Description
The Bently Nevada 131151-01 (often associated with part number 128276-01E) is a half-height future expansion faceplate designed for use within the Bently Nevada 3500 Machinery Protection System. This component serves as a protective blanking panel for unused half-height slots in the 3500 series chassis. By covering empty rack positions, the faceplate ensures proper airflow management, maintains the structural integrity of the rack, and protects internal backplane components from environmental contaminants and physical damage.
Features
Form Factor: Half-height design specifically for 3500 series rack slots.
Function: Provides a clean, professional finish for empty expansion slots and ensures system protection.
Compatibility: Designed for standard Bently Nevada 3500 series rack configurations.
Material: Durable construction suitable for industrial environments.
Technical Specifications
Manufacturer
Bently Nevada
Part Number
131151-01
Spare/Alternate ID
128276-01E
Type
Half-Height Blanking Panel / Faceplate
Weight
0.05 kg
Operating Temperature
-40 degC to +85 degC
Storage Temperature
-40 degC to +85 degC
Installation Guidelines
Ensure the rack is powered down if performing maintenance or inserting components in adjacent slots.
Align the faceplate with the empty half-height slot guides in the 3500 rack.
Secure the panel using the integrated fastening mechanism to ensure a flush fit against the chassis front.
Proper installation of blanking panels is essential to maintain the cooling airflow requirements of the 3500 rack system.
FAQ
What is the primary purpose of the 131151-01 faceplate?
It acts as a blanking cover for unused half-height slots in a Bently Nevada 3500 rack, helping to maintain the system's environmental seal and airflow efficiency.
Is this part compatible with all 3500 series racks?
This faceplate is designed specifically for standard 3500 series chassis that accommodate half-height modules.
Does this faceplate include any electronic components?
No, this is a passive mechanical component used for slot coverage and protection.
3 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
10 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
The Bently Nevada 3300/55 Dual Velocity Monitor is a high-performance rack-based module engineered for casing vibration monitoring. By interfacing directly with Velomitor piezo-velocity sensors, this unit provides two independent channels of continuous velocity measurement. It is designed for critical machinery protection, including turbines, compressors, pumps, and large motors, ensuring reliable alarm and trip functionality in industrial environments.Features
Dual-channel configuration for independent velocity monitoring.
Direct compatibility with Velomitor piezo-velocity sensors.
Integrated alarm setpoint comparison for Alert and Danger status.
Proportional 4-20 mA output for integration with external control systems and data acquisition.
Rack-mounted design for seamless integration into 3300 series protection systems.
ApplicationsThis module is primarily utilized in rotating machinery protection systems. It provides essential casing vibration data to prevent mechanical failure in industrial assets such as centrifugal compressors, steam turbines, gas turbines, and large industrial pumps.Technical Specifications
Model Number
3300/55-01-04-18-18-00-00-05-00
Manufacturer
Bently Nevada
Module Type
Dual Velocity Monitor
Input Compatibility
Velomitor Piezo-Velocity Sensors
Output Signals
Dynamic vibration, 4-20 mA proportional
Power Consumption
Approx. 1.5 W
Operating Temperature
0 degC to +60 degC
Installation Guidelines
Ensure the 3300 rack is powered down before inserting or removing the module to prevent electrical damage.
Verify that the module is seated correctly in the rack slot to ensure proper backplane connectivity.
Use shielded cabling for all sensor inputs to minimize electromagnetic interference (EMI) in high-noise industrial areas.
Ensure proper grounding of the rack system according to local electrical codes to maintain signal integrity.
Confirm that all configuration jumpers and settings match the specific requirements of the connected sensors and alarm logic.
FAQWhat does the 3300/55 monitor?This module monitors casing vibration velocity using piezo-velocity sensors to detect mechanical issues in rotating equipment.Does this module include intrinsic safety barriers?No, the '00' barrier option in this specific model code indicates standard input configuration without integrated intrinsic safety barriers.Can this module output to a PLC?Yes, the module provides a 4-20 mA proportional output that can be wired into a PLC or DCS for remote monitoring and data logging.
10 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
10 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
DescriptionThe Bently Nevada 84141-01 is an I/O terminal module engineered for the 3300 monitoring system. This component serves as a critical interface for transducer signal management, providing secure and stable termination points for proximity probes and various vibration sensors. By facilitating precise signal routing from field instrumentation to the rack-based monitoring modules, the 84141-01 helps maintain the integrity of data acquisition in complex machinery protection environments.Features
Designed specifically for integration within the Bently Nevada 3300 system architecture.
Provides dedicated termination points for proximity probes and vibration transducers.
Ensures robust electrical connectivity for reliable signal transmission to monitoring hardware.
Passive design architecture, requiring no external power for operation.
Standardized form factor for efficient rack-mounting in industrial cabinets.
ApplicationsThis terminal module is primarily deployed in industrial facilities where continuous machinery health monitoring is required. Common applications include the protection and predictive maintenance of critical rotating equipment such as large gas and steam turbines, centrifugal compressors, and high-capacity industrial pump sets.Technical Specifications
Model
84141-01
Brand
Bently Nevada
System Series
3300
Component Type
XDCR I/O Record Terminal
Operating Temperature
0 to 60 deg C
Power Requirements
Passive (No power required)
Installation Guidelines
Ensure the 3300 rack system is de-energized before inserting or removing any I/O modules to prevent electrical faults.
Handle the module by its edges to avoid contact with sensitive electronic components on the circuit board.
Verify that all field wiring is properly secured to the terminal blocks to prevent signal noise or intermittent connections.
Maintain proper cable routing practices to separate low-level transducer signals from high-voltage AC power lines to minimize electromagnetic interference (EMI).
Ensure the module is fully seated in the rack slot and that the front-panel retaining screws are tightened to provide a secure ground connection and physical stability.
FAQIs the 84141-01 an active or passive module?The 84141-01 is a passive termination module. It does not require an external power supply to function, as it acts as a connection bridge for field sensors.Can this module be used outside of a 3300 rack?No, this terminal is designed specifically for the physical and electrical interface requirements of the Bently Nevada 3300 monitoring system rack.
10 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
2 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
DescriptionThe Bently Nevada 3300/01 System Monitor is a core component of the 3300 machinery protection system, acting as the primary supervisory module for the rack. It is engineered to monitor the operational health of all installed modules within the rack, manage alarm relay logic, and facilitate reliable communication across the backplane. This module ensures system integrity by providing centralized diagnostics for critical rotating equipment, including turbines and compressors.Features
Centralized rack supervision for all integrated monitoring modules.
Coordinates OK, Bypass, Alert, and Danger relay status.
Continuous monitoring of rack power supply voltages and internal communication bus health.
Integrated LED indicators for rapid visual assessment of rack and module status.
Interfaces directly with external control systems to provide alarm signaling and diagnostic data.
ApplicationsThis module is designed for use in industrial environments requiring continuous machinery protection, such as power generation facilities, petrochemical plants, and large-scale industrial compressor stations.Technical Specifications
Model
3300/01 (330001)
Brand
Bently Nevada
Series
3300
Product Type
System Monitor Module
Operating Temperature
0 to 60 degC
Power Consumption
Approx. 2 W
Installation Guidelines
Ensure the rack power is disconnected before installing or removing the 3300/01 module to prevent electrical damage.
Slide the module into the designated slot in the 3300 rack, ensuring it is properly seated in the backplane connector.
Secure the module using the front-panel captive screws to maintain proper grounding and vibration resistance.
Handle with standard ESD precautions to protect internal sensitive electronic components.
Verify that all cabling to the rack interfaces is properly routed away from high-EMI sources to maintain signal integrity.
FAQWhat is the primary function of the 3300/01 module?The 3300/01 serves as the supervisory module for the 3300 rack, coordinating alarm relays and monitoring the health of other modules and the rack backplane itself.Is this module compatible with other 3300 series components?Yes, the 3300/01 is specifically designed for integration within the Bently Nevada 3300 series rack architecture.
2 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
The Bently Nevada 3300/16-11-01-01-00-00-00 is a dedicated dual-channel vibration monitor engineered for the 3300 rack-based monitoring system. This module provides essential protection and continuous surveillance for critical rotating machinery, including large turbines, centrifugal compressors, and industrial pumps. By processing signals from proximity probes, it delivers real-time radial vibration data, allowing operators to monitor machinery health and trigger alarms when parameters exceed defined safety limits.Features
Dual-channel configuration optimized for XY radial shaft vibration monitoring.
Direct interface with standard proximity probe systems and Proximitor sensors.
Integrated Alert and Danger alarm logic with relay output capabilities.
Comprehensive LED status indicators for local monitoring of OK, Bypass, Alert, and Danger states.
High-precision signal conditioning with programmable sensitivity settings.
ApplicationsThis module is widely utilized in power generation, petrochemical processing, and oil and gas industries. It serves as a primary component in machinery protection systems, ensuring reliable operation of high-speed rotating equipment through continuous displacement monitoring.Technical Specifications
Model Number
3300/16-11-01-01-00-00-00
Brand
Bently Nevada
Series
3300 System
Operating Temperature
0 to 60 deg C
Power Consumption
Approx. 1.5 W
Input Sensitivity
200 mV/mil (8 V/mm) default
Signal Accuracy
±0.33% typical (at 25 deg C)
Output Signals
4-20 mA, 1-5 VDC, 0 to -10 VDC
Installation Guidelines
Ensure the 3300 rack is powered down before inserting or removing the module to prevent electrical damage.
Verify that the module is fully seated in the rack backplane to ensure proper communication and power distribution.
Utilize shielded cabling for all proximity probe inputs to minimize EMI interference in industrial environments.
Maintain adequate airflow within the cabinet; the 3300 rack requires sufficient clearance for cooling to prevent thermal degradation of internal components.
Always perform system calibration after initial installation to match the specific transducer sensitivity and full-scale range requirements.
FAQWhat is the primary function of the 3300/16 monitor?The 3300/16 is designed to monitor radial shaft vibration using two independent channels, providing both local status indication and relay-based alarm outputs for machinery protection.Is this module compatible with existing 3300 rack systems?Yes, this unit is a standard 3300 series module designed for seamless integration into existing 3300 rack backplanes.Does this unit require external configuration?The 3300/16 features user-programmable settings for sensitivity and full-scale ranges to match the specific requirements of your proximity probe installation.
10 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
DescriptionThe Bently Nevada 134652-01 Transient Data Interface (TDI) module serves as the primary communications gateway for the 3500 Machinery Protection System. By integrating the functionality of a traditional Rack Interface Module (RIM) with high-speed transient data acquisition, this unit facilitates the seamless transmission of both steady-state and dynamic machinery data to external diagnostic software, such as System 1.Features
Advanced Data Acquisition: Captures high-resolution transient waveform data during machine startup, shutdown, and steady-state operation.
Seamless Integration: Designed for direct compatibility with Bently Nevada 3500 configuration software and asset management platforms.
High-Speed Communication: Features an integrated Ethernet interface to ensure rapid data transfer and reduced latency in complex monitoring environments.
Robust Diagnostics: Supports real-time monitoring and diagnostic analysis of rotating machinery, including M-Series monitor compatibility (e.g., 3500/40M, 3500/42M).
Operational Continuity: Equipped with dual-buffer memory to preserve critical startup/shutdown event data during power fluctuations.
Technical Specifications
Manufacturer
Bently Nevada
Part Number
134652-01
Module Type
Transient Data Interface (TDI)
Communication Interface
Ethernet
System Compatibility
3500 Series Monitoring Systems
Operating Frequency
Up to 30 kHz
Installation Guidelines
ESD Protection: Always utilize an anti-static wrist strap when handling the module to prevent damage to sensitive internal circuitry.
Rack Placement: The 134652-01 is designed for installation in designated slots within the 3500 rack; ensure the backplane connector is properly aligned before seating.
Power Management: Ensure the 3500 rack power supplies are de-energized or the system is in a safe maintenance state before inserting or removing the interface module.
Grounding: Verify that the rack is properly grounded to the cabinet chassis to minimize electromagnetic interference (EMI) and ensure signal integrity.
Cable Routing: Use shielded Ethernet cabling for network connections and maintain separation from high-voltage power lines to prevent signal noise.
FAQWhat is the primary function of the 134652-01 TDI module?The TDI module acts as the communication processor for the 3500 rack, managing data flow between the rack monitors and external diagnostic software, while also providing high-speed capture of transient events for detailed machinery analysis.Is this module compatible with all 3500 series racks?The 134652-01 is designed for the standard 3500 system architecture. It is commonly used with M-Series monitors, but users should verify their specific rack configuration and firmware requirements in the Bently Nevada 3500 system manual.
10 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
10 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
DescriptionThe Bently Nevada 3500/72M (176449-08) is a four-channel Reciprocating Rod Position Monitor designed for critical machinery protection in reciprocating compressor applications. It adheres to API 618 standards, providing continuous monitoring of rod position, rod drop, and hyper-compressor parameters. By processing signals from proximity transducers, the module provides both dynamic and static position measurements, comparing these values against user-programmable alarm setpoints to ensure asset integrity.Features
Four-channel monitoring capability for high-density rack configurations.
Configurable for Rod Position, Rod Drop, and Hyper-Compressor measurement functions.
Provides machinery protection through continuous parameter monitoring and alarm setpoint comparison.
Includes front-panel buffered transducer outputs for connection to external diagnostic and analysis equipment.
Flexible I/O options including internal termination, external termination, or internal barrier configurations.
Applications
Reciprocating Compressors: Monitoring crosshead and rod behavior for wear, misalignment, and mechanical degradation.
Hyper-Compressors: High-pressure monitoring with specialized alarms for transducer loss.
Industrial Pumps: Tracking piston and plunger position to ensure smooth operation and early fault detection.
Rod Trajectory Analysis: Real-time tracking of lateral vibration and rod movement.
Technical Specifications
Model
3500/72M 176449-08
Manufacturer
Bently Nevada
Input Impedance
10 kOhm
Output Impedance
510 Ohm
Transducer Power Supply
-24 Vdc
Gap Filter
-3 dB at 0.09 Hz
Average Piston Position (Fixed)
1 Hz to 600 Hz
Weight
0.85 kg
Installation Guidelines
The 3500/72M consists of a main module that plugs into the front of the 3500 rack and a corresponding I/O module installed at the rear.
The module can be placed in any of the 14 available monitor slots in the 3500 rack.
Ensure the system is powered down before inserting or removing any module to prevent electrical damage.
Use shielded cabling for all transducer inputs to minimize EMI interference in industrial environments.
Handle modules using ESD-safe practices to protect sensitive internal components.
Verify that the I/O module termination type (internal/external/barrier) matches your specific field wiring requirements.
FAQWhat is the primary purpose of the 3500/72M?The 3500/72M provides machinery protection for reciprocating compressors and pumps by continuously monitoring rod position and comparing inputs against configured alert and danger setpoints.What inputs does this monitor accept?It accepts inputs from proximity transducers to measure rod position, rod drop, and hyper-compressor parameters.Are the channels configurable?Yes, the 3500 Rack Configuration software allows each channel to be configured in pairs to perform specific functions such as Rod Position, Rod Drop, or Hyper-Compressor measurements.
10 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
4 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
DescriptionThe Bently Nevada 3500/05-01-01-00-00-00 is a 19-inch full-size rack chassis designed to house the components of the 3500 Machinery Protection System. This rack provides the physical mounting, power distribution, and communication backplane required for the operation of 3500 series monitoring modules. As a critical component of the Bently Nevada 3500 series, this chassis supports up to 14 module slots, allowing for flexible configuration of monitoring, relay, and communication interfaces.Features
Standard 19-inch rack-mount design for integration into industrial control cabinets.
Accommodates up to 14 module slots for versatile system expansion.
Integrated backplane for high-speed communication between installed modules.
Panel mount configuration for secure, fixed-location installation.
Robust construction designed for industrial environments.
Technical Specifications
Model
3500/05-01-01-00-00-00
Rack Size
19-inch (14 slots)
Mounting Type
Panel Mount
Agency Approvals
None
Weight
5.95 kg
Installation Guidelines
Ensure the rack is mounted in a clean, dry, and vibration-dampened environment to maintain system integrity.
Verify that the panel cutout dimensions are compatible with the 19-inch rack footprint before installation.
Always power down the system before inserting or removing any monitoring modules from the rack slots to prevent electrical damage.
Ensure proper grounding of the chassis to the cabinet ground bus to minimize EMI and protect against electrical surges.
Maintain adequate clearance around the rack to allow for proper airflow and cooling of the internal modules.
FAQIs this rack compatible with all 3500 series modules?Yes, this 19-inch full-size rack is designed to be the primary housing for standard 3500 series monitoring modules, relay modules, and communication gateways.Does this unit include power supplies?No, this order code represents the chassis rack only. Power supplies and monitoring modules must be ordered and installed separately according to your specific system requirements.
4 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
3 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
The Bently Nevada 330880-28-15-035-00-02 is a high-performance PROXPAC XL Proximity Transducer Assembly. This unit integrates a 3300 XL 8 mm proximity probe and a Proximitor sensor into a single, self-contained housing. By combining these components, the assembly eliminates the requirement for external extension cables and separate Proximitor housings, simplifying field wiring directly between the monitoring system and the transducer assembly.Features
Integrated 3300 XL 8 mm proximity probe and sensor system.
Constructed from Polyphenylene Sulfide (PPS), an advanced molded thermoplastic reinforced with glass and conductive fibers for structural strength and electrostatic dissipation.
Rated for Type 4X and IP66 environments, providing robust protection in severe industrial conditions.
Eliminates the need for extension cables between the probe and sensor.
Direct interface with monitoring equipment reduces installation complexity.
Applications
Steam and Gas Turbines: Monitoring for shaft vibration, axial position, and eccentricity.
Centrifugal Compressors: Precision tracking of shaft displacement during high-speed gas compression.
Hydro Turbines: Rotational dynamics monitoring in power generation.
Centrifugal Pumps: Early detection of bearing wear and misalignment through vibration analysis.
Electric Motors and Generators: Ensuring bearing health and shaft alignment to prevent mechanical failure.
Technical Specifications
Model
330880-28-15-035-00-02
Probe Type
3300 XL 8 mm
Standoff Adapter
1.5 in (38 mm)
Probe Penetration
3.5 in (96 mm)
Mounting Thread
3/4-14 NPT
Housing Material
Polyphenylene Sulfide (PPS)
Environmental Rating
IP66 / Type 4X
Installation Guidelines
Mount the assembly using the specified 3/4-14 NPT mounting thread.
Ensure all conduit entries are properly sealed to maintain the IP66/Type 4X rating and prevent moisture ingress.
Verify that the 1.5-inch standoff and 3.5-inch probe penetration provide adequate clearance from all internal machine components before final installation.
Handle the probe tip with care to avoid mechanical damage or calibration drift.
Ensure the system is powered down before performing any wiring or maintenance on the transducer assembly.
FAQWhat is the primary advantage of the PROXPAC XL design?The PROXPAC XL design integrates the Proximitor sensor directly into the housing, removing the need for extension cables and separate sensor mounting, which simplifies installation and reduces potential points of failure.What materials are used in the housing?The housing is manufactured from Polyphenylene Sulfide (PPS), a durable thermoplastic reinforced with glass and conductive fibers to provide strength and dissipate electrostatic charges.Is this unit suitable for harsh environments?Yes, the assembly is rated for IP66 and Type 4X, making it suitable for use in demanding industrial environments where protection against dust and moisture is required.
3 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
6 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
DescriptionThe Bently Nevada 3500/42M Proximitor Seismic Monitor is a high-performance, four-channel module designed for the 3500 Series machinery protection system. This module provides continuous, reliable monitoring of vibration and position parameters, ensuring critical turbomachinery assets are protected against mechanical failure. It accepts inputs from a variety of transducers, including proximity probes, velocity sensors, and accelerometers, making it a versatile tool for complex industrial monitoring requirements.Features
Four-channel monitoring capability for radial vibration, thrust position, and seismic signals.
Fully compatible with 3500 Series rack systems for seamless integration.
Programmable Alert and Danger setpoints to facilitate precise machinery protection.
Integrated 4-20 mA recorder outputs for direct communication with external DCS or PLC control systems.
Buffered transducer outputs provided via front-panel BNC connectors for diagnostic analysis.
Comprehensive LED status indicators for OK, TX/RX, and Bypass operational states.
Designed to comply with API 670 standards for machinery protection systems.
ApplicationsThe 3500/42M is primarily utilized in critical rotating machinery environments, including steam and gas turbines, centrifugal compressors, pumps, and large motors. It supports advanced diagnostic functions such as Rolling Element Bearing Analysis (REBAM), shaft absolute vibration, and circular acceptance region (CAR) monitoring.Technical Specifications
Model
3500/42M
Channels
4
Operating Temperature
-30 degC to +65 degC
Power Consumption
7.7 W (typical)
Outputs
4-20 mA, Relay (Alert/Danger), Buffered BNC
Compliance
API 670, CE, CSA/NRTL/C, Zone 2
Installation Guidelines
Ensure the 3500 rack power is disconnected before installing or removing the module.
Handle the module using proper ESD (Electrostatic Discharge) protection practices to prevent damage to internal circuitry.
Verify that the module is fully seated in the rack slot and that the front-panel screws are tightened to ensure a secure ground connection.
Use shielded cabling for all transducer inputs to minimize electromagnetic interference (EMI) and signal noise.
Ensure adequate ventilation around the 3500 rack to maintain operating temperatures within the specified -30 degC to +65 degC range.
FAQWhat types of transducers are compatible with the 3500/42M?The module supports proximity probes, velocity transducers, and accelerometers, allowing it to monitor a wide range of vibration and position parameters.Can this module communicate with a PLC?Yes, the 3500/42M provides 4-20 mA proportional recorder outputs that can be integrated directly into a PLC or DCS for external monitoring and control.Does this module meet industry standards?Yes, the 3500/42M is designed to meet API 670 standards for machinery protection and holds various certifications including CE and CSA/NRTL/C for hazardous area applications.
6 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
2 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
The Bently Nevada 21000-34-05-15-029-04-02 is an aluminum proximity probe housing assembly designed for the secure mounting and environmental protection of 3300 XL 8mm proximity probes. This assembly is engineered to meet the rigorous demands of industrial machinery monitoring, providing a robust, explosion-proof enclosure that complies with API 670 standards for externally mounted proximity probe housings.Features
Material: Durable aluminum housing construction (21000 series).
Hazardous Area Rating: Rated as explosion-proof for use in classified industrial environments, featuring CSA Type 4 enclosure certification.
Compatibility: Specifically configured for 3300 XL 8mm probes with connector protectors.
Mounting: 3/4-14 NPT mounting thread with a single 3/4-14 NPT plug.
Precision Design: Includes a 0.5m probe cable length and a 1.5-inch minimum standoff adapter length, with a 2.9-inch probe penetration depth.
Applications
Oil & Gas: Bearing condition monitoring for compressors and pump sets in refineries and transmission stations.
Power Generation: Axial displacement and radial vibration monitoring for steam turbine generator sets.
Petrochemical: Core power equipment monitoring, including large-scale mixers and centrifuges.
Heavy Industry: Vibration monitoring for large fans, coal mills, and industrial transmission systems.
Technical Specifications
Model Number
21000-34-05-15-029-04-02
Housing Material
Aluminum
Mounting Thread
3/4-14 NPT
Probe Compatibility
3300 XL 8mm
Probe Cable Length
0.5 m (20 in)
Standoff Adapter
1.5 in (38 mm)
Probe Penetration
2.9 in (73.66 mm)
Fittings
One 3/4-14 NPT plug
Compliance
API 670, CSA Type 4
Installation Guidelines
Ensure the probe lead is longer than the sleeve length to prevent mechanical stress.
For sleeve lengths exceeding 304 mm (12 inches), utilize additional sleeve support to mitigate vibration-induced fatigue.
Verify that the hazardous area classification of the installation site matches the rating of the housing assembly.
Ensure all NPT threads are properly sealed to maintain the integrity of the explosion-proof enclosure.
Handle with care to avoid damage to the probe tip or connector protector during installation.
FAQsWhat is the primary function of this housing assembly?The 21000-34-05-15-029-04-02 acts as a protective, explosion-proof enclosure for proximity probes, shielding them from harsh environmental factors such as oil, dust, and moisture while ensuring accurate vibration and position data collection.Is this assembly compliant with industrial standards?Yes, this housing is fully compliant with the American Petroleum Institute (API) 670 standard and carries CSA Type 4 enclosure certification for hazardous area applications.Can this be used in explosive atmospheres?Yes, the assembly is rated as explosion-proof for hazardous locations, provided that the installation adheres to the relevant safety codes and the specific hazardous area approval requirements for your facility.
2 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
5 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
The Bently Nevada 330180-X1-CN MOD:145004-13 is a high-precision 3300 XL Proximitor Sensor engineered for non-contact vibration and position monitoring in industrial rotating machinery. As a critical component of the 3300 XL 8 mm Proximity Transducer System, this unit converts probe tip proximity to a conductive surface into a proportional output voltage, enabling accurate measurement of both static and dynamic machine parameters.Features
Designed for fluid-film bearing machines, compression systems, and speed measurement applications.
Provides complete interchangeability of probes, extension cables, and sensors, eliminating the need for individual bench calibration.
Backwards compatible with legacy 3300 series transducer system components.
Extended temperature range performance for demanding industrial environments.
Includes hazardous area approvals (ATEX, IECEx, and NEPSI) for safe operation in explosive atmospheres.
Applications
Oil & Gas: Monitoring critical centrifugal compressors and pumps in refineries and offshore platforms.
Power Generation: Protecting steam and gas turbines, and hydro generators.
Petrochemical Processing: Tracking equipment health in high-risk areas where flammable gases are present.
Water & Wastewater: Ensuring long-term reliability in large-scale pumping systems.
Technical Specifications
Model
330180-X1-CN MOD:145004-13
System Compatibility
3300 XL 8mm Proximity Transducer System
Linear Range
2 mm (80 mils)
Output Resistance
50 Ohm
Frequency Response
0 to 10 kHz (+0, -3 dB)
Extension Cable Capacitance
69.9 pF/m (21.3 pF/ft) typical
Operating Voltage
-17.5 to -26 Vdc
Agency Approvals
CSA, ATEX, IECEx, NEPSI
Installation Guidelines
Mounting: Install the sensor in a protective enclosure or on a DIN rail within a control cabinet.
Isolation: The mounting base provides electrical isolation from the DIN rail; no additional isolator plates are required.
Spacing: To prevent cross-talk, maintain a minimum separation of 40 mm (1.6 in) for axial measurements or 74 mm (2.9 in) for radial measurements when installing multiple sensors.
Handling: Ensure the system is powered down before connecting or disconnecting cables to prevent electrical damage.
FAQWhat is the primary function of the 330180-X1-CN?It is a Proximitor sensor that processes signals from a proximity probe to provide a voltage output proportional to the distance between the probe tip and a conductive target, used primarily for vibration and position monitoring.What does the -CN suffix indicate?The -CN suffix denotes that the unit is configured with agency approvals specifically for the Chinese market, including compliance with NEPSI standards alongside standard ATEX/IECEx hazardous area markings.Is this sensor compatible with older 3300 series probes?Yes, the 3300 XL system is designed to be backwards compatible with non-XL 3300 series 5 mm probes, though system-wide performance is optimized when using the full 3300 XL component set.
5 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
6 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
DescriptionThe Bently Nevada 3300/40 Eccentricity Monitor is a specialized rack-mounted module engineered for the continuous monitoring of shaft eccentricity in critical rotating machinery, such as large steam turbines and compressors. This module detects rotor bow and misalignment by measuring shaft displacement during slow-roll conditions. By providing real-time data and alarm setpoint comparisons, it serves as a vital component in predictive maintenance programs, helping to prevent catastrophic equipment failure and minimize unplanned downtime.Features
Designed for integration within the Bently Nevada 3300 series monitoring rack.
Provides continuous monitoring of shaft eccentricity and slow-roll displacement.
Features user-programmable sensitivity settings (200 mV/mil or 100 mV/mil).
Includes integrated relay outputs for Alert and Danger alarm conditions.
Equipped with front-panel LED indicators for rapid status identification, including OK, Bypass, Alert, and Danger states.
Supports standard proximity probe and Proximitor sensor inputs.
ApplicationsThis module is primarily utilized in power generation and heavy industrial environments where large rotating equipment requires precise shaft position monitoring. It is essential for detecting thermal bow or mechanical misalignment during turbine start-up, shut-down, and steady-state operation.Technical Specifications
Model
3300/40-13-01-01-00-00
Brand
Bently Nevada
Series
3300
Operating Temperature
0 to 60 deg C
Power Consumption
~1.5 W
Signal Accuracy
±0.33% typical, ±1% max at 25 deg C
Output Signals
+4 to +20 mA, +1 to +5 VDC, 0 to -10 VDC
Installation Guidelines
Ensure the 3300 rack is powered down before inserting or removing the module to prevent electrical damage.
Handle the module using proper ESD (Electrostatic Discharge) precautions to protect internal circuitry.
Verify that the proximity probe and Proximitor sensor wiring is shielded and routed away from high-voltage or high-EMI sources to maintain signal integrity.
Ensure the module is fully seated in the rack slot and the front-panel screws are tightened to maintain proper grounding and mechanical stability.
Confirm that the configuration settings (sensitivity and alarm setpoints) match the specific machine requirements before commissioning.
FAQWhat is the primary function of the 3300/40 module?The 3300/40 module monitors shaft eccentricity, which is the displacement of the shaft centerline from the center of rotation, typically during slow-roll conditions to detect rotor bow.Does this module require external power?The module is powered directly through the 3300 series rack backplane; it consumes approximately 1.5 W of power during operation.What type of sensors does this module support?This specific model (3300/40-13-01-01-00-00) is configured for use with standard Bently Nevada proximity probes and Proximitor sensors.
6 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
10 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
DescriptionThe Bently Nevada 3300/03-02-00 System Monitor serves as the primary supervisory unit for the 3300 Series rack-based monitoring system. This module is engineered to provide centralized oversight of rack health, including power supply monitoring, communication bus integrity, and the operational status of individual monitoring modules. By coordinating alarm relay logic and providing a unified diagnostic interface, it ensures reliable protection for critical rotating machinery such as turbines and compressors.Features
Centralized supervision of all modules installed within the 3300 rack.
Integrated coordination for OK, Bypass, Alert, and Danger relay states.
Continuous monitoring of rack-level power supply and internal communication bus health.
Front-panel LED indicators for immediate visual status of rack and module health.
Facilitates alarm signaling and diagnostic data exchange with external control and automation systems.
ApplicationsThis module is essential for critical infrastructure protection in industrial environments, specifically designed for use in Bently Nevada 3300 rack systems monitoring rotating equipment including steam and gas turbines, centrifugal compressors, pumps, and large motors.Technical Specifications
Model
3300/03-02-00
Brand
Bently Nevada
Series
3300
Operating Temperature
0 to 60 degC
Power Consumption
Approximately 2 W
Agency Approval
Standard (No special certification)
Installation Guidelines
Ensure the 3300 rack is powered down before inserting or removing the System Monitor module to prevent electrical damage or unintended relay activation.
Slide the module into the designated slot in the 3300 rack, ensuring proper alignment with the backplane connectors.
Secure the module using the provided front-panel locking mechanisms to ensure a reliable connection and proper grounding.
Maintain adequate ventilation around the rack to ensure the ambient temperature remains within the 0 to 60 degC operating range.
Handle with standard ESD precautions to protect sensitive internal electronic components.
FAQWhat is the primary function of the 3300/03-02-00?The module acts as the supervisory controller for the 3300 rack, managing alarm relay coordination and monitoring the health of the rack's power and communication infrastructure.Can this module be used in any Bently Nevada rack?This module is specifically designed for the 3300 Series rack system. It is not compatible with other series such as the 3500 or 7200 systems.What do the LED indicators on the front panel signify?The LEDs provide real-time status updates regarding the health of the rack power, the integrity of the communication bus, and the operational status of the monitoring modules installed in the rack.
10 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
2 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
The Bently Nevada 21000-16-10-00-103-04-02 is a specialized proximity probe housing assembly designed to provide robust mechanical and environmental protection for 3300 XL 8mm proximity probes. This assembly ensures the integrity of safety-critical vibration and position measurements in demanding industrial environments by shielding the sensor from process fluids, moisture, and mechanical damage.Features
Designed for 3300 XL 8mm proximity probes.
Constructed with a 3/4-14 NPT mounting thread for secure installation.
Includes a 1.0 m (39 in) probe cable configuration.
Features a 10.3 in (261.62 mm) probe penetration depth.
Equipped with one 3/4-14 NPT plug for conduit port sealing.
CSA Type 4 enclosure rating for environmental protection.
Explosion-proof design suitable for hazardous area applications (Class I, Div 1 & 2, Groups C and D).
Compliant with API 670 standards for machinery protection systems.
Applications
Oil and Gas: Monitoring of centrifugal and reciprocating compressors in refineries and liquefaction facilities.
Electric Power: Protection of steam turbines and critical feedwater pumps in thermal and nuclear power plants.
Petrochemicals: Integration with ethylene cracking and ammonia compressor systems.
Industrial Manufacturing: Vibration monitoring for large blowers and pump sets in steel mills and water treatment facilities.
Technical Specifications
Model Number
21000-16-10-00-103-04-02
Probe Compatibility
3300 XL 8mm
Probe Cable Length
1.0 m (39 in)
Probe Penetration
10.3 in (261.62 mm)
Mounting Thread
3/4-14 NPT
Fittings
One 3/4-14 NPT plug
Standoff Adapter
None
Enclosure Rating
CSA Type 4
Installation Guidelines
Ensure the probe lead is longer than the sleeve length during installation.
For sleeve lengths exceeding 304 mm (12 inches), additional mechanical support is required to mitigate vibration-induced fatigue.
Verify that all O-rings and thread seals are properly seated to maintain the environmental seal against moisture and contaminants.
Always power down the associated monitoring system before installing or removing probe assemblies to prevent electrical faults.
Ensure the conduit connection is properly sealed to maintain the explosion-proof integrity of the housing.
FAQWhat is the primary function of the 21000 series housing?The 21000 housing provides essential mechanical and environmental protection for proximity probes, ensuring accurate data collection for radial vibration and axial position monitoring in rotating machinery.Is this housing suitable for hazardous locations?Yes, the 21000 aluminum housing is certified as explosion-proof for hazardous areas (Class I, Div 1 & 2, Groups C and D) and meets CSA Type 4 enclosure requirements.What is required for probe penetrations less than 1.0 inch?For applications requiring a probe penetration of less than 25 mm (1.0 in), a separate 21003-020 individual standoff adapter is typically required.
2 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
9 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
The Bently Nevada 3500/70M 176449-09 is a 4-channel Recip Impulse Velocity Monitor designed for the 3500 series rack-based monitoring system. It is specifically engineered to provide critical protection for reciprocating compressors by monitoring crankcase and crosshead vibration. The module processes inputs from seismic transducers, conditions the signals to derive precise vibration measurements, and evaluates them against user-programmable alarm setpoints.Features
Four-channel monitoring capability for high-density rack configurations.
Supports multiple measurement modes including Impulse Acceleration, Acceleration 2, Recip Velocity, and Low Frequency Recip Velocity.
Programmable Alert and Danger setpoints for active static values.
Fast update rate of less than 100 milliseconds for real-time protection.
Compatible with 3500 series rack infrastructure and configuration software.
Applications
Reciprocating Compressors: Essential for detecting mechanical faults in crankcases and crossheads.
Pipeline Compression: Maintains the operational reliability of large-scale compressor stations.
Oil and Gas Production: Supports monitoring requirements for upstream and downstream gas compression assets.
Chemical and Petrochemical Processing: Provides vibration monitoring for critical rotating and reciprocating equipment.
Technical Specifications
Model
3500/70M 176449-09
Power Consumption
7.7 W (nominal)
Voltage Input
-22 Vdc (minimum)
Output Impedance
550 Ohm (typical)
Load Resistance
600 Ohm (maximum)
Resolution
0.3662 uA (maximum)
Accuracy
+/- 0.05 mA; +/- 0.14 mA over temperature range
Storage Temperature
-40 degC to +85 degC
Humidity
95% non-condensing
Installation Guidelines
Ensure the 3500 rack power is disconnected before installing or removing the module.
The module should be seated firmly into the designated rack slot to ensure proper backplane connection.
Use shielded cabling for all transducer inputs to minimize electromagnetic interference (EMI).
Ensure proper grounding of the 3500 rack chassis to a common instrument ground to maintain signal integrity.
Verify that the module configuration matches the installed transducer type and required alarm setpoints via the 3500 configuration software.
FAQWhat is the primary function of the 3500/70M module?The 3500/70M is a 4-channel monitor designed to process seismic transducer inputs for reciprocating compressor vibration analysis, specifically for crankcase and crosshead monitoring.How does the 3500/70M differ from the 3500/72M?While both are 4-channel rack-based monitors for reciprocating compressors, the 3500/70M is designed for seismic vibration inputs, whereas the 3500/72M is intended for piston rod position and drop monitoring using proximity probes.
9 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
7 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
The Bently Nevada 330881-28-06-155-03-02 is a high-performance ProxPac XL Proximity Transducer Assembly designed for industrial vibration and position monitoring. This self-contained system integrates a 3300 XL 8 mm proximity probe and a 3300 XL Proximitor sensor into a single, robust housing, eliminating the need for external extension cables and separate sensor enclosures.Features
Integrated 3300 XL 8 mm proximity probe and Proximitor sensor system.
Self-contained design simplifies installation and reduces field wiring complexity.
Constructed with AISI 304 stainless steel and durable PPS housing for harsh environments.
Threaded sleeve design allows for precise probe gap adjustment of +/- 12.7 mm.
Compatible with standard 3/4-14 NPT machine case mounting.
Includes M20 fitting and two plugs for versatile connectivity.
Applications
Radial vibration and axial position monitoring for steam and gas turbines.
Predictive maintenance for centrifugal compressors in space-constrained installations.
General machinery protection for pumps, large motors, and fans.
Monitoring in high-heat or harsh industrial environments such as steel and metal mills.
Technical Specifications
Model Number
330881-28-06-155-03-02
Probe Type
3300 XL 8 mm
Standoff Adapter
60 mm
Probe Penetration
155 mm
Mounting Thread
3/4-14 NPT
Housing Material
AISI 304 Stainless Steel / PPS
Weight
1.55 kg
Installation Guidelines
Ensure the assembly is mounted through the machine case using the 3/4-14 NPT thread.
For assemblies where the combined B and C dimensions exceed 305 mm (12.0 in), additional sleeve support is required to prevent resonance.
Maintain a nominal probe tip gap of 1.27 mm (0.050 in) from the target surface during initial setup.
The installation must maintain at least an IP54 protection rating to ensure sensor integrity.
Always power down the monitoring system before performing any wiring changes or maintenance on the transducer assembly.
Handle with care to avoid damage to the probe tip; ensure the assembly is properly grounded according to site safety standards.
FAQWhat is the primary function of the 330881-28-06-155-03-02?This unit is a fully integrated proximity transducer assembly used to measure shaft vibration and position on rotating machinery, combining the probe and sensor into one unit to streamline installation.What is the typical operating gap voltage?For 3300 XL series probes, the normal operating gap voltage is generally maintained between -9 V and -11 V DC.Does this assembly require an external extension cable?No, the ProxPac XL design integrates the Proximitor sensor directly into the housing, removing the need for an extension cable between the probe and the sensor.
7 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
4 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
The Bently Nevada 330881-16-04-138-03-02 is a PROXPAC XL Proximity Transducer system. Unlike traditional proximity systems that utilize separate components, the PROXPAC XL integrates the probe, extension cable, and Proximitor sensor into a single, self-contained unit. This design simplifies installation and reduces the number of connection points in vibration monitoring applications.Features
Integrated system design combining probe, extension cable, and Proximitor sensor
Housing constructed from Polyphenylene Sulfide (PPS), a molded thermoplastic reinforced with glass and conductive fibers for electrostatic dissipation
Rated for Type 4X and IP66 environments, providing protection in severe industrial conditions
8 mm 3300 XL probe technology
Configured with 40 mm standoff adapter and 138 mm probe penetration
Includes one M20 fitting and two plugs
Mounting thread: 3/4-14 NPT
ApplicationsThis transducer is designed for continuous monitoring and protection of critical rotating machinery, including:
Steam and gas turbines in power generation
Large centrifugal, axial, and process gas compressors
Critical boiler feed pumps and high-pressure process pumps
Large electric motors and industrial generators
Heavy-duty industrial gearboxes requiring precise shaft alignment monitoring
Technical Specifications
Model Number
330881-16-04-138-03-02
Probe Type
3300 XL 8 mm
Standoff Adapter
40 mm
Probe Penetration
138 mm
Fittings
One M20 fitting, two plugs
Mounting Thread
3/4-14 NPT
Housing Material
Polyphenylene Sulfide (PPS)
Environmental Rating
Type 4X / IP66
Installation Guidelines
Gapping: For optimal performance, gap the probe at the center of its linear range. For this 8 mm system, the target gap is typically 1.27 mm (50 mils), corresponding to an output of approximately -10 VDC.
Cross-Talk Prevention: Maintain a minimum separation between transducer tips of at least 40 mm (1.6 in) for axial measurements or 38 mm (1.5 in) for radial vibration to prevent signal interference.
Handling: Ensure the system is powered down before performing any wiring or maintenance. Handle with care to avoid damage to the probe tip or cable insulation.
Environment: Ensure the mounting location is free from excessive mechanical shock and that the housing is properly sealed using the provided fittings to maintain the IP66 rating.
FAQWhat is the primary function of the PROXPAC XL?It is designed for real-time, high-precision monitoring of vibration and position in rotating machinery, ensuring safe operation through continuous condition monitoring.What is the working principle of this transducer?The transducer operates on the principle of electromagnetic induction to measure shaft displacement and vibration without physical contact.Is this part still available?The 330881-16-04-138-03-02 may be available for purchase and support even if it has reached End-Of-Life (EOL) status from the original manufacturer.
4 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
7 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
DescriptionThe Bently Nevada 3300/48 Case Expansion Monitor is a rack-mounted module designed to measure the thermal expansion of turbine casings relative to their foundation. This measurement is critical for steam turbines and other large rotating machinery where casing growth can lead to mechanical interference. The monitor continuously compares expansion values against configured alarm setpoints, providing early warning of abnormal conditions to facilitate predictive maintenance.Features
Measures casing expansion relative to the foundation.
Continuous parameter comparison against Alert and Danger alarm setpoints.
Relay actuation for alarm conditions.
LED indicators for OK, Bypass, Alert, and Danger status.
Compatible with proximity probes or LVDT signals.
ApplicationsThis module is primarily utilized in power generation and industrial facilities for monitoring steam turbine thermal growth, ensuring mechanical alignment and preventing casing damage during thermal cycling.Technical Specifications
Model
3300/48-03-02-02-00
Brand
Bently Nevada
Series
3300
Operating Temperature
0 to 60 degC
Power Consumption
~1.5 W
Sensitivity
200 mV/mil or 100 mV/mil
Signal Accuracy
+/- 0.33% typical
Outputs
4-20 mA, 1-5 VDC, 0 to -10 VDC
Installation Guidelines
Ensure the 3300 rack is powered down before inserting or removing the module.
Handle the module using standard ESD precautions to prevent damage to internal circuitry.
Ensure the module is fully seated in the rack slot to maintain proper backplane connection.
Use shielded cabling for transducer inputs to minimize EMI interference.
Verify that the transducer signal type matches the module configuration settings.
FAQWhat is the primary function of the 3300/48 monitor?The module monitors the thermal expansion of turbine casings relative to the foundation, which is essential for preventing mechanical interference in large rotating machinery.Can this module be used with different types of sensors?Yes, the 3300/48-03-02-02-00 is configured to accept inputs from proximity probes or LVDTs, depending on the specific application requirements.What do the alarm setpoints control?The module provides relay outputs for Alert and Danger conditions, which can be integrated into the plant's safety or control systems to trigger alarms or automated shutdowns.
7 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
10 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
The Bently Nevada TK-3E 177313-02-02-00 is a motorized, portable proximity system test kit designed to simulate shaft vibration and position for the calibration and verification of Bently Nevada eddy current proximity transducer systems. This kit ensures that transducer inputs and monitor readouts remain accurate, supporting critical machinery condition monitoring.Features
Electric-driven calibration system for proximity transducers
Simulates shaft vibration and axial/radial displacement
Precision spindle micrometer assembly for controlled probe positioning
Universal probe mount accommodating diameters from 5 mm to 19 mm
Integrated target wheel assembly with AISI 4140 alloy steel target
Rugged, foam-lined carrying case for field and laboratory use
Applications
Power Generation: Calibration of vibration monitoring loops in thermal, hydroelectric, and nuclear plants
Oil, Gas, & Petrochemicals: Verification of proximity sensors in refineries and offshore processing facilities
Rotating Equipment: Routine maintenance and commissioning for centrifugal compressors, steam turbines, and large industrial fans
Machinery Protection: Checking thrust position drift and radial vibration linearity to prevent rotor-to-stator contact
Technical Specifications
Model
TK-3E 177313-02-02-00
Vibration Amplitude Range
50 um to 254 um (2 to 10 mils) peak-to-peak
Spindle Micrometer Range
0 to 25.4 mm (0 to 1000 mils)
Operating Temperature
0 degC to 50 degC (32 degF to 122 degF)
Storage Temperature
-18 degC to 65 degC (0 degF to 150 degF)
Humidity
95% Non-Condensing
Power Supply
115/230 VAC, 50/60 Hz
Target Material
AISI 4140 Alloy Steel
Installation Guidelines
Ensure the test kit is placed on a stable, level surface. The base includes vibration isolation feet to minimize external interference.
Verify the power supply voltage setting (115V or 230V) matches the local power source before connecting.
When mounting the proximity probe, ensure it is securely held in the universal mount without over-tightening the clamp.
Connect the Proximitor sensor to the probe using the appropriate extension cable and provide the required -24 VDC power to the sensor.
Use a digital multimeter to monitor the gap voltage while adjusting the micrometer in calibrated increments to verify the Incremental Scale Factor (ISF).
Always power down the test kit and disconnect from the power source before performing maintenance or cleaning.
FAQWhat is the TK-3E 177313-02-02-00?The Bently Nevada TK-3E 177313-02-02-00 is an electrically driven proximity system test kit used to calibrate vibration monitors and verify the operational condition of proximity transducer systems.Do I need an oscilloscope to use the TK-3E?No, an oscilloscope is not required. You can use a standard digital multimeter to read the gap voltage and evaluate the vibration signal.What is the power requirement for this kit?The unit operates on 95–125 Vac or 190–250 Vac, 50/60 Hz.What are the environmental limits?It is rated for indoor use up to an altitude of 2000 meters. The operational temperature range is 0 degC to 50 degC in up to 95% non-condensing humidity.
10 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
2 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
DescriptionThe Bently Nevada 330180-X1-00 (MOD: 145004-81) is a Proximitor sensor designed for use within the 3300 XL proximity transducer system. This sensor is engineered to provide precise, non-contact measurement of shaft position and vibration in rotating machinery. It serves as a critical component in condition monitoring, converting the gap between the probe tip and the observed surface into a proportional voltage signal for analysis by monitoring systems.Features
Compatible with 3300 XL series proximity transducer systems.
Designed for DIN-rail mounting configurations.
Provides high-accuracy signal conditioning for vibration and position monitoring.
Robust construction suitable for industrial environments.
Technical Specifications
Product Model
330180-X1-00 MOD:145004-81
Device Type
Proximitor Sensor
Manufacturer
Bently Nevada
Weight
0.22 kg
Tariff Code
8537101190
Installation Guidelines
Ensure the Proximitor sensor is installed in a protected, dry environment, typically within an instrumentation cabinet.
Use appropriate DIN-rail mounting hardware to secure the module.
Maintain proper shielding for all signal cables to minimize EMI/RFI interference.
Verify that the system length (probe, extension cable, and sensor) matches the calibrated configuration (e.g., 5.0m or 9.0m) to ensure measurement accuracy.
Always power down the monitoring system before connecting or disconnecting the sensor to prevent electrical damage.
FAQWhat is the primary function of the 330180 Proximitor sensor?The Proximitor sensor is the signal conditioning unit of the proximity transducer system. It receives an RF signal from the probe, processes it, and outputs a voltage signal proportional to the distance between the probe tip and the target surface.Is this sensor compatible with all Bently Nevada systems?This model is specifically part of the 3300 XL series. It is recommended to verify compatibility with your existing probe and extension cable lengths before installation.
2 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
5 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
DescriptionThe Bently Nevada 3500/91-01-02-02 EGD Communication Gateway Module is a critical component of the 3500 Series Machinery Protection System. It is engineered to facilitate high-speed, real-time data exchange between the 3500 rack and external plant control systems, such as GE Mark VIe controllers, using the Ethernet Global Data (EGD) protocol. This module ensures robust connectivity for machinery diagnostics, protection data, and integration with System 1 software.Features
Provides Ethernet Global Data (EGD) protocol integration for real-time communication.
Equipped with an Ethernet 100BASE-FX fiber optic interface for superior noise immunity and long-distance data transmission.
Supports seamless data exchange for predictive maintenance and transient data analysis.
Front panel LED indicators for quick status monitoring: OK, TX/RX, and Bypass.
Designed for integration into the standard 3500 rack communication slot.
ApplicationsThis communication gateway is primarily used in critical turbomachinery protection applications, including steam and gas turbines, centrifugal compressors, and large pumps, where high-speed data integration with plant-wide control systems is required.Technical Specifications
Manufacturer
Bently Nevada
Product Number
3500/91-01-02-02
Module Type
EGD Communication Gateway
I/O Module Type
Ethernet 100BASE-FX Fiber Optic
Agency Approval
CE/PCCC
Operating Temperature
-30 degC to +65 degC
Storage Temperature
-40 degC to +85 degC
Humidity
95% non-condensing
Installation Guidelines
Ensure the 3500 rack is powered down before inserting or removing the module to prevent electrical damage.
The module must be installed in the designated communication slot of the 3500 rack, paired with the corresponding rear I/O module.
Handle with care using ESD-safe procedures to protect sensitive internal components.
Ensure fiber optic cables are routed away from high-EMI sources and are not subjected to excessive bending radii.
Verify that the module is fully seated and the front panel screws are tightened to ensure proper grounding and mechanical stability.
FAQWhat is the primary function of the 3500/91 module?The module serves as a gateway to allow the 3500 Machinery Protection System to communicate with external control systems using the EGD protocol over a fiber optic network.Does this module support standard copper Ethernet?No, this specific order code (3500/91-01-02-02) is configured for 100BASE-FX fiber optic connectivity.
5 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
4 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
DescriptionThe Bently Nevada 3300/16 XY/Gap Dual Vibration Monitor is a specialized rack-mounted module designed for the 3300 Monitoring System. It provides simultaneous measurement of radial shaft vibration and probe gap voltage. By continuously monitoring these parameters against user-defined alarm setpoints, the module provides critical protection for rotating machinery, including industrial turbines, centrifugal compressors, and large pumps. This unit supports predictive maintenance strategies by delivering reliable, high-resolution displacement and vibration data to the control system.Features
Dual-channel monitoring capability for XY vibration and gap voltage.
Continuous signal processing with integrated Alert and Danger alarm logic.
Compatible with standard Bently Nevada proximity probe and Proximitor sensor systems.
Front-panel LED status indicators for OK, Bypass, Alert, and Danger conditions.
Configurable output options including 4-20 mA, 1-5 VDC, and 0 to -10 VDC signals.
Designed for seamless integration into existing 3300 series rack environments.
Applications
Radial shaft vibration monitoring for fluid-film bearing machines.
Proximity probe gap voltage monitoring for machine health diagnostics.
Critical asset protection in petrochemical, power generation, and oil and gas facilities.
Integration with DCS or PLC systems for automated machinery shutdown and data logging.
Technical Specifications
Model
3300/16-13-01-01-00-00-00
Brand
Bently Nevada
Series
3300
Operating Temperature
0 to 60 deg C
Power Consumption
~1.5 W
Input Compatibility
Proximity probes with Proximitor sensors
Sensitivity
200 mV/mil (8 V/mm) or 100 mV/mil (4 V/mm)
Signal Accuracy
±0.33% typical, ±1% max at 25 deg C
Output Signals
4-20 mA, 1-5 VDC, 0 to -10 VDC
Installation Guidelines
Ensure the 3300 rack is powered down before inserting or removing the monitor module to prevent electrical damage.
The module must be installed in a clean, dry environment within the specified temperature range.
Use shielded twisted-pair cabling for all transducer inputs to minimize EMI/RFI interference.
Ensure proper grounding of the 3300 rack system per Bently Nevada installation manuals to maintain signal integrity.
Verify that all field wiring is correctly terminated at the rack backplane before applying power.
Confirm that the configuration switches/jumpers match the specific transducer and range requirements for the application.
FAQWhat is the primary function of the 3300/16 monitor?The 3300/16 is designed to monitor radial shaft vibration and probe gap voltage simultaneously, providing essential data for machinery protection and condition monitoring.Is this module compatible with existing 3300 series racks?Yes, this module is specifically engineered for the 3300 rack system and is fully compatible with standard 3300 backplanes.What do the status LEDs on the front panel indicate?The LEDs provide visual confirmation of the module's operational status, including OK (system health), Bypass (maintenance mode), and Alert/Danger (alarm thresholds exceeded).
4 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
7 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
DescriptionThe Bently Nevada 21000-00-00-00-000-00-02 is an aluminum proximity probe housing assembly designed for the external mounting of proximity probes on industrial rotating machinery. This unit provides a robust, environmentally sealed enclosure that protects the proximity probe and its electrical connections, while enabling precise positioning of the probe tip relative to the target surface for accurate vibration and position monitoring.This specific model is a base housing unit configured without an integrated probe, sleeve, or conduit fittings. It serves as a mechanical foundation for 3300 XL 8 mm proximity probes, allowing for field-customized installations. The assembly includes the aluminum housing body, a dome cover, O-rings, and a thread seal, with a 3/4-14 NPT mounting thread.Features
Aluminum construction for durability in industrial environments.
Provides environmental protection for proximity probes and cable connections.
Allows for external probe adjustment and maintenance without machine disassembly.
Includes a dome cover for secure, sealed access to internal components.
Compatible with standard 3/4-14 NPT conduit connections.
Supports precise probe penetration adjustment within a 13 mm range.
Applications
Oil and Gas Refineries: Protecting vibration monitoring sensors on compressors, pumps, and turbines.
Power Generation: Safeguarding turbine-generator shaft sensors in hydro, fossil, and nuclear plants.
Petrochemical Facilities: Shielding probes from volatile or corrosive atmospheres.
Heavy Manufacturing: Supporting fluid-film bearing machine monitoring in continuous-operation environments.
Technical Specifications
Model
21000-00-00-00-000-00-02
Material
Aluminum
Mounting Thread
3/4-14 NPT
Adjustment Range
13 mm (±0.5 in)
Weight
0.8 kg
Included Components
Housing body, dome cover, O-rings, thread seal
Installation Guidelines
Ensure the mounting surface is clean and flat to maintain the integrity of the housing seal.
Route field wiring through the designated 3/4-14 NPT threaded ports.
Use appropriate cable seal grips or conduit fittings to maintain the weatherproof and explosion-proof rating of the assembly.
Tighten the dome cover securely using the captive screws to ensure the internal environment remains sealed.
For probe penetration lengths exceeding 300 mm (12 inches), install additional sleeve support to prevent resonance.
Always verify the probe-to-target gap during commissioning using the 13 mm adjustment range.
FAQWhat is the primary function of the 21000-00-00-00-000-00-02?This assembly acts as a protective, adjustable housing for proximity probes, allowing for the monitoring of machine vibration and position while protecting the transducer system from environmental hazards.Is this housing compatible with all Bently Nevada probes?It is designed primarily for use with Bently Nevada 3300, 3300 XL, and 7200 series proximity transducer systems. Please consult your specific probe datasheet to ensure mechanical compatibility.Does this unit include conduit fittings?No, this specific model (-00 in the fitting position) is supplied as a base housing without pre-installed conduit fittings or probes.
7 dalam stok
Pengiriman dalam waktu 48 jam, bayar setelahnya
Pertengahan minggu Senin sampai Jumat kami menawarkan pengiriman hari berikutnya jika produk tersedia dan pengecualian pada hari libur.
Akhir pekan Kami tidak menawarkan pengiriman di akhir pekan.
Internasional Tergantung lokasi Anda, kami menawarkan pengiriman keesokan harinya. Periksa status pengiriman Anda di tautan ini.
