Approximately 2 mm Scale Factor 3.94 V/mm (100 mV/mil) Recommended Gap Setting Approximately 2.5 mm Frequency Response 0 Hz to 8 kHz typical Target Material AISI 4140 steel target recommended Minimum Target Diameter 31 mm Power Supply Requirement -17.5 VDC to -26 VDC Eddy Current Measurement and Rotor Dynamics Characteristics The 330709-000-060-50-02-00 uses eddy-current sensing technology to convert shaft movement into proportional electrical signals. Therefore, the probe provides direct measurement of relative shaft vibration, radial displacement, and axial position. The 3300 XL 11 mm probe system uses a defined scaling characteristic of 3.94 V/mm (100 mV/mil). Furthermore, the Proximitor Sensor validates the probe gap condition through gap voltage measurement, where approximately -10 VDC represents the normal operating target position for the sensing circuit. The 11 mm sensing tip supports increased measurement range compared with smaller diameter proximity probes. As a result, the system supports rotor dynamics analysis, shaft orbit monitoring, and machinery protection applications requiring continuous displacement feedback. Frequently Asked Questions Q: What components are required to operate the 330709-000-060-50-02-00 probe?A: The probe requires a compatible 3300 XL 11 mm Proximitor Sensor and extension cable to form a complete proximity transducer measurement circuit. Q: What electrical principle does this proximity probe use?A: The probe uses eddy current technology to measure the distance between the probe tip and the conductive shaft target without physical contact. Q: What is the purpose of gap voltage validation in this system?A: Gap voltage validation confirms that the probe operates within the calibrated measurement range and maintains correct electrical distance from the shaft target. Field Installation Guidelines Install the probe using the specified M16 x 1.5 mounting thread and maintain mechanical alignment with the shaft target surface. Adjust the probe position according to the recommended gap voltage range before connecting the monitoring channel. Verify the extension cable length and Proximitor Sensor configuration match the selected probe system. Maintain proper cable routing and avoid installation paths with excessive electromagnetic interference. Connect cable shielding according to the machinery monitoring system grounding practice. Confirm signal polarity, gap voltage, and output scaling before placing the protection channel into service.
$200.00 $100.00
-
Bently Nevada 330709-000-060-50-02-05 | 3300 XL 11 mm Proximity Probe | Bently Nevada
Bently Nevada 330709-000-060-50-02-05 3300 XL 11 mm Proximity Probe Configured for shaft displacement measurement and vibration signal acquisition in the 3300 XL Proximity Transducer System, the Bently Nevada 330709-000-060-50-02-05 (330709 3300 XL 11 mm Proximity Probe) provides direct eddy-current sensing for rotating machinery monitoring circuits. Hardware Specifications Parameter Specification Model 330709-000-060-50-02-05 Brand Bently Nevada Product Series 3300 XL 11 mm Proximity Probe Origin USA Weight Approx. 0.3 kg to 0.5 kg Dimensions 11 mm probe tip diameter; 60 mm case length; 5.0 m total length Operating Temp -51 deg C to +177 deg C Power Consumption Supplied by compatible 3300 XL Proximitor Sensor; probe operates as passive eddy-current sensing element Measurement Principle Eddy-current non-contact displacement measurement Linear Range 4.0 mm (160 mils) Incremental Scale Factor 3.94 V/mm (100 mV/mil) nominal Target Material AISI 4140 steel standard calibration target Thread Type M16 x 1.5 metric thread Probe Tip Material Polyphenylene sulfide (PPS) Case Material AISI 304 stainless steel Cable Type 75 ohm triaxial cable with FEP insulation Connector Type Miniature coaxial ClickLoc connector Agency Approval CSA, ATEX, IECEx hazardous area approvals Eddy-Current Probe Scaling and Rotor Dynamics Monitoring The 330709-000-060-50-02-05 uses an 11 mm eddy-current sensing element to convert shaft position changes into proportional electrical output signals. The 3300 XL system applies probe scaling characteristics through the Proximitor Sensor to maintain displacement measurement accuracy. Furthermore, the probe supports rotor dynamics analysis by providing shaft vibration and axial position data for condition monitoring systems. The measurement circuit evaluates shaft motion, mechanical clearance variation, and dynamic displacement behavior during machine operation. The installation process requires correct probe gap adjustment because the gap voltage directly affects measurement linearity. The standard Bently Nevada setup uses gap voltage validation with -10 VDC targets to confirm the probe operates inside the specified measurement region. Frequently Asked Questions Q: Can the 330709-000-060-50-02-05 operate without a Proximitor Sensor?A: No. The probe requires a compatible 3300 XL Proximitor Sensor and extension cable to form a complete eddy-current transducer system. Q: What type of mechanical movement can this probe measure?A: The probe measures non-contact shaft displacement, including radial vibration and axial position changes in rotating machinery. Q: What installation factors affect measurement accuracy?A: Probe gap setting, target material condition, cable routing, and proper shielding connection directly influence signal stability and measurement performance. Field Installation Guidelines Install the probe with the specified M16 x 1.5 mounting thread and maintain proper mechanical alignment with the monitored shaft surface. Verify the probe tip faces the correct target area and remains free from physical contact during operation. Adjust the probe gap according to the compatible Proximitor Sensor calibration requirements and confirm the gap voltage before commissioning. Route the triaxial cable separately from high-current power conductors to reduce electromagnetic interference. Connect cable shielding according to the system grounding practice defined for the 3300 XL monitoring rack installation. Inspect the ClickLoc connector engagement to ensure a secure electrical connection under machine vibration conditions.
$200.00 $100.00
-
Bently Nevada 330709-000-080-10-02-00 Bently Nevada 3300 XL 11 mm Proximity Probe
Bently Nevada 330709-000-080-10-02-00 3300 XL 11 mm Proximity Probe The Bently Nevada 330709-000-080-10-02-00, also cataloged as the 330709 3300 XL 11 mm Proximity Probe, operates as a dedicated hardware component for non-contact shaft displacement and vibration measurement within the 3300 XL Transducer System. Hardware Specifications Parameter Specification Model 330709-000-080-10-02-00 Brand Bently Nevada Product Type 3300 XL 11 mm Proximity Probe Origin USA Weight 0.2kg Dimensions Case length: 80 mm; Total cable length: 1.0 meter Operating Temp -52 deg C to +177 deg C Power Consumption Supplied by compatible Bently Nevada Proximitor Sensor Probe Tip Material Polyphenylene sulfide (PPS) Probe Case Material AISI 304 Stainless Steel Thread Size M16 x 1.5 Unthreaded Length 0 mm Connector Type Miniature coaxial ClickLoc connector Cable Structure 75 ohm triaxial FEP insulated standard cable without armor Linear Range 4.0 mm (160 mils) Linear Measurement Span Approximately 0.5 mm to 4.5 mm Target Material AISI 4140 steel Incremental Scale Factor 3.94 V/mm (100 mV/mil) Probe DC Resistance 7.2 +/- 0.8 ohm Recommended Target Diameter >= 31 mm Recommended Shaft Diameter >= 152 mm Recommended Case Torque 21.1 N m Maximum Case Torque 63.3 N m Eddy-Current Measurement Scaling and Rotor Dynamics Monitoring The Bently Nevada 330709-000-080-10-02-00 uses eddy-current probe scaling characteristics to convert shaft displacement into proportional electrical output signals. The 3300 XL 11 mm design provides a 4.0 mm linear range with an incremental scale factor of 3.94 V/mm, allowing the connected Proximitor Sensor to process radial vibration, axial position, and phase reference measurements. Furthermore, the probe supports rotor dynamics analysis by providing stable non-contact measurement of rotating shaft movement. The system configuration requires correct mechanical positioning and gap voltage validation. Bently Nevada proximity systems typically verify operating gap conditions near the -10 VDC target range to maintain measurement accuracy across the transducer chain. Frequently Asked Questions Q: What type of measurement does the 330709-000-080-10-02-00 perform?A: The probe measures non-contact shaft displacement using an eddy-current sensing principle. It supports vibration, axial position, and Keyphasor phase reference applications when paired with compatible 3300 XL electronics. Q: Can the probe operate without a Bently Nevada Proximitor Sensor?A: No. The probe requires a compatible Proximitor Sensor to provide excitation, signal conditioning, and output conversion. Q: What installation factors affect measurement performance?A: Probe gap setting, target material condition, shaft diameter, cable routing, and mechanical alignment directly affect measurement stability and signal accuracy. Field Installation Guidelines Install the probe with the specified M16 x 1.5 threaded mounting interface and maintain correct mechanical alignment with the shaft target surface. Verify the probe tip clearance and operating gap before commissioning the monitoring channel. Connect the ClickLoc coaxial connector securely to prevent signal interruption caused by mechanical vibration. Route the triaxial cable away from high-current power conductors, ignition sources, and strong electromagnetic interference areas. Maintain proper cable shielding practices and connect the shield according to the system grounding design. Confirm the Proximitor Sensor receives a valid gap voltage before performing vibration or position calibration. Avoid exceeding the specified case torque limits during mechanical installation.
$200.00 $100.00
-
Bently Nevada 330710-000-060-10-02-00 Bently Nevada 3300 XL 11 mm Proximity Probe
Bently Nevada 330710-000-060-10-02-00 3300 XL 11 mm Proximity Probe The Bently Nevada 330710-000-060-10-02-00, also cataloged as the 330710 3300 XL 11 mm Proximity Probe, operates as a dedicated hardware component for shaft displacement measurement within the Bently Nevada 3300 XL Proximity Transducer System. The probe converts eddy-current sensing signals into vibration and position data for rotor monitoring circuits. Hardware Specifications Parameter Specification Model 330710-000-060-10-02-00 Brand Bently Nevada Product Series 3300 XL 11 mm Proximity Probe Product Type Eddy-current proximity sensor Origin USA Weight 0.2 kg Dimensions Estimated shipping size: 3 x 2.8 x 116 cm Operating Temp Not specified Power Consumption Supplied through compatible Bently Nevada Proximitor Sensor, value not specified Total Length Option 1.0 meter (3.3 feet) Thread Type M16 x 1.5 Probe Construction Armored probe design Cable Type Miniature coaxial ClickLoc connector standard cable Connector Option 02 - Miniature coaxial ClickLoc connector Agency Approval 00 - Not required Measurement Principle Eddy-current non-contact displacement measurement Eddy-Current Measurement and Rotor Dynamics Features The 330710-000-060-10-02-00 uses eddy-current probe scaling to provide proportional displacement signals between the probe tip and the rotating shaft target. The 3300 XL 11 mm probe design supports rotor dynamics analysis by measuring shaft vibration, radial displacement, and mechanical movement. Additionally, the system requires proper gap voltage validation during commissioning. Bently Nevada proximity systems commonly use -10 VDC gap voltage targets as a reference point for probe positioning and signal calibration. Correct probe installation maintains linear measurement performance and prevents incorrect vibration interpretation. The probe construction includes an armored cable configuration that protects the miniature coaxial signal path from mechanical stress. Furthermore, the ClickLoc connector provides a controlled connection interface between the probe assembly and the extension cable or Proximitor Sensor. Frequently Asked Questions Q: What measurement principle does the Bently Nevada 330710 probe use?A: The 330710-000-060-10-02-00 uses eddy-current sensing technology to measure shaft displacement without physical contact between the probe tip and the rotating target. Q: What is the function of the -10 VDC gap voltage reference in installation?A: The -10 VDC gap voltage reference helps technicians verify probe position within the operating range of the eddy-current measurement system. Q: Can the armored cable be replaced with another cable type?A: The probe uses a specified miniature coaxial ClickLoc connector standard cable. Replacement components should match the approved 3300 XL 11 mm system configuration. Field Installation Guidelines Install the probe using the specified M16 x 1.5 mounting thread and maintain proper mechanical alignment with the shaft target. Verify the probe gap voltage before final system commissioning to confirm correct operating position. Route the armored cable away from high-current power conductors to reduce electromagnetic interference. Maintain proper cable shielding and grounding practices according to Bently Nevada installation requirements. Avoid excessive bending or mechanical loading on the miniature coaxial cable section. Confirm compatibility between the probe, extension cable, and Proximitor Sensor before energizing the monitoring loop.
$200.00 $100.00
-
Bently Nevada 330730-040-00-CN Bently Nevada 3300 XL 11 mm Extension Cable
Bently Nevada 330730-040-00-CN 3300 XL 11 mm Extension Cable The Bently Nevada 330730-040-00-CN, also cataloged as the 330730 3300 XL 11 mm Extension Cable, operates as a dedicated signal transmission component for eddy-current displacement measurement within the 3300 XL 11 mm Proximity Transducer System. Hardware Specifications Parameter Specification Model 330730-040-00-CN Brand Bently Nevada (Baker Hughes) Product Type 3300 XL 11 mm Extension Cable System Compatibility 3300 XL 11 mm Proximity Transducer System Origin USA Cable Length 4.0 meters (13.1 feet) Cable Construction 75 Ohm triaxial cable with FEP insulation Armor Type Unarmored standard cable Connector Type Gold-plated brass miniature coaxial ClickLoc connectors Operating Temp -51 deg C to +177 deg C Power Consumption Passive signal transmission component; no external power consumption Target Linear Range 4.0 mm (160 mils) within the 3300 XL 11 mm system System Scale Factor 3.94 V/mm (100 mV/mil) Environmental Protection Moisture-resistant ClickLoc positive-locking connector system Humidity Resistance 100% condensing environment capability Eddy-Current Signal Transmission and Rotor Dynamics The 330730-040-00-CN extension cable maintains the electrical characteristics required for 3300 XL 11 mm eddy-current probe operation. It transfers high-frequency displacement signals between the proximity probe and Proximitor Sensor while preserving the calibrated system response. Furthermore, the cable assembly supports rotor dynamics monitoring by maintaining signal integrity during shaft position and vibration measurement. The matched impedance triaxial construction minimizes measurement deviation across the complete probe-cable-sensor circuit. The 3300 XL 11 mm system uses probe scaling characteristics with a nominal scale factor of 3.94 V/mm. Therefore, the extension cable must remain within the specified system configuration to maintain gap voltage interpretation and displacement output accuracy. Frequently Asked Questions Q: What components connect with the Bently Nevada 330730-040-00-CN cable?A: The cable connects a 3300 XL 11 mm proximity probe to a compatible 3300 XL Proximitor Sensor within the 3300 XL Proximity Transducer System. Q: Does the 330730-040-00-CN cable require external power?A: No. The extension cable is a passive signal transmission component and receives operating excitation through the connected Proximitor Sensor circuit. Q: What installation factors affect measurement accuracy?A: Correct probe-cable matching, proper connector engagement, and controlled cable routing away from high-noise electrical sources help maintain signal performance. Field Installation Guidelines Install the cable according to the 3300 XL 11 mm Proximity Transducer System configuration requirements. Ensure ClickLoc connectors are fully engaged before equipment operation to maintain mechanical locking and environmental sealing. Route the extension cable separately from high-current power conductors to reduce electromagnetic interference. Avoid sharp bending, crushing forces, and mechanical stress on the FEP insulated cable jacket. Maintain proper shield and signal reference practices according to the monitoring system installation documentation. Verify the complete probe, extension cable, and Proximitor Sensor combination before performing shaft position or vibration calibration. Confirm gap voltage values during commissioning to validate correct probe positioning and measurement range.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330730-040-03-00 3300 XL 11 mm Extension Cable
Bently Nevada 330730-040-03-00 3300 XL 11 mm Extension Cable Configured for shaft displacement signal transmission in the Bently Nevada 3300 XL 11 mm Proximity Transducer System, the Bently Nevada 330730-040-03-00 (330730 3300 XL 11 mm Extension Cable) provides direct electrical connection between proximity probes and monitoring instrumentation. Hardware Specifications Parameter Specification Model 330730-040-03-00 Brand Bently Nevada Product Type 3300 XL 11 mm Extension Cable Origin USA Weight 0.14 kg Dimensions 18 x 18 x 1.5 cm estimated shipping size Operating Temp -40 deg C to +85 deg C Storage Temp -52 deg C to +105 deg C Power Consumption Passive cable component, no external power consumption Total Length 4.0 meters (13.1 feet) Cable Configuration Armored cable with connector protector Probe Case Material AISI 304 stainless steel (SST) Output Resistance 50 ohm Connector Type ClickLoc connectors Compatible System Bently Nevada 3300 XL 11 mm Proximity Transducer System Signal Function Vibration, axial position, phase reference, tachometer, and zero speed signal transmission Eddy-Current Signal Scaling and Rotor Dynamics Interface The 330730-040-03-00 extension cable maintains the electrical characteristics required for Bently Nevada eddy-current probe systems. It transfers proportional displacement signals from 3300 XL 11 mm probes to the Proximitor Sensor while preserving probe scaling performance. The cable assembly supports rotor dynamics monitoring functions by maintaining stable impedance characteristics between the probe and monitoring channel. Therefore, the system can process shaft vibration, axial thrust position, and phase reference signals without additional signal conditioning inside the cable assembly. The cable construction includes an armored outer layer and connector protector configuration. This design protects the signal path during mechanical installation near rotating equipment monitoring points. Frequently Asked Questions Q: What probes are compatible with the Bently Nevada 330730-040-03-00 cable?A: The cable is designed for Bently Nevada 3300 XL 11 mm proximity probes and connects through the required ClickLoc connector interface. Q: Does the 330730-040-03-00 extension cable require external power?A: No. The extension cable is a passive signal transmission component and does not consume external electrical power. Q: What measurement signals can this cable transmit in a 3300 XL system?A: The cable supports shaft vibration, axial position, ramp differential expansion, rod position, rod drop, tachometer, zero speed, and Keyphasor phase reference signals. Field Installation Guidelines Install the 330730-040-03-00 cable according to the mechanical requirements of the 3300 XL 11 mm Proximity Transducer System. Route the armored cable away from high-current power conductors, variable frequency drive output cables, and strong electromagnetic interference sources. Maintain proper cable separation to reduce electrical noise coupling. Verify that ClickLoc connectors are fully engaged before system commissioning. Inspect connector surfaces for contamination, mechanical damage, or improper alignment. Connect the cable shield according to the monitoring system grounding practice. Avoid multiple shield grounding points that may create unwanted ground loops. Confirm the probe, extension cable, and Proximitor Sensor combination matches the required system configuration before applying operating power.
$200.00 $100.00
-
Bently Nevada Proximity Sensors | Bently Nevada | 330801-28-05-101-03-02
Bently Nevada 330801-28-05-101-03-02 3300 XL PROXPAC XL Proximity Transducer Assembly The Bently Nevada 330801-28-05-101-03-02, also cataloged as the 330801 3300 XL PROXPAC XL Proximity Transducer Assembly, operates as a dedicated hardware component for non-contact shaft displacement measurement within Bently Nevada 3300 XL mechanical monitoring systems. Hardware Specifications Parameter Specification Model 330801-28-05-101-03-02 Brand Bently Nevada Origin USA Operating Temp Probe: -51 deg C to +177 deg C; Proximitor Sensor / Housing: -51 deg C to +85 deg C Power Consumption Supplied through compatible 3300 XL Proximitor Sensor system; value not specified Product Series 3300 XL PROXPAC XL Proximity Transducer Assembly Probe Type 3300 XL 8 mm Eddy Current Proximity Probe Measurement Method Non-contact eddy current displacement measurement Measurement Range 2.0 mm (approximately 80 mils) Scale Factor 7.87 V/mm (200 mV/mil) nominal Target Material AISI 4140 Steel calibration target Mounting Thread 3/4-14 NPT Probe Penetration 101 mm Standoff Adapter Length 50 mm Frequency Response 0 Hz to 10 kHz (0 to 600,000 cpm) Environmental Protection Weatherproof sealed housing, IP66 / Type 4X rated Eddy Current Measurement and Rotor Dynamics Characteristics The 3300 XL PROXPAC assembly uses an eddy-current sensing principle to convert shaft displacement into proportional electrical output signals. The integrated 3300 XL 8 mm probe provides a nominal scale factor of 200 mV/mil, allowing the connected monitoring system to evaluate shaft vibration and axial position changes. The system supports rotor dynamics analysis by measuring dynamic shaft movement without mechanical contact. Therefore, the probe assembly avoids wear between the sensor and rotating target surface. The measurement chain requires correct gap voltage validation, with Bently Nevada proximity systems typically using a -10 VDC target gap voltage reference for proper probe operating range verification. The probe assembly also maintains signal stability through controlled electromagnetic characteristics, which reduces measurement interference during rotating equipment operation. Proper probe installation and cable routing help maintain eddy-current signal integrity. Frequently Asked Questions Q: What measurement signals can the 330801-28-05-101-03-02 assembly provide? A: The assembly provides non-contact shaft displacement measurements for radial vibration, axial position, and speed-related monitoring when connected with compatible 3300 XL Proximitor Sensor electronics. Q: Does the assembly require mechanical contact with the rotating shaft? A: No. The 3300 XL PROXPAC XL assembly uses an eddy-current proximity sensing method and measures the target surface without physical contact. Q: How is the probe operating condition verified during installation? A: Technicians verify probe gap voltage and signal output through the connected proximity system. Bently Nevada systems commonly use a -10 VDC gap voltage reference for probe positioning validation. Field Installation Guidelines Install the 330801-28-05-101-03-02 assembly using the specified 3/4-14 NPT mounting interface and ensure correct mechanical alignment with the monitored shaft surface. Maintain proper probe clearance according to the connected 3300 XL Proximitor Sensor calibration requirements. Verify the target surface condition before commissioning because surface damage or incorrect material characteristics can affect eddy-current measurement accuracy. Route the extension cable away from high-current power conductors and electromagnetic interference sources. Ground cable shields according to site instrumentation standards to reduce electrical noise coupling. After installation, confirm gap voltage, output signal stability, and mechanical mounting integrity before placing the monitoring channel into service.
$200.00 $100.00
-
Bently Nevada 330851-02-000-060-50-00-CN Bently Nevada 3300 XL 25 mm Proximity Probe
Bently Nevada 330851-02-000-060-50-00-CN 3300 XL 25 mm Eddy Current Proximity Probe Configured for axial displacement and differential expansion measurement in turbine rotor monitoring systems, the Bently Nevada 330851-02-000-060-50-00-CN (330851 3300 XL 25 mm Eddy Current Proximity Probe) provides direct physical signal conversion through eddy-current sensing technology. The probe connects with 3300 XL proximity transducer systems for shaft position and rotor dynamic measurement. Suffix Breakdown & Model Matrix Code Specification 330851 3300 XL 25 mm Eddy Current Proximity Probe 02 Probe case thread option: M30 x 2 metric thread 000 Unthreaded length: 0 mm 060 Probe case length: 60 mm 50 Total system length: 5.0 meters 00 Cable armor option: No armor CN Country/agency approval option for China Hardware Specifications Parameter Specification Model 330851-02-000-060-50-00-CN Brand Bently Nevada Origin USA Weight Not specified in available technical data Dimensions 25 mm probe tip diameter, 60 mm case length Operating Temp Probe tip: -35 deg C to +200 deg C continuous operation Power Consumption Powered by compatible 3300 XL Proximitor Sensor, value depends on system configuration Product Type Eddy Current Proximity Sensors Transducer Type Non-contact eddy-current displacement probe Probe Diameter 25 mm tip diameter Thread Type M30 x 2 metric thread Linear Range 12.7 mm (500 mils) Linear Range Start Approximately 0.63 mm (25 mils) from target Average Scale Factor 0.787 V/mm (20 mV/mil) nominal Deviation from Best Fit Straight Line Less than +/- 0.31 mm (+/- 12 mils) at ambient temperature Target Material AISI 4140 steel standard target Case Material Stainless steel Connector Type ClickLoc coaxial connector with FluidLoc seal protection Eddy-Current Scaling and Rotor Dynamic Measurement The 3300 XL 25 mm probe uses eddy-current sensing to generate proportional displacement signals between the probe tip and conductive target surface. Therefore, the connected Proximitor Sensor converts gap changes into voltage outputs for machinery monitoring applications. The system supports rotor dynamics analysis by providing shaft position and movement data. Additionally, gap voltage validation uses the standard -10 VDC target condition to verify correct probe installation and measurement range before machinery operation. The large 25 mm sensing tip provides a 12.7 mm linear measurement range, which allows monitoring of large rotor axial movement and differential expansion conditions. Frequently Asked Questions Q: What measurement function does the 330851-02-000-060-50-00-CN provide?A: The probe measures non-contact shaft displacement, axial position, and differential expansion through eddy-current sensing technology. Q: Can this probe operate without a separate signal conditioner?A: No. The probe requires a compatible Bently Nevada 3300 XL Proximitor Sensor to provide excitation and convert probe signals into monitoring outputs. Q: What installation verification method applies to this probe system?A: Technicians verify probe gap voltage and confirm the approximate -10 VDC operating target condition during setup. Field Installation Guidelines Install the probe with the specified M30 x 2 mounting thread and maintain correct probe-to-target alignment. The sensing surface must face the conductive target area without mechanical interference. Route the coaxial cable away from high-current power conductors to reduce electrical interference. Maintain proper cable shielding and connect the shield according to the monitoring system grounding practice. Before operation, verify probe gap voltage, mechanical clearance, and cable connection condition. Confirm that the connected 3300 XL Proximitor Sensor receives the correct probe signal before commissioning the machinery monitoring channel.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330854-040-24-00 3300 XL 25 mm Extension Cable
Bently Nevada 330854-040-24-00 3300 XL 25 mm Extension Cable The Bently Nevada 330854-040-24-00, also cataloged as the 330854 3300 XL 25 mm Extension Cable, provides direct signal connection between a 25 mm proximity probe and a Proximitor Sensor within the 3300 XL Transducer System. Hardware Specifications Parameter Specification Model 330854-040-24-00 Brand Bently Nevada Product Type 3300 XL 25 mm Extension Cable Origin USA Weight 0.44 kg Dimensions 10 x 7.5 x 5.2 cm estimated shipping size Operating Temp -35 deg C to +200 deg C Storage Temp -35 deg C to +200 deg C Cable Length 4.0 metres (13.1 feet) Cable Construction High Temperature FluidLoc cable Armor Option High Temperature FluidLoc cable Probe Case Material AISI 304 stainless steel Power Consumption Passive cable assembly, no external power consumption Tariff Code 8537101190 Eddy-Current Signal Transmission and Rotor Dynamics Application The 330854-040-24-00 extension cable transfers eddy-current probe signals between the 3300 XL 25 mm probe and the Proximitor Sensor. Therefore, the cable maintains the electrical characteristics required for shaft displacement measurement and rotor dynamics monitoring. The cable assembly supports stable probe scaling performance by maintaining the impedance and signal path requirements of the 3300 XL proximity system. In addition, the high temperature FluidLoc cable construction allows installation in elevated temperature environments where standard cable jackets are unsuitable. The stainless steel probe case material provides mechanical protection for the connected probe assembly. Furthermore, the cable design maintains signal integrity for vibration, axial position, and differential expansion measurement circuits. Frequently Asked Questions Q: What system components connect with the 330854-040-24-00 cable?A: The cable connects a 3300 XL 25 mm proximity probe to a compatible 3300 XL Proximitor Sensor in the proximity monitoring system. Q: Does the 330854-040-24-00 require external power?A: No. The extension cable is a passive electrical connection component and does not consume external power. Q: What environmental condition does this cable support?A: The cable supports operating and storage temperatures from -35 deg C to +200 deg C with a high temperature FluidLoc cable design. Field Installation Guidelines Install the 330854-040-24-00 extension cable according to the 3300 XL Transducer System installation requirements. Verify that the probe, extension cable, and Proximitor Sensor part numbers are electrically compatible before installation. Route the cable away from high current power conductors to reduce electromagnetic interference. Maintain proper cable separation from variable frequency drive outputs and switching power circuits. Connect cable shielding according to the system grounding practice specified for the monitoring rack and machinery protection system. Avoid sharp bends, mechanical stress, and excessive pulling force during cable routing. Confirm the probe gap voltage after installation to validate correct eddy-current measurement operation.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330854-040-24-05 3300 XL 25 mm Extension Cable
Bently Nevada 330854-040-24-05 3300 XL 25 mm Extension Cable The Bently Nevada 330854-040-24-05, also cataloged as the 330854 3300 XL 25 mm Extension Cable, operates as a dedicated hardware component for probe signal extension within the Bently Nevada 3300 XL 25 mm Proximity Transducer System. Hardware Specifications Parameter Specification Model 330854-040-24-05 Brand Bently Nevada Product Type 3300 XL 25 mm Extension Cable Origin USA Weight 0.16 kg Dimensions 20 x 18 x 2 cm (estimated shipping size) Operating Temp -35 deg C to +200 deg C Power Consumption Passive cable component; no external power consumption Cable Length 4.0 m Cable Type 75 ohm triaxial cable with PFA insulation Cable Construction FluidLoc cable design for moisture and fluid migration prevention Connector Type High-temperature ClickLoc connectors Conductor Material Gold-plated brass / beryllium copper connector pins Minimum Bend Radius 25.4 mm Torque Specification Finger-tight recommended; maximum 0.565 N m System Compatibility 3300 XL 25 mm Proximitor Sensors and 25 mm Proximity Probes Agency Approval Multiple approvals including CSA, ATEX, and IECEx options Eddy-Current Signal Extension and Rotor Dynamics Interface The Bently Nevada 330854-040-24-05 extends the electrical path between the 25 mm eddy-current probe and the 3300 XL Proximitor Sensor. Therefore, the cable maintains probe calibration characteristics required for shaft displacement and differential expansion measurements. The 3300 XL 25 mm system uses controlled cable impedance and defined electrical length to preserve eddy-current probe scaling. Furthermore, the extension cable supports stable gap voltage validation procedures, including typical -10 VDC target checks during probe installation and system verification. The FluidLoc cable structure limits oil and moisture movement through the cable layers. Additionally, the ClickLoc connector design maintains mechanical engagement under vibration conditions found in rotating equipment monitoring applications. Frequently Asked Questions Q: Can the 330854-040-24-05 be used with standard 8 mm or 11 mm proximity probes?A: No. The cable is designed specifically for the Bently Nevada 3300 XL 25 mm Proximity Transducer System and requires compatible 25 mm probes and Proximitor Sensors. Q: Does the extension cable require external power or signal conditioning?A: No. The 330854-040-24-05 is a passive extension cable and receives operating signals through the connected Proximitor Sensor circuit. Q: How should the ClickLoc connectors be installed in field applications?A: Install the connectors by hand tightening first, then apply the specified maximum torque only when required. Avoid excessive force that may damage connector components. Field Installation Guidelines Verify that the total system electrical length matches the configured 3300 XL 25 mm Proximity Transducer System requirements before installation. Route the extension cable away from high-current power cables, switching devices, and sources of electromagnetic interference. Maintain the minimum bend radius during cable installation to prevent mechanical stress on the triaxial structure. Inspect ClickLoc connectors for contamination, moisture, and mechanical damage before connection. Confirm probe gap voltage after installation using the Proximitor Sensor monitoring circuit. A typical verification target is approximately -10 VDC for correct probe positioning. Install cable sections with proper mechanical support to prevent vibration-induced movement near connector interfaces.
$200.00 $100.00
-
Bently Nevada 330854-080-24-CN Bently Nevada 3300 XL 25 mm Extension Cable
Bently Nevada 330854-080-24-CN 3300 XL 25 mm Extension Cable Configured for signal transmission extension in the Bently Nevada 3300 XL 25 mm Proximity Transducer System, the Bently Nevada 330854-080-24-CN (330854 3300 XL 25 mm Extension Cable) provides direct electrical connection between the proximity probe and monitoring instrumentation. Hardware Specifications Parameter Specification Model 330854-080-24-CN Brand Bently Nevada Product Type 3300 XL 25 mm Extension Cable Origin USA Weight 0.16 kg Dimensions 20 x 18 x 2 cm (estimated shipping size) Cable Length 8.0 m (26.2 ft) Cable Type High Temperature FluidLoc cable Operating Temp -35 deg C to +85 deg C (-31 deg F to +185 deg F) Storage Temp -51 deg C to +100 deg C (-60 deg F to +212 deg F) Power Consumption Passive cable component, no external power consumption Tariff Code 8537101190 Eddy-Current Signal Transmission and Mechanical Monitoring Characteristics The Bently Nevada 330854-080-24-CN extension cable maintains the electrical characteristics required for 3300 XL 25 mm proximity probe systems. It transfers eddy-current measurement signals between the probe and the monitoring module while preserving probe calibration parameters. Additionally, the cable construction supports rotor dynamics monitoring applications where stable shaft displacement signals are required. The cable assembly works with the complete proximity transducer chain to maintain gap voltage measurement accuracy and signal integrity. The high temperature FluidLoc cable design provides resistance against fluid ingress and environmental exposure. Furthermore, the cable routing design helps reduce signal disturbance in industrial machinery monitoring installations. Frequently Asked Questions Q: What system does the Bently Nevada 330854-080-24-CN extension cable support?A: The 330854-080-24-CN supports Bently Nevada 3300 XL 25 mm proximity probe systems and provides the cable connection path between the probe and monitoring electronics. Q: Does the 330854-080-24-CN require external power?A: No. The extension cable is a passive component and does not consume electrical power. It transfers probe signals through the transducer circuit. Q: What environmental temperature range does this cable support?A: The operating temperature range is -35 deg C to +85 deg C, while the storage temperature range is -51 deg C to +100 deg C. Field Installation Guidelines Install the extension cable according to the 3300 XL proximity transducer system wiring requirements. Maintain proper cable routing separation from high-current power cables to minimize electrical interference. Connect cable shielding according to the monitoring system grounding specification. Avoid sharp bending or mechanical stress on the cable during installation. Verify connector engagement and cable continuity before placing the monitoring loop into service. Confirm the complete probe, extension cable, and monitor chain operates within the specified signal range.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330876-02-50-00-00 High-Temperature Proximity Probe
Bently Nevada 330876-02-50-00-00 3300 XL 50 mm High-Temperature Proximity Probe The Bently Nevada 330876-02-50-00-00, also cataloged as the 330876 3300 XL 50 mm High-Temperature Proximity Probe, operates as a dedicated hardware component for shaft displacement and vibration measurement within Bently Nevada TSI monitoring systems. Hardware Specifications Parameter Specification Model 330876-02-50-00-00 Brand Bently Nevada Product Type 3300 XL 50 mm High-Temperature Proximity Probe System Type Eddy Current Proximity Transducer Origin USA Tip Diameter 50 mm Linear Range Up to 27.9 mm (1100 mils) Scale Factor 394 mV/mm (10 mV/mil) Target Material AISI 4140 steel target, minimum target surface diameter 102 mm Case Thread M14 x 1.5 threaded case Case Material AISI 304 stainless steel Tip Material Polyphenylene sulfide (PPS) Cable Type High-Temperature FluidLoc cable Cable Length 5.0 meters Armor Unarmored Connector Type Miniature coaxial ClickLoc connector Operating Temp -35 deg C to +200 deg C Short-Term Temperature Limit Up to +250 deg C for transient conditions less than 24 hours Power Consumption Supplied through compatible Bently Nevada proximity driver system; value not specified Eddy-Current Measurement and Rotor Dynamics Characteristics The 330876-02-50-00-00 uses an eddy-current sensing principle to generate proportional displacement signals from conductive targets. Therefore, the probe provides a 394 mV/mm scaling factor for shaft position and vibration measurement applications. The 3300 XL 50 mm design supports differential expansion monitoring by measuring the relative movement between rotating components and stationary machine structures. In addition, the extended linear range allows the probe to monitor large mechanical displacement movements in turbine applications. The probe system requires proper gap voltage validation during commissioning. Bently Nevada proximity systems typically verify probe operation through gap voltage targets around -10 VDC to confirm correct installation position and measurement range. Furthermore, the probe construction supports rotor dynamics analysis by providing continuous displacement feedback for vibration evaluation, thrust position monitoring, and machine protection logic. Frequently Asked Questions Q: What measurement principle does the Bently Nevada 330876-02-50-00-00 use?A: The probe uses an eddy-current sensing element to measure shaft displacement without mechanical contact between the probe tip and the monitored target. Q: Can the 330876-02-50-00-00 operate in high-temperature environments?A: Yes. The probe supports continuous operation from -35 deg C to +200 deg C and allows short-term exposure up to +250 deg C under transient conditions. Q: What cable design is used on this proximity probe?A: The probe uses a 5.0 meter unarmored High-Temperature FluidLoc cable, which limits oil and fluid migration through the cable structure. Field Installation Guidelines Install the probe with the specified M14 x 1.5 threaded case connection and maintain correct mechanical alignment with the monitored shaft target. Before operation, verify the probe gap position using the compatible proximity system monitor. Confirm that the gap voltage remains within the expected operating range, including typical -10 VDC validation targets. Route the FluidLoc cable away from high-current power conductors and strong electromagnetic interference sources. Use proper cable separation practices to reduce signal disturbance. Connect the miniature coaxial ClickLoc connector securely and inspect the connection point for contamination, mechanical stress, or moisture exposure. During commissioning, confirm target material compatibility, probe clearance, and signal scaling before enabling machine protection functions.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330877-080-36-00 3300 XL 50 mm Extension Cable
Bently Nevada 330877-080-36-00 3300 XL 50 mm Extension Cable Configured for proximity signal transmission in the 3300 XL 50 mm Proximity Transducer System, the Bently Nevada 330877-080-36-00 (330877 3300 XL 50 mm Extension Cable) provides direct electrical connection between the proximity probe and Proximitor sensor. Hardware Specifications Parameter Specification Model 330877-080-36-00 Brand Bently Nevada Product Type 3300 XL 50 mm Extension Cable Origin USA Weight 0.94 kg Dimensions 28 x 28 x 3 cm (estimated shipping size) Operating Temp -51 deg C to +200 deg C Storage Temp -51 deg C to +200 deg C Power Consumption Passive cable assembly, no external power consumption Cable Length 8.0 meters (26.2 feet) Cable Type FluidLoc cable Armor and Cable Option FluidLoc cable Agency Approval No approvals Characteristic Impedance 75 Ohm +/- 2% Cable Insulation Material Perfluoroalkoxy (PFA) Shielding Construction Triaxial shielded construction Typical Capacitance 69.9 pF/m (21.3 pF/ft) Application System 3300 XL 50 mm Proximity Transducer System Eddy-Current Signal Transmission and Rotor Dynamics Interface The 330877-080-36-00 extension cable transfers eddy-current proximity signals between the 3300 XL 50 mm probe and the Proximitor sensor. Therefore, it maintains the electrical characteristics required for shaft displacement and vibration measurement circuits. The cable supports Bently Nevada proximity measurement systems that apply probe scaling and gap voltage validation methods. In addition, the triaxial shielded construction reduces external electrical interference and improves signal stability in rotor dynamics monitoring circuits. The FluidLoc cable structure prevents fluid migration along the cable path. Furthermore, the PFA insulation material supports continuous operation across the specified temperature range for rotating machinery monitoring installations. Frequently Asked Questions Q: What equipment does the 330877-080-36-00 cable connect?A: The cable connects a 3300 XL 50 mm proximity probe to a compatible 3300 XL 50 mm Proximitor sensor within the proximity transducer system. Q: Does the 330877-080-36-00 require an external power supply?A: No. The extension cable is a passive signal transmission component and does not consume external electrical power. Q: What shielding method does this extension cable use?A: The cable uses triaxial shielded construction to control electromagnetic interference and maintain proximity signal integrity. Field Installation Guidelines Install the extension cable according to the 3300 XL Proximity Transducer System wiring requirements. Maintain separation between the extension cable and high-current power cables to reduce electromagnetic interference. Connect cable shielding according to the approved system grounding practice for the monitoring rack and sensor circuit. Avoid sharp bending, mechanical stress, and damage to the FluidLoc cable outer structure during installation. Verify probe, extension cable, and Proximitor sensor compatibility before commissioning the vibration monitoring loop. Confirm gap voltage and signal output values during startup to validate correct probe installation and measurement performance.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330901-00-40-10-02-05 3300 XL NSv Proximity Probe
Bently Nevada 330901-00-40-10-02-05 3300 XL NSv Proximity Probe The Bently Nevada 330901-00-40-10-02-05, also cataloged as the 330901-00-40-10-02-05 3300 XL NSv Proximity Probe, operates as a dedicated eddy-current sensing component for shaft vibration, axial position, speed, and phase reference measurement within the 3300 XL NSv Proximity Transducer System. Hardware Specifications Parameter Specification Model 330901-00-40-10-02-05 Brand Bently Nevada Product Type 3300 XL NSv Proximity Probe Origin USA Weight 0.05 kg Dimensions Estimated shipping size: 1.2 x 1 x 117 cm Power Consumption Supplied by compatible 3300 XL NSv Proximitor Sensor Thread Type 1/4-28 UNF Armor Type Without armor Unthreaded Length Option 0.0 in Overall Case Length Option 4.0 in Total Length Option 1.0 meter (39 in) Connector Type Miniature coaxial ClickLoc connector standard cable Agency Approval Multiple Approvals Average Scale Factor 7.87 V/mm (200 mV/mil) Linear Range 1.5 mm (60 mils) Eddy-Current Probe Scaling and Rotor Dynamics Characteristics The 330901-00-40-10-02-05 uses eddy-current measurement technology to convert shaft displacement into proportional electrical signals. The probe provides an average scale factor of 7.87 V/mm (200 mV/mil), allowing the connected 3300 XL NSv Proximitor Sensor to process dynamic vibration and position signals. Furthermore, the probe design supports rotor dynamics monitoring by measuring radial vibration, radial position, axial thrust position, tachometer signals, zero speed conditions, and Keyphasor phase reference signals. The narrow side-view structure reduces installation limitations where standard 3300 and 3300 XL 5 mm or 8 mm transducer systems cannot fit. The probe also supports gap voltage validation through the standard eddy-current transducer measurement method. Proper gap voltage adjustment enables accurate target detection and stable displacement measurement. Frequently Asked Questions Q: What type of target applications does the 330901-00-40-10-02-05 support?A: The probe supports small target measurements, including radial vibration monitoring on shafts smaller than 51 mm (2 in) and axial position measurement on flat targets smaller than 15 mm (0.6 in). Q: Can the 330901-00-40-10-02-05 replace older 3300 RAM or 3000-series systems?A: The 3300 XL NSv Transducer System can replace 3300 RAM and 3000-series or 7000-series 190 Transducer Systems. However, system upgrades may require replacement of the probe, extension cable, and Proximitor Sensor depending on the existing configuration. Q: What installation condition requires the NSv probe design?A: The NSv probe design fits applications with counter bore, side-view, or rear-view restrictions that prevent installation of standard proximity transducer systems. Field Installation Guidelines Install the 330901-00-40-10-02-05 probe according to the mechanical clearance requirements of the monitored machine. Verify that the 1/4-28 UNF threaded mounting location provides correct probe alignment with the shaft or target surface. Route the miniature coaxial cable away from high-current power wiring, ignition sources, and strong electromagnetic interference areas. Maintain proper cable support to prevent mechanical stress on the ClickLoc connector. Before operation, adjust the probe gap according to the connected 3300 XL NSv Proximitor Sensor requirements. Confirm the gap voltage output and verify the target surface condition before collecting vibration or position data. For TSI applications, verify probe orientation, target geometry, and signal polarity before commissioning rotor vibration, axial position, or Keyphasor measurement channels.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330902-00-40-10-02-00 3300 NSv Proximity Probe
Bently Nevada 330902-00-40-10-02-00 3300 NSv Proximity Probe The Bently Nevada 330902-00-40-10-02-00, also cataloged as the 330902 3300 NSv Proximity Probe, operates as a dedicated eddy-current sensing component for shaft displacement measurement within Bently Nevada TSI monitoring systems. The probe uses a 1/4-28 UNF threaded body with armor protection and a 1.0 meter cable assembly for vibration and position monitoring circuits. Hardware Specifications Parameter Specification Model 330902-00-40-10-02-00 Brand Bently Nevada Product Series 3300 NSv Proximity Probe Product Type Eddy-current Proximity Sensor Origin USA Weight 0.06 kg Dimensions Estimated shipping size: 62 x 1 x 1 cm Power Consumption Supplied through compatible Bently Nevada proximity system Thread Type 1/4-28 UNF thread Armor Option Armored probe construction Unthreaded Length Option 0.0 in Overall Case Length Option 4.0 in Total Length Option 1.0 meter (39 in) Connector Type Miniature coaxial ClickLoc connector Cable Type Standard cable Eddy-Current Probe Scaling and Gap Voltage Characteristics The 330902-00-40-10-02-00 uses eddy-current probe scaling principles to convert shaft displacement into proportional electrical signals. The connected proximity transducer system measures the probe gap voltage and provides dynamic vibration or position data for TSI monitoring. The probe installation requires correct mechanical positioning to maintain the designed sensing range. Additionally, Bently Nevada proximity systems commonly validate probe operation through gap voltage monitoring, including typical -10 VDC target validation during setup procedures. The probe supports rotor dynamics analysis by providing non-contact shaft motion feedback. Therefore, engineers can evaluate vibration behavior, axial movement, and mechanical clearance conditions through the connected monitoring hardware. Frequently Asked Questions Q: What type of measurement does the 330902-00-40-10-02-00 provide?A: The probe provides non-contact displacement measurement through an eddy-current sensing principle. It detects shaft position changes and dynamic movement when connected to a compatible Bently Nevada proximity system. Q: Does this model include an armored cable construction?A: Yes. The 330902-00-40-10-02-00 configuration includes an armored probe design with a miniature coaxial ClickLoc connector and standard cable. Q: What installation factors affect probe signal accuracy?A: Mechanical alignment, target surface condition, cable routing, and proper shielding practices affect signal quality. Installers should avoid routing the probe cable near high-current power cables to reduce electrical interference. Field Installation Guidelines Install the probe into the 1/4-28 UNF mounting location and verify mechanical engagement before system operation. Maintain correct probe-to-target clearance according to the connected Bently Nevada monitoring system requirements. Route the miniature coaxial cable separately from high-voltage power conductors and switching circuits. Connect the cable shield according to the monitoring system grounding instructions to minimize electrical noise. Verify the probe output signal and gap voltage condition during commissioning before enabling vibration or position monitoring functions.
$200.00 $100.00
-
Bently Nevada 330903-00-06-10-02-05 Bently Nevada 3300 NSv Proximity Probe
Bently Nevada 330903-00-06-10-02-05 3300 NSv Proximity Probe The Bently Nevada 330903-00-06-10-02-05, also cataloged as the 330903 3300 NSv Proximity Probe, operates as a dedicated hardware component for eddy-current shaft displacement measurement within Bently Nevada machinery monitoring systems. Hardware Specifications Parameter Specification Model 330903-00-06-10-02-05 Brand Bently Nevada Product Type 3300 NSv Proximity Probe Origin USA Weight 0.32 kg Dimensions 20.5 x 22.5 x 3 cm shipping size Thread Type M8 x 1 metric thread Probe Design Unarmored proximity probe Unthreaded Length 0 mm Overall Case Length 60 mm Total Length 1.0 meter (39 in) Connector Type Miniature coaxial ClickLoc connector Cable Type Standard cable Agency Approval Multiple approvals Measurement Principle Eddy-current displacement sensing Power Consumption Supplied through compatible proximity sensor system Eddy-Current Probe Scaling and Rotor Dynamics Monitoring The Bently Nevada 330903-00-06-10-02-05 uses eddy-current probe scaling principles to convert shaft displacement changes into electrical signals for machinery condition monitoring. Therefore, the probe provides proportional measurement output when paired with compatible proximitor electronics. The probe structure supports rotor dynamics analysis by measuring radial shaft movement, vibration displacement, and mechanical position changes. In addition, the M8 x 1 threaded body allows installation in compact machinery monitoring locations where mounting space is limited. The system verifies probe operating conditions through gap voltage validation. Furthermore, Bently Nevada proximity measurement systems typically use -10 VDC target gap voltage references to confirm correct probe positioning and signal response. Frequently Asked Questions Q: What measurement technology does the 330903-00-06-10-02-05 use?A: The probe uses eddy-current sensing technology to measure shaft displacement without physical contact between the probe tip and rotating target. Q: What connector configuration does this model include?A: This model includes a miniature coaxial ClickLoc connector with a standard cable configuration. Q: Can this probe directly connect to a monitoring system input?A: No. The probe requires compatible Bently Nevada proximitor electronics to provide signal conditioning and displacement measurement output. Field Installation Guidelines Install the probe using the specified M8 x 1 mounting thread and maintain proper mechanical alignment with the shaft target surface. Keep the probe cable away from high-current power conductors to reduce electrical interference. Connect cable shielding according to the monitoring system grounding requirements. Verify probe gap voltage after installation to confirm correct target distance and measurement range. Avoid excessive cable bending near the miniature coaxial ClickLoc connector to maintain signal integrity. Confirm the probe tip remains free from mechanical contact during shaft rotation.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330903-00-21-10-02-05 3300 XL NSv Proximity Probe
Bently Nevada 330903-00-21-10-02-05 3300 XL NSv Proximity Probe The Bently Nevada 330903-00-21-10-02-05, also cataloged as the 330903 3300 XL NSv Proximity Probe, operates as a dedicated hardware component for eddy current displacement measurement within Bently Nevada TSI monitoring systems. The probe measures shaft position and dynamic vibration by converting gap distance changes into electrical signals. Hardware Specifications Parameter Specification Model 330903-00-21-10-02-05 Brand Bently Nevada Series 3300 XL NSv Proximity Probe Product Type Eddy Current Proximity Sensor Origin USA Dimensions Case length: 210 mm; Total cable length: 1.0 m Operating Temp Probe: -51 deg C to +177 deg C Power Consumption Powered by compatible Proximitor Sensor; value not specified Thread Type M8 x 1 metric thread Armor Type Unarmored Unthreaded Length 0 mm Linear Range 1.5 mm (60 mils) Typical Gap Range 0.25 mm to 1.75 mm (10 to 70 mils) Average Scale Factor 7.87 V/mm (200 mV/mil) nominal Target Material AISI 4140 steel Minimum Target Diameter 8.9 mm; 13 mm recommended Connector Type Miniature coaxial ClickLoc connector Connector Material Gold-plated brass Probe Tip Material PPS molded probe tip Agency Approval CSA, ATEX, IECEx Eddy Current Probe Scaling and Gap Voltage Validation The 330903-00-21-10-02-05 uses eddy current measurement technology to determine the distance between the probe tip and the conductive shaft target. The probe output changes according to shaft displacement, allowing the connected Proximitor Sensor to calculate vibration and position values. In addition, the system uses gap voltage validation to confirm probe operating conditions. During commissioning, technicians verify the electrical gap signal to maintain correct measurement range, with Bently Nevada proximity systems commonly using -10 VDC as the target reference for nominal operating gap conditions. The 3300 XL NSv design also applies cross-talk suppression techniques to reduce interference when multiple probes operate within limited installation areas. Therefore, the probe supports stable rotor dynamics monitoring in applications with restricted mounting space. Frequently Asked Questions Q: What measurement principle does the Bently Nevada 330903-00-21-10-02-05 use?A: The probe uses an eddy current sensing principle to measure the distance between the probe tip and a conductive shaft target. The measured displacement is converted into an electrical output signal by the Proximitor Sensor. Q: Can the 330903-00-21-10-02-05 be installed in small clearance locations?A: Yes. The 3300 XL NSv series uses a compact M8 x 1 threaded design for applications requiring limited mounting space and smaller shaft targets. Q: What target material is specified for calibration?A: The standard calibration target material is AISI 4140 steel. Other target materials may require system calibration adjustments. Field Installation Guidelines Install the probe with correct M8 x 1 thread engagement and ensure the sensing tip faces the measurement target without mechanical contact. Maintain proper cable routing to prevent signal interference from high-current power conductors and switching equipment. Connect the miniature coaxial ClickLoc connector securely to maintain signal integrity. Verify probe gap voltage during commissioning to confirm the sensing position before vibration monitoring. Use appropriate shielding and grounding practices according to the connected Bently Nevada monitoring system installation requirements. Avoid excessive bending stress on the cable near the probe body and connector area.
$200.00 $100.00
-
Bently Nevada 330904-04-14-05-02-00 | 3300 XL NSv Proximity Probe | Bently Nevada
Bently Nevada 330904-04-14-05-02-00 3300 XL NSv Proximity Probe The Bently Nevada 330904-04-14-05-02-00, also cataloged as the 330904 3300 XL NSv Proximity Probe, operates as a dedicated hardware component for non-contact shaft displacement measurement and vibration monitoring within Bently Nevada TSI monitoring systems. Hardware Specifications Parameter Specification Model 330904-04-14-05-02-00 Brand Bently Nevada Product Type Proximity Sensors Series 3300 XL NSv Proximity Probe Origin USA Dimensions 40 mm unthreaded length, 140 mm overall case length, 0.5 m cable length Operating Temp -52 deg C to +177 deg C Power Consumption Supplied by compatible Bently Nevada Proximitor sensor system Linear Range 1.5 mm (60 mils) Average Scale Factor 7.87 V/mm (200 mV/mil) Linearity Deviation Less than or equal to +/- 0.06 mm (+/- 2.3 mils) from best fit straight line Frequency Response 0 Hz to 10 kHz (+0, -3 dB) Probe Tip Material Polyphenylene sulfide (PPS) Probe Body Material 300 series stainless steel Cable Type 75 ohm coaxial cable with FEP insulation Connector Type Miniature coaxial ClickLoc connector Target Diameter Requirement Minimum 8.9 mm (0.35 inch) flat target Eddy-Current Scaling and Rotor Dynamics Measurement The 3300 XL NSv proximity probe uses eddy-current technology to convert shaft movement into proportional electrical signals. The probe maintains a defined scale factor of 7.87 V/mm, which allows the connected Proximitor sensor to calculate shaft displacement and vibration values. Additionally, the NSv probe design supports rotor dynamics analysis by providing stable gap voltage behavior and repeatable displacement output. The measurement chain validates the probe operating gap through the negative DC gap voltage range, including standard Bently Nevada -10 VDC target conditions for proper probe calibration. The narrow side-view construction reduces installation interference in applications with restricted mounting space. Furthermore, the probe supports vibration monitoring, radial position measurement, Keyphasor reference signals, and zero-speed detection functions when integrated with compatible monitoring hardware. Frequently Asked Questions Q: Can the 330904-04-14-05-02-00 probe operate without a compatible Proximitor sensor?A: No. The probe requires a compatible Bently Nevada Proximitor sensor to provide excitation, signal conditioning, and displacement output conversion. Q: What installation factors affect measurement accuracy?A: Proper probe gap adjustment, target surface condition, cable routing, and electromagnetic noise control affect the accuracy of eddy-current measurement. Q: Does the NSv probe require recalibration when replacing another 3300 XL NSv component?A: The 3300 XL NSv probe maintains interchangeability with compatible 3300 XL NSv system components when installed according to Bently Nevada configuration requirements. Field Installation Guidelines Install the probe perpendicular to the monitored shaft target surface to maintain correct eddy-current measurement geometry. Adjust the probe gap according to the connected Proximitor sensor calibration requirements and verify the operating gap voltage. Route the coaxial cable away from high-current power cables and strong electromagnetic interference sources. Maintain proper cable shielding practices and connect grounding according to the monitoring system installation manual. Inspect the target surface condition before commissioning because scratches, uneven surfaces, or contamination can influence displacement measurement. Secure the ClickLoc connector connection to prevent signal interruption caused by mechanical vibration.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330904-08-15-10-02-05 3300 XL NSv Proximity Probe
Bently Nevada 330904-08-15-10-02-05 3300 XL NSv Proximity Probe The Bently Nevada 330904-08-15-10-02-05, also cataloged as the 330904 3300 XL NSv Proximity Probe, operates as a dedicated hardware component for non-contact shaft displacement measurement within Bently Nevada machinery monitoring systems. Hardware Specifications Parameter Specification Model 330904-08-15-10-02-05 Brand Bently Nevada Product Type 3300 XL NSv Proximity Probe Origin USA Weight 0.2 kg Dimensions Estimated shipping size: 1.5 x 1.3 x 116 cm Thread Type M8 x 1 thread Armor Option Armored probe design Unthreaded Length 80 mm Overall Case Length 150 mm Total Length 1.0 meter (39 in) Connector Type Miniature coaxial ClickLoc connector Cable Type Standard cable Agency Approval Multiple approvals Tariff Code 8537101190 Eddy-Current Measurement and Rotor Dynamics The 330904-08-15-10-02-05 uses eddy-current probe scaling principles to convert shaft position changes into electrical displacement signals. Therefore, the probe provides non-contact measurement for machinery vibration and position monitoring applications. The probe design supports gap voltage validation procedures, where technicians typically verify probe operating conditions around the -10 VDC target range for correct displacement measurement. In addition, the 3300 XL NSv series supports rotor dynamics analysis by providing consistent shaft motion data for vibration monitoring channels. The miniature coaxial ClickLoc connector maintains signal connection integrity between the probe and extension cable assembly. Furthermore, the armored construction improves mechanical protection in installations that require additional cable resistance against physical stress. Frequently Asked Questions Q: What measurement principle does the 330904-08-15-10-02-05 probe use?A: The probe uses eddy-current sensing technology to measure shaft displacement without physical contact with the rotating target. Q: What is the thread specification of this probe model?A: The probe uses an M8 x 1 thread configuration with an armored construction option. Q: What connector type is installed on this probe?A: The probe uses a miniature coaxial ClickLoc connector with a standard cable assembly. Field Installation Guidelines Install the probe with the specified M8 x 1 mounting interface and maintain correct mechanical alignment with the target shaft surface. Verify probe gap voltage during commissioning to confirm proper operating range and signal output condition. Route the coaxial cable away from high-current power conductors to reduce electrical interference. Connect cable shielding according to the machinery monitoring system grounding requirements. Avoid sharp cable bends and excessive mechanical stress near the miniature coaxial ClickLoc connector. Confirm probe clearance, mounting rigidity, and target surface condition before final operation.
$200.00 $100.00
-
Bently Nevada 330905-00-08-10-02-00 | Bently Nevada | 3300 NSv Proximity Probe
Bently Nevada 330905-00-08-10-02-00 3300 NSv Proximity Probe The Bently Nevada 330905-00-08-10-02-00, also cataloged as the 330905 Proximity Probe, operates as a dedicated hardware component for shaft displacement and vibration signal measurement within the 3300 NSv Eddy Current Transducer System. Hardware Specifications Parameter Specification Model 330905-00-08-10-02-00 Brand Bently Nevada Product Type 3300 NSv Eddy Current Proximity Probe System Series 3300 NSv Proximity Transducer System Origin USA Weight 0.05 kg Dimensions Estimated shipping size: 1.6 x 1.4 x 119 cm Probe Configuration M10 x 1 metric thread, without armor Probe Case Thread M10 x 1, 15 mm Metric Thread Configuration 80 mm Total Length 1.0 meter (39 in) Cable Type Miniature coaxial ClickLoc connector standard cable Connector Option ClickLoc miniature coaxial connector Probe Tip Diameter 5 mm (0.20 in) Probe Body Diameter 5.8 mm (0.23 in) Linear Range 80 mil (2 mm) Average Scale Factor 7.87 V/mm (200 mV/mil) Eddy-Current Probe Scaling and Rotor Dynamics The Bently Nevada 330905-00-08-10-02-00 uses eddy-current probe scaling to convert shaft displacement into proportional electrical output signals. The probe provides an average scale factor of 7.87 V/mm (200 mV/mil), which allows the 3300 NSv system to process radial vibration, radial position, axial position, tachometer, and phase reference measurements. Furthermore, the probe design supports rotor dynamics monitoring on fluid-film bearing machinery. The compact 5 mm probe tip allows installation in restricted counterbore, side-view, and rear-view locations where standard 3300 and 3300 XL 5 mm or 8 mm probes cannot be installed. The system maintains gap voltage measurement principles used in Bently Nevada eddy-current monitoring technology. During installation, technicians validate the probe gap voltage condition against the typical -10 VDC target range to confirm correct probe positioning and signal operation. Frequently Asked Questions Q: What mechanical interfaces does the 330905-00-08-10-02-00 probe support?A: The probe uses an M10 x 1 metric thread with a 15 mm probe case thread length. It provides an 80 mm metric thread configuration for compact installation locations. Q: Can this probe replace standard 3300 XL 8 mm probes?A: The 3300 NSv probe provides the same 80 mil (2 mm) linear measurement range as the standard 3300 XL 8 mm system, but it uses a smaller probe body for restricted installation areas. Q: What measurements can the probe perform in a monitoring system?A: The probe supports radial vibration, radial position, axial thrust position, tachometer, zero speed, and Keyphasor phase reference measurements when connected to compatible Bently Nevada monitoring hardware. Field Installation Guidelines Install the probe with the specified M10 x 1 mounting thread and maintain proper mechanical alignment with the target shaft surface. Verify probe gap voltage after mechanical installation before placing the monitoring channel into service. Route the miniature coaxial cable away from high-current power conductors to reduce electrical interference. Maintain proper cable shielding practices and connect the shield according to the monitoring system grounding requirements. Avoid excessive cable bending near the ClickLoc connector to prevent mechanical stress on the coaxial connection. Confirm the probe target material and surface condition meet eddy-current measurement requirements before calibration.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330905-00-05-10-02-00 3300 XL NSv Proximity Probe
Bently Nevada 330905-00-05-10-02-00 3300 XL NSv Proximity Probe The Bently Nevada 330905-00-05-10-02-00, also cataloged as the 330905 3300 XL NSv Proximity Probe, operates as a dedicated hardware component for non-contact shaft displacement and vibration measurement within Bently Nevada TSI monitoring systems. Hardware Specifications Parameter Specification Model 330905-00-05-10-02-00 Brand Bently Nevada Product Type 3300 XL NSv Proximity Probe Origin USA Dimensions M10 x 1 threaded probe, 50 mm case length, 1.0 m total cable length Operating Temp -51 deg C to +177 deg C Power Consumption Supplied by compatible Proximitor sensor; probe is passive eddy-current sensing element Thread Size M10 x 1.0 metric fine thread Armor Configuration Without armor Unthreaded Length 0 mm Connector Type Miniature coaxial ClickLoc connector Cable Type Standard miniature coaxial cable Average Scale Factor 7.87 V/mm (200 mV/mil) nominal Linear Range 1.5 mm (60 mils) nominal Target Material AISI 4140 steel calibration target Frequency Response 0 Hz to 10 kHz (-3 dB) Probe Tip Material Polyphenylene sulfide (PPS) Probe Case Material AISI 303 or 304 stainless steel Minimum Cable Bend Radius 25.4 mm Eddy-Current Measurement and Rotor Dynamics Features The 3300 XL NSv proximity probe applies eddy-current sensing technology to convert shaft position changes into electrical displacement signals. Therefore, the connected Proximitor sensor can process gap voltage variations and vibration movement data for machinery protection and condition monitoring. The probe provides a nominal scale factor of 7.87 V/mm, which supports consistent displacement measurement across the specified linear range. In addition, the system uses gap voltage validation with typical -10 VDC target conditions to confirm probe operating position and measurement accuracy. Furthermore, the compact NSv mechanical structure supports rotor dynamics monitoring where installation clearance limits restrict conventional probe mounting. The narrow side-view design reduces physical interference near small-diameter shafts, counterbores, and restricted bearing housings. The miniature coaxial ClickLoc connector uses a locking mechanism to maintain electrical connection under mechanical vibration. Meanwhile, the TipLoc molding and CableLoc design increase the mechanical connection strength between the probe tip, body, and cable assembly. Frequently Asked Questions Q: What measurement principle does the 330905-00-05-10-02-00 use?A: The probe uses eddy-current sensing technology and requires a compatible Proximitor sensor to convert shaft displacement into vibration and position signals. Q: What is the function of the M10 x 1 thread configuration?A: The M10 x 1 metric thread allows installation in compact machinery locations where standard larger proximity probes cannot fit. Q: Can the probe operate independently without a Proximitor sensor?A: No. The probe functions as the sensing element and requires a compatible Bently Nevada Proximitor interface for signal conditioning and output processing. Field Installation Guidelines Install the probe with the sensing tip aligned toward the monitored shaft surface according to the machinery manufacturer installation drawing. Maintain proper probe-to-target positioning to achieve the required gap voltage range before system commissioning. Verify the electrical output through the connected Proximitor sensor and confirm the expected gap voltage condition. Route the miniature coaxial cable away from high-current power conductors and strong electromagnetic interference sources. Use proper cable support to prevent excessive bending stress near the connector and probe body. Ensure the M10 x 1 threaded section is mechanically secured without applying excessive torque that may damage the probe housing. Grounding and shielding practices should follow the applicable Bently Nevada monitoring system installation requirements.
$200.00 $100.00
Anda telah melihat 24 dari 1408 produk
