Sensor dan probe menyediakan pemantauan yang akurat untuk peralatan industri. Produk kami mencakup probe getaran, jarak, dan perpindahan dari produsen terkemuka. Kami menyediakan model yang masih ada maupun yang sudah dihentikan produksinya dengan dukungan global yang tepercaya.
Sensor dan Probe
-
Bently Nevada Bently Nevada 330901-00-40-10-02-05 3300 XL NSv Proximity Probe
Bently Nevada 330901-00-40-10-02-05 3300 XL NSv Proximity Probe The Bently Nevada 330901-00-40-10-02-05, also cataloged as the 330901-00-40-10-02-05 3300 XL NSv Proximity Probe, operates as a dedicated eddy-current sensing component for shaft vibration, axial position, speed, and phase reference measurement within the 3300 XL NSv Proximity Transducer System. Hardware Specifications Parameter Specification Model 330901-00-40-10-02-05 Brand Bently Nevada Product Type 3300 XL NSv Proximity Probe Origin USA Weight 0.05 kg Dimensions Estimated shipping size: 1.2 x 1 x 117 cm Power Consumption Supplied by compatible 3300 XL NSv Proximitor Sensor Thread Type 1/4-28 UNF Armor Type Without armor Unthreaded Length Option 0.0 in Overall Case Length Option 4.0 in Total Length Option 1.0 meter (39 in) Connector Type Miniature coaxial ClickLoc connector standard cable Agency Approval Multiple Approvals Average Scale Factor 7.87 V/mm (200 mV/mil) Linear Range 1.5 mm (60 mils) Eddy-Current Probe Scaling and Rotor Dynamics Characteristics The 330901-00-40-10-02-05 uses eddy-current measurement technology to convert shaft displacement into proportional electrical signals. The probe provides an average scale factor of 7.87 V/mm (200 mV/mil), allowing the connected 3300 XL NSv Proximitor Sensor to process dynamic vibration and position signals. Furthermore, the probe design supports rotor dynamics monitoring by measuring radial vibration, radial position, axial thrust position, tachometer signals, zero speed conditions, and Keyphasor phase reference signals. The narrow side-view structure reduces installation limitations where standard 3300 and 3300 XL 5 mm or 8 mm transducer systems cannot fit. The probe also supports gap voltage validation through the standard eddy-current transducer measurement method. Proper gap voltage adjustment enables accurate target detection and stable displacement measurement. Frequently Asked Questions Q: What type of target applications does the 330901-00-40-10-02-05 support?A: The probe supports small target measurements, including radial vibration monitoring on shafts smaller than 51 mm (2 in) and axial position measurement on flat targets smaller than 15 mm (0.6 in). Q: Can the 330901-00-40-10-02-05 replace older 3300 RAM or 3000-series systems?A: The 3300 XL NSv Transducer System can replace 3300 RAM and 3000-series or 7000-series 190 Transducer Systems. However, system upgrades may require replacement of the probe, extension cable, and Proximitor Sensor depending on the existing configuration. Q: What installation condition requires the NSv probe design?A: The NSv probe design fits applications with counter bore, side-view, or rear-view restrictions that prevent installation of standard proximity transducer systems. Field Installation Guidelines Install the 330901-00-40-10-02-05 probe according to the mechanical clearance requirements of the monitored machine. Verify that the 1/4-28 UNF threaded mounting location provides correct probe alignment with the shaft or target surface. Route the miniature coaxial cable away from high-current power wiring, ignition sources, and strong electromagnetic interference areas. Maintain proper cable support to prevent mechanical stress on the ClickLoc connector. Before operation, adjust the probe gap according to the connected 3300 XL NSv Proximitor Sensor requirements. Confirm the gap voltage output and verify the target surface condition before collecting vibration or position data. For TSI applications, verify probe orientation, target geometry, and signal polarity before commissioning rotor vibration, axial position, or Keyphasor measurement channels.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330902-00-40-10-02-00 3300 NSv Proximity Probe
Bently Nevada 330902-00-40-10-02-00 3300 NSv Proximity Probe The Bently Nevada 330902-00-40-10-02-00, also cataloged as the 330902 3300 NSv Proximity Probe, operates as a dedicated eddy-current sensing component for shaft displacement measurement within Bently Nevada TSI monitoring systems. The probe uses a 1/4-28 UNF threaded body with armor protection and a 1.0 meter cable assembly for vibration and position monitoring circuits. Hardware Specifications Parameter Specification Model 330902-00-40-10-02-00 Brand Bently Nevada Product Series 3300 NSv Proximity Probe Product Type Eddy-current Proximity Sensor Origin USA Weight 0.06 kg Dimensions Estimated shipping size: 62 x 1 x 1 cm Power Consumption Supplied through compatible Bently Nevada proximity system Thread Type 1/4-28 UNF thread Armor Option Armored probe construction Unthreaded Length Option 0.0 in Overall Case Length Option 4.0 in Total Length Option 1.0 meter (39 in) Connector Type Miniature coaxial ClickLoc connector Cable Type Standard cable Eddy-Current Probe Scaling and Gap Voltage Characteristics The 330902-00-40-10-02-00 uses eddy-current probe scaling principles to convert shaft displacement into proportional electrical signals. The connected proximity transducer system measures the probe gap voltage and provides dynamic vibration or position data for TSI monitoring. The probe installation requires correct mechanical positioning to maintain the designed sensing range. Additionally, Bently Nevada proximity systems commonly validate probe operation through gap voltage monitoring, including typical -10 VDC target validation during setup procedures. The probe supports rotor dynamics analysis by providing non-contact shaft motion feedback. Therefore, engineers can evaluate vibration behavior, axial movement, and mechanical clearance conditions through the connected monitoring hardware. Frequently Asked Questions Q: What type of measurement does the 330902-00-40-10-02-00 provide?A: The probe provides non-contact displacement measurement through an eddy-current sensing principle. It detects shaft position changes and dynamic movement when connected to a compatible Bently Nevada proximity system. Q: Does this model include an armored cable construction?A: Yes. The 330902-00-40-10-02-00 configuration includes an armored probe design with a miniature coaxial ClickLoc connector and standard cable. Q: What installation factors affect probe signal accuracy?A: Mechanical alignment, target surface condition, cable routing, and proper shielding practices affect signal quality. Installers should avoid routing the probe cable near high-current power cables to reduce electrical interference. Field Installation Guidelines Install the probe into the 1/4-28 UNF mounting location and verify mechanical engagement before system operation. Maintain correct probe-to-target clearance according to the connected Bently Nevada monitoring system requirements. Route the miniature coaxial cable separately from high-voltage power conductors and switching circuits. Connect the cable shield according to the monitoring system grounding instructions to minimize electrical noise. Verify the probe output signal and gap voltage condition during commissioning before enabling vibration or position monitoring functions.
$200.00 $100.00
-
Bently Nevada 330903-00-06-10-02-05 Bently Nevada 3300 NSv Proximity Probe
Bently Nevada 330903-00-06-10-02-05 3300 NSv Proximity Probe The Bently Nevada 330903-00-06-10-02-05, also cataloged as the 330903 3300 NSv Proximity Probe, operates as a dedicated hardware component for eddy-current shaft displacement measurement within Bently Nevada machinery monitoring systems. Hardware Specifications Parameter Specification Model 330903-00-06-10-02-05 Brand Bently Nevada Product Type 3300 NSv Proximity Probe Origin USA Weight 0.32 kg Dimensions 20.5 x 22.5 x 3 cm shipping size Thread Type M8 x 1 metric thread Probe Design Unarmored proximity probe Unthreaded Length 0 mm Overall Case Length 60 mm Total Length 1.0 meter (39 in) Connector Type Miniature coaxial ClickLoc connector Cable Type Standard cable Agency Approval Multiple approvals Measurement Principle Eddy-current displacement sensing Power Consumption Supplied through compatible proximity sensor system Eddy-Current Probe Scaling and Rotor Dynamics Monitoring The Bently Nevada 330903-00-06-10-02-05 uses eddy-current probe scaling principles to convert shaft displacement changes into electrical signals for machinery condition monitoring. Therefore, the probe provides proportional measurement output when paired with compatible proximitor electronics. The probe structure supports rotor dynamics analysis by measuring radial shaft movement, vibration displacement, and mechanical position changes. In addition, the M8 x 1 threaded body allows installation in compact machinery monitoring locations where mounting space is limited. The system verifies probe operating conditions through gap voltage validation. Furthermore, Bently Nevada proximity measurement systems typically use -10 VDC target gap voltage references to confirm correct probe positioning and signal response. Frequently Asked Questions Q: What measurement technology does the 330903-00-06-10-02-05 use?A: The probe uses eddy-current sensing technology to measure shaft displacement without physical contact between the probe tip and rotating target. Q: What connector configuration does this model include?A: This model includes a miniature coaxial ClickLoc connector with a standard cable configuration. Q: Can this probe directly connect to a monitoring system input?A: No. The probe requires compatible Bently Nevada proximitor electronics to provide signal conditioning and displacement measurement output. Field Installation Guidelines Install the probe using the specified M8 x 1 mounting thread and maintain proper mechanical alignment with the shaft target surface. Keep the probe cable away from high-current power conductors to reduce electrical interference. Connect cable shielding according to the monitoring system grounding requirements. Verify probe gap voltage after installation to confirm correct target distance and measurement range. Avoid excessive cable bending near the miniature coaxial ClickLoc connector to maintain signal integrity. Confirm the probe tip remains free from mechanical contact during shaft rotation.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330903-00-21-10-02-05 3300 XL NSv Proximity Probe
Bently Nevada 330903-00-21-10-02-05 3300 XL NSv Proximity Probe The Bently Nevada 330903-00-21-10-02-05, also cataloged as the 330903 3300 XL NSv Proximity Probe, operates as a dedicated hardware component for eddy current displacement measurement within Bently Nevada TSI monitoring systems. The probe measures shaft position and dynamic vibration by converting gap distance changes into electrical signals. Hardware Specifications Parameter Specification Model 330903-00-21-10-02-05 Brand Bently Nevada Series 3300 XL NSv Proximity Probe Product Type Eddy Current Proximity Sensor Origin USA Dimensions Case length: 210 mm; Total cable length: 1.0 m Operating Temp Probe: -51 deg C to +177 deg C Power Consumption Powered by compatible Proximitor Sensor; value not specified Thread Type M8 x 1 metric thread Armor Type Unarmored Unthreaded Length 0 mm Linear Range 1.5 mm (60 mils) Typical Gap Range 0.25 mm to 1.75 mm (10 to 70 mils) Average Scale Factor 7.87 V/mm (200 mV/mil) nominal Target Material AISI 4140 steel Minimum Target Diameter 8.9 mm; 13 mm recommended Connector Type Miniature coaxial ClickLoc connector Connector Material Gold-plated brass Probe Tip Material PPS molded probe tip Agency Approval CSA, ATEX, IECEx Eddy Current Probe Scaling and Gap Voltage Validation The 330903-00-21-10-02-05 uses eddy current measurement technology to determine the distance between the probe tip and the conductive shaft target. The probe output changes according to shaft displacement, allowing the connected Proximitor Sensor to calculate vibration and position values. In addition, the system uses gap voltage validation to confirm probe operating conditions. During commissioning, technicians verify the electrical gap signal to maintain correct measurement range, with Bently Nevada proximity systems commonly using -10 VDC as the target reference for nominal operating gap conditions. The 3300 XL NSv design also applies cross-talk suppression techniques to reduce interference when multiple probes operate within limited installation areas. Therefore, the probe supports stable rotor dynamics monitoring in applications with restricted mounting space. Frequently Asked Questions Q: What measurement principle does the Bently Nevada 330903-00-21-10-02-05 use?A: The probe uses an eddy current sensing principle to measure the distance between the probe tip and a conductive shaft target. The measured displacement is converted into an electrical output signal by the Proximitor Sensor. Q: Can the 330903-00-21-10-02-05 be installed in small clearance locations?A: Yes. The 3300 XL NSv series uses a compact M8 x 1 threaded design for applications requiring limited mounting space and smaller shaft targets. Q: What target material is specified for calibration?A: The standard calibration target material is AISI 4140 steel. Other target materials may require system calibration adjustments. Field Installation Guidelines Install the probe with correct M8 x 1 thread engagement and ensure the sensing tip faces the measurement target without mechanical contact. Maintain proper cable routing to prevent signal interference from high-current power conductors and switching equipment. Connect the miniature coaxial ClickLoc connector securely to maintain signal integrity. Verify probe gap voltage during commissioning to confirm the sensing position before vibration monitoring. Use appropriate shielding and grounding practices according to the connected Bently Nevada monitoring system installation requirements. Avoid excessive bending stress on the cable near the probe body and connector area.
$200.00 $100.00
-
Bently Nevada 330904-04-14-05-02-00 | 3300 XL NSv Proximity Probe | Bently Nevada
Bently Nevada 330904-04-14-05-02-00 3300 XL NSv Proximity Probe The Bently Nevada 330904-04-14-05-02-00, also cataloged as the 330904 3300 XL NSv Proximity Probe, operates as a dedicated hardware component for non-contact shaft displacement measurement and vibration monitoring within Bently Nevada TSI monitoring systems. Hardware Specifications Parameter Specification Model 330904-04-14-05-02-00 Brand Bently Nevada Product Type Proximity Sensors Series 3300 XL NSv Proximity Probe Origin USA Dimensions 40 mm unthreaded length, 140 mm overall case length, 0.5 m cable length Operating Temp -52 deg C to +177 deg C Power Consumption Supplied by compatible Bently Nevada Proximitor sensor system Linear Range 1.5 mm (60 mils) Average Scale Factor 7.87 V/mm (200 mV/mil) Linearity Deviation Less than or equal to +/- 0.06 mm (+/- 2.3 mils) from best fit straight line Frequency Response 0 Hz to 10 kHz (+0, -3 dB) Probe Tip Material Polyphenylene sulfide (PPS) Probe Body Material 300 series stainless steel Cable Type 75 ohm coaxial cable with FEP insulation Connector Type Miniature coaxial ClickLoc connector Target Diameter Requirement Minimum 8.9 mm (0.35 inch) flat target Eddy-Current Scaling and Rotor Dynamics Measurement The 3300 XL NSv proximity probe uses eddy-current technology to convert shaft movement into proportional electrical signals. The probe maintains a defined scale factor of 7.87 V/mm, which allows the connected Proximitor sensor to calculate shaft displacement and vibration values. Additionally, the NSv probe design supports rotor dynamics analysis by providing stable gap voltage behavior and repeatable displacement output. The measurement chain validates the probe operating gap through the negative DC gap voltage range, including standard Bently Nevada -10 VDC target conditions for proper probe calibration. The narrow side-view construction reduces installation interference in applications with restricted mounting space. Furthermore, the probe supports vibration monitoring, radial position measurement, Keyphasor reference signals, and zero-speed detection functions when integrated with compatible monitoring hardware. Frequently Asked Questions Q: Can the 330904-04-14-05-02-00 probe operate without a compatible Proximitor sensor?A: No. The probe requires a compatible Bently Nevada Proximitor sensor to provide excitation, signal conditioning, and displacement output conversion. Q: What installation factors affect measurement accuracy?A: Proper probe gap adjustment, target surface condition, cable routing, and electromagnetic noise control affect the accuracy of eddy-current measurement. Q: Does the NSv probe require recalibration when replacing another 3300 XL NSv component?A: The 3300 XL NSv probe maintains interchangeability with compatible 3300 XL NSv system components when installed according to Bently Nevada configuration requirements. Field Installation Guidelines Install the probe perpendicular to the monitored shaft target surface to maintain correct eddy-current measurement geometry. Adjust the probe gap according to the connected Proximitor sensor calibration requirements and verify the operating gap voltage. Route the coaxial cable away from high-current power cables and strong electromagnetic interference sources. Maintain proper cable shielding practices and connect grounding according to the monitoring system installation manual. Inspect the target surface condition before commissioning because scratches, uneven surfaces, or contamination can influence displacement measurement. Secure the ClickLoc connector connection to prevent signal interruption caused by mechanical vibration.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330904-08-15-10-02-05 3300 XL NSv Proximity Probe
Bently Nevada 330904-08-15-10-02-05 3300 XL NSv Proximity Probe The Bently Nevada 330904-08-15-10-02-05, also cataloged as the 330904 3300 XL NSv Proximity Probe, operates as a dedicated hardware component for non-contact shaft displacement measurement within Bently Nevada machinery monitoring systems. Hardware Specifications Parameter Specification Model 330904-08-15-10-02-05 Brand Bently Nevada Product Type 3300 XL NSv Proximity Probe Origin USA Weight 0.2 kg Dimensions Estimated shipping size: 1.5 x 1.3 x 116 cm Thread Type M8 x 1 thread Armor Option Armored probe design Unthreaded Length 80 mm Overall Case Length 150 mm Total Length 1.0 meter (39 in) Connector Type Miniature coaxial ClickLoc connector Cable Type Standard cable Agency Approval Multiple approvals Tariff Code 8537101190 Eddy-Current Measurement and Rotor Dynamics The 330904-08-15-10-02-05 uses eddy-current probe scaling principles to convert shaft position changes into electrical displacement signals. Therefore, the probe provides non-contact measurement for machinery vibration and position monitoring applications. The probe design supports gap voltage validation procedures, where technicians typically verify probe operating conditions around the -10 VDC target range for correct displacement measurement. In addition, the 3300 XL NSv series supports rotor dynamics analysis by providing consistent shaft motion data for vibration monitoring channels. The miniature coaxial ClickLoc connector maintains signal connection integrity between the probe and extension cable assembly. Furthermore, the armored construction improves mechanical protection in installations that require additional cable resistance against physical stress. Frequently Asked Questions Q: What measurement principle does the 330904-08-15-10-02-05 probe use?A: The probe uses eddy-current sensing technology to measure shaft displacement without physical contact with the rotating target. Q: What is the thread specification of this probe model?A: The probe uses an M8 x 1 thread configuration with an armored construction option. Q: What connector type is installed on this probe?A: The probe uses a miniature coaxial ClickLoc connector with a standard cable assembly. Field Installation Guidelines Install the probe with the specified M8 x 1 mounting interface and maintain correct mechanical alignment with the target shaft surface. Verify probe gap voltage during commissioning to confirm proper operating range and signal output condition. Route the coaxial cable away from high-current power conductors to reduce electrical interference. Connect cable shielding according to the machinery monitoring system grounding requirements. Avoid sharp cable bends and excessive mechanical stress near the miniature coaxial ClickLoc connector. Confirm probe clearance, mounting rigidity, and target surface condition before final operation.
$200.00 $100.00
-
Bently Nevada 330905-00-08-10-02-00 | Bently Nevada | 3300 NSv Proximity Probe
Bently Nevada 330905-00-08-10-02-00 3300 NSv Proximity Probe The Bently Nevada 330905-00-08-10-02-00, also cataloged as the 330905 Proximity Probe, operates as a dedicated hardware component for shaft displacement and vibration signal measurement within the 3300 NSv Eddy Current Transducer System. Hardware Specifications Parameter Specification Model 330905-00-08-10-02-00 Brand Bently Nevada Product Type 3300 NSv Eddy Current Proximity Probe System Series 3300 NSv Proximity Transducer System Origin USA Weight 0.05 kg Dimensions Estimated shipping size: 1.6 x 1.4 x 119 cm Probe Configuration M10 x 1 metric thread, without armor Probe Case Thread M10 x 1, 15 mm Metric Thread Configuration 80 mm Total Length 1.0 meter (39 in) Cable Type Miniature coaxial ClickLoc connector standard cable Connector Option ClickLoc miniature coaxial connector Probe Tip Diameter 5 mm (0.20 in) Probe Body Diameter 5.8 mm (0.23 in) Linear Range 80 mil (2 mm) Average Scale Factor 7.87 V/mm (200 mV/mil) Eddy-Current Probe Scaling and Rotor Dynamics The Bently Nevada 330905-00-08-10-02-00 uses eddy-current probe scaling to convert shaft displacement into proportional electrical output signals. The probe provides an average scale factor of 7.87 V/mm (200 mV/mil), which allows the 3300 NSv system to process radial vibration, radial position, axial position, tachometer, and phase reference measurements. Furthermore, the probe design supports rotor dynamics monitoring on fluid-film bearing machinery. The compact 5 mm probe tip allows installation in restricted counterbore, side-view, and rear-view locations where standard 3300 and 3300 XL 5 mm or 8 mm probes cannot be installed. The system maintains gap voltage measurement principles used in Bently Nevada eddy-current monitoring technology. During installation, technicians validate the probe gap voltage condition against the typical -10 VDC target range to confirm correct probe positioning and signal operation. Frequently Asked Questions Q: What mechanical interfaces does the 330905-00-08-10-02-00 probe support?A: The probe uses an M10 x 1 metric thread with a 15 mm probe case thread length. It provides an 80 mm metric thread configuration for compact installation locations. Q: Can this probe replace standard 3300 XL 8 mm probes?A: The 3300 NSv probe provides the same 80 mil (2 mm) linear measurement range as the standard 3300 XL 8 mm system, but it uses a smaller probe body for restricted installation areas. Q: What measurements can the probe perform in a monitoring system?A: The probe supports radial vibration, radial position, axial thrust position, tachometer, zero speed, and Keyphasor phase reference measurements when connected to compatible Bently Nevada monitoring hardware. Field Installation Guidelines Install the probe with the specified M10 x 1 mounting thread and maintain proper mechanical alignment with the target shaft surface. Verify probe gap voltage after mechanical installation before placing the monitoring channel into service. Route the miniature coaxial cable away from high-current power conductors to reduce electrical interference. Maintain proper cable shielding practices and connect the shield according to the monitoring system grounding requirements. Avoid excessive cable bending near the ClickLoc connector to prevent mechanical stress on the coaxial connection. Confirm the probe target material and surface condition meet eddy-current measurement requirements before calibration.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330905-00-05-10-02-00 3300 XL NSv Proximity Probe
Bently Nevada 330905-00-05-10-02-00 3300 XL NSv Proximity Probe The Bently Nevada 330905-00-05-10-02-00, also cataloged as the 330905 3300 XL NSv Proximity Probe, operates as a dedicated hardware component for non-contact shaft displacement and vibration measurement within Bently Nevada TSI monitoring systems. Hardware Specifications Parameter Specification Model 330905-00-05-10-02-00 Brand Bently Nevada Product Type 3300 XL NSv Proximity Probe Origin USA Dimensions M10 x 1 threaded probe, 50 mm case length, 1.0 m total cable length Operating Temp -51 deg C to +177 deg C Power Consumption Supplied by compatible Proximitor sensor; probe is passive eddy-current sensing element Thread Size M10 x 1.0 metric fine thread Armor Configuration Without armor Unthreaded Length 0 mm Connector Type Miniature coaxial ClickLoc connector Cable Type Standard miniature coaxial cable Average Scale Factor 7.87 V/mm (200 mV/mil) nominal Linear Range 1.5 mm (60 mils) nominal Target Material AISI 4140 steel calibration target Frequency Response 0 Hz to 10 kHz (-3 dB) Probe Tip Material Polyphenylene sulfide (PPS) Probe Case Material AISI 303 or 304 stainless steel Minimum Cable Bend Radius 25.4 mm Eddy-Current Measurement and Rotor Dynamics Features The 3300 XL NSv proximity probe applies eddy-current sensing technology to convert shaft position changes into electrical displacement signals. Therefore, the connected Proximitor sensor can process gap voltage variations and vibration movement data for machinery protection and condition monitoring. The probe provides a nominal scale factor of 7.87 V/mm, which supports consistent displacement measurement across the specified linear range. In addition, the system uses gap voltage validation with typical -10 VDC target conditions to confirm probe operating position and measurement accuracy. Furthermore, the compact NSv mechanical structure supports rotor dynamics monitoring where installation clearance limits restrict conventional probe mounting. The narrow side-view design reduces physical interference near small-diameter shafts, counterbores, and restricted bearing housings. The miniature coaxial ClickLoc connector uses a locking mechanism to maintain electrical connection under mechanical vibration. Meanwhile, the TipLoc molding and CableLoc design increase the mechanical connection strength between the probe tip, body, and cable assembly. Frequently Asked Questions Q: What measurement principle does the 330905-00-05-10-02-00 use?A: The probe uses eddy-current sensing technology and requires a compatible Proximitor sensor to convert shaft displacement into vibration and position signals. Q: What is the function of the M10 x 1 thread configuration?A: The M10 x 1 metric thread allows installation in compact machinery locations where standard larger proximity probes cannot fit. Q: Can the probe operate independently without a Proximitor sensor?A: No. The probe functions as the sensing element and requires a compatible Bently Nevada Proximitor interface for signal conditioning and output processing. Field Installation Guidelines Install the probe with the sensing tip aligned toward the monitored shaft surface according to the machinery manufacturer installation drawing. Maintain proper probe-to-target positioning to achieve the required gap voltage range before system commissioning. Verify the electrical output through the connected Proximitor sensor and confirm the expected gap voltage condition. Route the miniature coaxial cable away from high-current power conductors and strong electromagnetic interference sources. Use proper cable support to prevent excessive bending stress near the connector and probe body. Ensure the M10 x 1 threaded section is mechanically secured without applying excessive torque that may damage the probe housing. Grounding and shielding practices should follow the applicable Bently Nevada monitoring system installation requirements.
$200.00 $100.00
-
Bently Nevada 3300 NSv Proximity Probe | 330905-00-10-05-02-00 | Bently Nevada
Bently Nevada 330905-00-10-05-02-00 3300 NSv Proximity Probe The Bently Nevada 330905-00-10-05-02-00, also cataloged as the 330905 3300 NSv Proximity Probe, operates as a dedicated hardware component for non-contact shaft displacement measurement within the Bently Nevada 3300 NSv Transducer System. Hardware Specifications Parameter Specification Model 330905-00-10-05-02-00 Brand Bently Nevada Product Type 3300 NSv Proximity Probe Origin USA Weight 0.14 kg Dimensions 20.5 x 22.5 x 3.5 cm estimated shipping size Power Consumption Passive eddy-current sensing element, system supplied Thread Type M10 x 1 metric thread Armor Type Without armor Unthreaded Length 0 mm Overall Case Length 100 mm Total Length 0.5 meter (20 in) Connector Type Miniature coaxial ClickLoc connector Cable Type Standard cable Agency Approval Not required Eddy-Current Measurement and Rotor Dynamics Monitoring The 3300 NSv proximity probe uses eddy-current sensing technology to measure shaft displacement through a non-contact electromagnetic field. Therefore, the probe provides a direct proportional relationship between probe gap distance and output voltage when connected with a compatible Proximitor module. The probe supports rotor dynamics analysis by providing displacement signals for vibration monitoring, axial position measurement, and mechanical shaft movement evaluation. In addition, the narrow side-view construction allows installation where standard radial probes cannot fit due to restricted mechanical clearance. The system requires proper eddy-current probe scaling and gap voltage validation during commissioning. Field technicians typically verify probe operation by checking the gap voltage condition, with Bently Nevada systems commonly targeting approximately -10 VDC at the normal operating gap. The miniature coaxial ClickLoc connector maintains signal integrity between the probe and extension cable. Furthermore, correct cable routing and shielding practices reduce signal interference and cross-talk effects in high vibration monitoring environments. Frequently Asked Questions Q: What measurement principle does the Bently Nevada 330905-00-10-05-02-00 use?A: The probe uses eddy-current technology to measure shaft displacement without physical contact between the probe tip and rotating shaft surface. Q: Does the 330905-00-10-05-02-00 include armored protection?A: No. This model uses an unarmored construction with a 0 mm unthreaded length option. Q: What connector type does this proximity probe use?A: The probe uses a miniature coaxial ClickLoc connector with a standard cable configuration. Field Installation Guidelines Install the probe using the specified M10 x 1 metric mounting thread and maintain proper mechanical alignment with the monitored shaft surface. Route the coaxial cable away from high-current power conductors, switching devices, and strong electromagnetic interference sources. Maintain correct cable shielding and grounding practices according to the connected monitoring system installation requirements. During commissioning, verify probe gap voltage, signal polarity, and mechanical clearance before placing the monitoring channel into service. Confirm that the probe tip remains free from physical contact with the rotating target under all operating conditions. Avoid excessive cable bending near the ClickLoc connector area because mechanical stress can affect signal transmission performance. Follow the approved Bently Nevada installation procedure for final probe positioning and system calibration.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330905-00-10-10-02-00 3300 NSv Proximity Probe
Bently Nevada 330905-00-10-10-02-00 3300 NSv Proximity Probe The Bently Nevada 330905-00-10-10-02-00, also cataloged as the 330905 3300 NSv Proximity Probe, operates as a dedicated hardware component for non-contact shaft displacement measurement within Bently Nevada TSI monitoring systems. Hardware Specifications Parameter Specification Model 330905-00-10-10-02-00 Brand Bently Nevada Product Series 3300 NSv Proximity Probe Product Type Eddy-current proximity sensor Thread Type M10 x 1 metric thread Armor Type Without armor Unthreaded Length 0 mm Overall Case Length 100 mm Total Length 1.0 meter (39 in) Connector Type Miniature coaxial ClickLoc connector standard cable Origin USA Weight 0.08 kg Dimensions Estimated shipping size: 1.8 x 1.6 x 63 cm Power Consumption Passive probe; powered by compatible proximity transducer interface Eddy-Current Measurement and Rotor Dynamics Characteristics The 330905-00-10-10-02-00 uses eddy-current sensing technology to convert shaft surface position changes into electrical displacement signals. Therefore, the probe operates with a compatible proximity system to measure relative shaft movement, vibration, and position deviation. The 3300 NSv design applies eddy-current probe scaling characteristics for installations requiring compact mechanical dimensions. Additionally, the M10 x 1 threaded body and 0 mm unthreaded length option support mounting locations with limited clearance. During system commissioning, technicians typically perform gap voltage validation to confirm correct probe positioning. The Bently Nevada monitoring architecture commonly references -10 VDC target gap voltage values for proper probe operation. Furthermore, rotor dynamics analysis uses the displacement signal generated by the probe to evaluate shaft motion behavior. The miniature coaxial ClickLoc connector reduces connection time while maintaining signal continuity between the probe cable assembly and monitoring electronics. The probe construction also supports signal integrity control by reducing potential measurement disturbances caused by installation-related interference. Frequently Asked Questions Q: What measurement principle does the 330905-00-10-10-02-00 use?A: The probe uses eddy-current measurement technology to detect shaft displacement without physical contact between the probe tip and rotating shaft surface. Q: Does this model include an armored cable design?A: No. The 330905-00-10-10-02-00 specification defines a probe without armor and uses a miniature coaxial ClickLoc connector standard cable configuration. Q: What installation factors affect probe signal accuracy?A: Correct mechanical gap setting, proper thread installation, cable routing, and shielding practices affect displacement signal quality and measurement stability. Field Installation Guidelines Install the M10 x 1 threaded probe into the prepared mounting location according to mechanical assembly requirements. Verify the probe tip clearance before operating the rotating equipment. Route the coaxial cable away from high-current power conductors to reduce electromagnetic interference. Connect the cable shield according to the monitoring system grounding requirements. Confirm the probe gap voltage during commissioning before enabling vibration or position monitoring functions. Avoid sharp cable bends and excessive mechanical stress on the ClickLoc connector interface.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330905-00-12-10-02-00 3300 NSv Proximity Probe
Bently Nevada 330905-00-12-10-02-00 3300 NSv Proximity Probe The Bently Nevada 330905-00-12-10-02-00, also cataloged as the 330905 Proximity Probe, operates as a dedicated eddy-current displacement sensor for shaft vibration and position measurement within the 3300 NSv Transducer System. Hardware Specifications Parameter Specification Model 330905-00-12-10-02-00 Brand Bently Nevada Product Series 3300 NSv Proximity Probe Origin USA Weight 0.14 kg Dimensions 120 mm overall case length, 1.0 m cable length Operating Temp -34 deg C to +177 deg C Power Consumption Supplied by compatible Bently Nevada proximity signal conditioner Measurement Type Non-contact eddy-current displacement and vibration sensing Thread Type M10 x 1 metric thread Probe Construction Unarmored probe design Scale Factor 7.87 V/mm (200 mV/mil) nominal Linear Range Approximately 1.5 mm to 2.0 mm (60 to 80 mils) Target Material AISI 4140 steel calibration target Cable Type 75 ohm coaxial cable with FEP insulation Connector Type Miniature coaxial ClickLoc connector Case Material 300 series stainless steel Probe Tip Material Polyphenylene sulfide (PPS) Eddy-Current Measurement and Rotor Dynamics Characteristics The 330905-00-12-10-02-00 uses an eddy-current sensing principle to detect relative shaft displacement without mechanical contact. Therefore, the probe provides direct measurements of shaft vibration and axial position changes for rotating machinery monitoring. The probe applies Bently Nevada eddy-current probe scaling characteristics with a nominal sensitivity of 7.87 V/mm. Furthermore, the system requires correct gap voltage validation during commissioning to maintain signal accuracy, with typical proximity systems using a -10 VDC target gap reference. The 3300 NSv design supports rotor dynamics analysis by providing displacement signals from restricted installation locations. In addition, the narrow side-view construction allows installation near small diameter shafts, compact bearing housings, and limited counterbore spaces. Frequently Asked Questions Q: Does the 330905-00-12-10-02-00 require physical contact with the rotating shaft?A: No. The probe uses an eddy-current sensing method and measures shaft displacement through an electromagnetic field without mechanical contact. Q: What cable and connector configuration does this model use?A: This model uses a 1.0 m standard coaxial cable with a miniature coaxial ClickLoc connector. Q: Can this probe operate in high-temperature machinery environments?A: Yes. The probe operating temperature range is -34 deg C to +177 deg C. The installation location must remain within the specified environmental limits. Field Installation Guidelines Install the 330905-00-12-10-02-00 probe with the correct M10 x 1 thread engagement and maintain mechanical alignment with the monitored shaft surface. Route the coaxial cable away from high-current power conductors and sources of electromagnetic interference. Use proper cable separation practices to maintain signal integrity. Verify the probe gap voltage during commissioning through the connected proximity monitoring system. Confirm the output signal polarity, mechanical clearance, and target surface condition before placing the machinery into operation. Avoid excessive cable bending near the ClickLoc connector area. Maintain the recommended minimum bend radius defined by the cable installation requirements to prevent internal conductor damage.
$200.00 $100.00
-
Bently Nevada 330905-00-15-05-02-05 | Bently Nevada | 3300 NSv Proximity Probe
Bently Nevada 330905-00-15-05-02-05 3300 NSv Proximity Probe The Bently Nevada 330905-00-15-05-02-05, also cataloged as the 330905 3300 NSv Proximity Probe, operates as a dedicated hardware component for shaft displacement measurement within the 3300 XL NSv Transducer System. It uses eddy-current sensing technology to provide non-contact vibration and position monitoring signals for rotating machinery applications. Hardware Specifications Parameter Specification Model 330905-00-15-05-02-05 Brand Bently Nevada Product Series 3300 XL NSv Proximity Probe Probe Type M10 x 1 Thread, Non-armored Probe Origin USA Dimensions Case Length: 150 mm; Cable Length: 0.5 m Operating Temp -52 deg C to +177 deg C Power Consumption Supplied by compatible 3300 XL NSv Proximity System Linear Range 1.5 mm (60 mils) Average Scale Factor (ASF) 7.87 V/mm (200 mV/mil) nominal Linear Range Start Gap Approximately 0.25 mm (10 mils) from target Target Material Calibration AISI 4140 steel Thread Size M10 x 1 metric fine thread Unthreaded Length 0 mm Probe Tip Material Polyphenylene sulfide (PPS) Probe Case Material AISI 304 Stainless Steel Connector Type Miniature coaxial ClickLoc connector, gold-plated brass Minimum Cable Bend Radius 25.4 mm Eddy-Current Probe Scaling and Rotor Dynamics Monitoring The 3300 XL NSv transducer system uses eddy-current probe scaling to convert shaft displacement into proportional electrical output signals. The 330905-00-15-05-02-05 probe provides a nominal scale factor of 200 mV/mil for vibration and position measurement. Furthermore, the probe supports rotor dynamics analysis by measuring relative shaft movement against the machine bearing structure. The system verifies the probe operating gap through gap voltage validation, where a typical target gap voltage is approximately -10 VDC for correct signal conditioning. The miniature coaxial ClickLoc connector maintains signal integrity through controlled impedance transmission. Additionally, the compact probe construction reduces installation restrictions in applications requiring limited side-view clearance. Frequently Asked Questions Q: What measurement principle does the Bently Nevada 330905-00-15-05-02-05 use?A: The probe uses eddy-current sensing technology to measure shaft displacement without physical contact between the probe tip and the rotating target. Q: What target material is used for standard calibration?A: The standard calibration target material is AISI 4140 steel. Other target materials may require system recalibration. Q: Can this probe operate in high-temperature machinery environments?A: Yes. The probe and cable assembly support an operating temperature range from -52 deg C to +177 deg C. Field Installation Guidelines Install the M10 x 1 threaded probe into the designated mounting location while maintaining the specified mechanical clearance around the probe tip. Ensure that the sensing face remains aligned with the rotating shaft target surface. Route the 0.5 m probe cable away from high-current conductors and strong electromagnetic interference sources. Maintain the minimum cable bend radius of 25.4 mm to prevent mechanical stress on the coaxial cable assembly. Connect the miniature coaxial ClickLoc connector securely and verify electrical continuity before commissioning. During setup, confirm the probe gap voltage output and adjust the installation position until the required operating gap is achieved.
$200.00 $100.00
-
Bently Nevada 330905-00-18-05-02-05 3300 NSv Proximity Probe | Bently Nevada
Bently Nevada 330905-00-18-05-02-05 3300 NSv Proximity Probe The Bently Nevada 330905-00-18-05-02-05, also cataloged as the 330905 3300 NSv Proximity Probe, operates as a dedicated hardware component for non-contact shaft displacement measurement within the Bently Nevada 3300 NSv Transducer System. Hardware Specifications Parameter Specification Model 330905-00-18-05-02-05 Brand Bently Nevada Product Type 3300 NSv Proximity Probe Origin USA Weight 0.14 kg Dimensions Estimated shipping size: 1.8 x 1.6 x 63 cm Thread Type M10 x 1 metric thread Armor Type Without armor Unthreaded Length 0 mm Overall Case Length 180 mm Total Length 0.5 meter (20 in) Connector Type Miniature coaxial ClickLoc connector Cable Type Standard cable Agency Approval Multiple Approvals Application Interface Eddy-current displacement measurement system Eddy-Current Probe Scaling and Rotor Dynamics Characteristics The Bently Nevada 330905-00-18-05-02-05 uses eddy-current sensing technology to measure shaft displacement without mechanical contact. The probe generates an electromagnetic field at the sensing tip and converts shaft position changes into electrical output signals through the associated proximity transducer system. Additionally, the 3300 NSv probe design supports rotor dynamics monitoring applications by providing displacement feedback for vibration analysis and shaft position evaluation. Therefore, correct probe installation, target material compatibility, and cable routing directly influence measurement stability. The probe system requires proper gap voltage validation during commissioning. Engineers typically verify the probe operating gap against Bently Nevada proximity system requirements, including standard gap voltage targets around -10 VDC for correct linear measurement operation. The miniature coaxial ClickLoc connector improves field connection consistency, while the compact M10 x 1 threaded housing allows installation in locations with limited mechanical clearance. Frequently Asked Questions Q: What measurement technology does the 330905-00-18-05-02-05 use?A: The probe uses eddy-current technology to detect shaft displacement by measuring changes in the electromagnetic field between the probe tip and the rotating target. Q: Does this model include an armored construction?A: No. The 330905-00-18-05-02-05 uses an unarmored configuration with a standard cable and miniature coaxial ClickLoc connector. Q: What installation factors affect probe measurement accuracy?A: Engineers should verify probe gap setting, target surface condition, cable routing, shielding practices, and connector installation to maintain accurate displacement signals. Field Installation Guidelines Install the Bently Nevada 330905-00-18-05-02-05 probe using the specified M10 x 1 mounting thread and maintain proper mechanical alignment with the monitored shaft target. Route the probe cable away from high-current power conductors and strong electromagnetic interference sources. Use appropriate shielding and grounding methods according to the system installation requirements. Before operation, verify the probe gap voltage and confirm that the connected monitoring channel receives a stable displacement signal. Inspect the miniature coaxial ClickLoc connector for correct engagement and secure mechanical connection. Avoid excessive cable bending near the connector area because mechanical stress can affect signal integrity. Confirm the installed probe length and clearance requirements before final equipment startup.
$200.00 $100.00
-
Bently Nevada 3300 NSv Proximity Probe | Bently Nevada | 330905-00-20-10-02-00
Bently Nevada 330905-00-20-10-02-00 3300 NSv Proximity Probe The Bently Nevada 330905-00-20-10-02-00, also cataloged as the 330905 3300 NSv Proximity Probe, operates as a dedicated hardware component for non-contact shaft displacement measurement within Bently Nevada 3300 NSv Transducer System platforms. Hardware Specifications Parameter Specification Model 330905-00-20-10-02-00 Brand Bently Nevada Product Type 3300 NSv Proximity Probe Origin USA Dimensions Case length: 200 mm; total length: 1.0 m Operating Temp -51 deg C to +177 deg C Power Consumption Supplied through compatible Bently Nevada Proximitor sensor module; probe operates as a passive sensing element Thread Type M10 x 1 metric fine thread Probe Construction Unarmored probe design with fully threaded body Target Material Standard AISI 4140 steel Linear Range 1.5 mm (60 mils) Incremental Scale Factor (ISF) 7.87 V/mm (200 mV/mil) nominal Recommended Gap Setting 1.0 mm (40 mils) Case Material AISI 304 stainless steel Tip Material Polyphenylene sulfide (PPS) Cable Type 75 ohm coaxial cable, FEP insulated Connector Type Gold-plated brass miniature coaxial ClickLoc connector Connector Mechanism Push-pull locking mechanism Humidity Rating 100% condensing, non-submerged Eddy-Current Probe Scaling and Gap Voltage Validation The 3300 NSv proximity probe uses an eddy-current measurement principle to convert shaft displacement into electrical output signals. The probe maintains a nominal incremental scale factor of 7.87 V/mm, allowing compatible Proximitor systems to process radial shaft movement data. Furthermore, installation requires gap voltage validation to establish the correct operating position. Bently Nevada systems typically verify probe gap conditions around the -10 VDC target range when adjusting the transducer circuit. This process confirms proper signal linearity and measurement accuracy before machinery operation. The narrow side-view construction also supports rotor dynamics monitoring where installation space limits the available probe mounting position. Therefore, the probe can measure relative shaft motion in machines using fluid-film bearings, compressor rotors, and similar rotating equipment. Frequently Asked Questions Q: What type of measurement does the Bently Nevada 330905-00-20-10-02-00 provide?A: The probe provides non-contact shaft displacement measurement through eddy-current sensing technology. It detects relative movement between the probe tip and the conductive shaft target. Q: Does the 330905-00-20-10-02-00 require an external power supply?A: The probe itself is a passive sensing element. A compatible Bently Nevada Proximitor module supplies excitation and converts the probe signal into monitoring data. Q: What installation factors affect measurement performance?A: Proper thread mounting, target surface condition, cable routing, electrical shielding, and correct probe gap adjustment affect measurement performance. The cable should avoid strong electromagnetic interference sources. Field Installation Guidelines Install the M10 x 1 threaded probe body into the approved mounting location without damaging the probe tip surface. Adjust the probe gap according to the compatible Proximitor system requirements and verify the electrical gap voltage before operation. Maintain proper cable routing practices to reduce electromagnetic interference and signal noise. Avoid sharp cable bends that may affect the 75 ohm coaxial cable characteristics. Connect the miniature coaxial ClickLoc connector securely and confirm the locking mechanism engages correctly. Use appropriate grounding practices for the monitoring system shield connection according to site electrical standards. Verify shaft target material compatibility before commissioning the vibration monitoring channel.
$200.00 $100.00
-
Bently Nevada 330905-00-25-05-01-CN 3300 NSv Proximity Probe | Bently Nevada
Bently Nevada 330905-00-25-05-01-CN 3300 NSv Proximity Probe The Bently Nevada 330905-00-25-05-01-CN, also cataloged as the 330905 3300 NSv Proximity Probe, operates as a dedicated hardware component for shaft displacement and vibration measurement within 3300 XL NSv Transducer System installations. Hardware Specifications Parameter Specification Model 330905-00-25-05-01-CN Brand Bently Nevada Product Type Proximity Sensors Series 3300 XL NSv Transducer System Origin USA Dimensions Case Length: 250 mm; Total Length: 0.5 meter Operating Temp -51 deg C to +177 deg C Storage Temp -51 deg C to +177 deg C Thread Type M10 x 1.0 Fine Thread Probe Construction Without Armor Unthreaded Length 0 mm Case Material 304 Stainless Steel Probe Tip Material Polyphenylene Sulfide (PPS) Connector Type Miniature Coaxial ClickLoc Connector with Connector Protector Measurement Technology Eddy Current Proximity Sensing Linear Range 1.5 mm nominal Average Scale Factor 7.87 V/mm nominal Target Material AISI 4140 Steel Power Consumption Not specified; supplied through compatible 3300 XL NSv Proximitor system Eddy-Current Probe Scaling and Rotor Dynamics Measurement The 330905-00-25-05-01-CN uses eddy-current sensing technology to detect relative shaft motion without mechanical contact. Therefore, the probe provides proportional displacement signals for vibration analysis and axial position monitoring. The probe maintains a nominal scale factor of 7.87 V/mm, which supports calibrated distance measurement between the probe tip and conductive shaft surfaces. In addition, the 3300 XL NSv design applies side-view immunity characteristics to reduce measurement influence from restricted mounting areas. Furthermore, the probe supports rotor dynamics evaluation by delivering displacement data required for vibration monitoring systems. The system configuration allows engineers to validate probe gap conditions through standard proximity system gap voltage checks, including typical -10 VDC target settings during installation calibration. Frequently Asked Questions Q: What measurement principle does the 330905-00-25-05-01-CN use?A: The probe uses eddy-current proximity sensing to measure shaft displacement by detecting changes in the electromagnetic field between the probe tip and the conductive target. Q: Can this probe operate in restricted installation spaces?A: Yes. The 3300 XL NSv probe design supports installations with limited side clearance, counterbore mounting restrictions, and small target geometry requirements. Q: What connector configuration does this model provide?A: This model uses a miniature coaxial ClickLoc connector with a connector protector and standard cable configuration. Field Installation Guidelines Install the probe using the specified M10 x 1.0 mounting thread and maintain proper mechanical alignment with the measured shaft surface. Verify the probe tip clearance and target condition before commissioning the proximity measurement loop. Connect the miniature coaxial cable according to the applicable 3300 XL NSv system wiring requirements. Maintain separation between probe signal cables and high-voltage power conductors to reduce electromagnetic interference. Ground cable shielding according to the monitoring system installation practice and avoid creating unintended ground loops. Confirm the gap voltage output after installation to verify correct probe positioning and signal scaling.
$200.00 $100.00
-
Bently Nevada 330905-00-25-05-02-05 Bently Nevada 3300 NSv Proximity Probe
Bently Nevada 330905-00-25-05-12-CN 3300 NSv Proximity Probe The Bently Nevada 330905-00-25-05-12-CN, also cataloged as the 330905 3300 NSv Proximity Probe, operates as a dedicated hardware component for shaft displacement measurement within Bently Nevada 3300 XL NSv Transducer System platforms. Hardware Specifications Parameter Specification Model 330905-00-25-05-12-CN Brand Bently Nevada Product Type 3300 NSv Proximity Probe Origin USA Weight 0.05 kg Dimensions 1.8 x 1.6 x 66 cm estimated shipping size Power Consumption Supplied through compatible Proximitor Sensor, not specified Thread Type M10 x 1 metric thread Armor Configuration Without armor Unthreaded Length 0 mm Overall Case Length 250 mm Total Length 0.5 meter (20 in) Connector Type Miniature coaxial ClickLoc connector Cable Type FluidLoc cable Agency Approval Multiple Approval Average Scale Factor 7.87 V/mm (200 mV/mil) Measurement Principle Eddy-current displacement sensing Eddy-Current Probe Scaling and Rotor Dynamics The 330905-00-25-05-12-CN uses an eddy-current measurement principle to convert shaft position changes into electrical displacement signals. Therefore, the probe provides a 7.87 V/mm (200 mV/mil) average scale factor for compatibility with the 3300 XL NSv Proximitor Sensor. The compact M10 x 1 mechanical design supports installation where standard 3300 and 3300 XL 5 mm or 8 mm transducer systems cannot be installed. In addition, the probe geometry supports rotor dynamics monitoring applications by measuring radial vibration, axial position, and shaft movement characteristics. The system configuration requires proper gap voltage validation during commissioning. Furthermore, Bently Nevada monitoring systems typically verify probe operating range through gap voltage measurements, including -10 VDC target reference conditions for correct eddy-current probe operation. Frequently Asked Questions Q: What monitoring system is compatible with the 330905-00-25-05-12-CN probe?A: The probe operates as part of the 3300 XL NSv Transducer System and requires a compatible 3300 XL NSv Proximitor Sensor and extension cable configuration. Q: Can this probe replace older 3300 RAM or 3000-series systems directly?A: The 3300 XL NSv system can replace 3300 RAM and 3000-series or 7000-series 190 Transducer Systems. However, upgrades may require replacement of the probe, extension cable, and Proximitor Sensor depending on the original system configuration. Q: Does the probe include armor protection?A: No. The 330905-00-25-05-12-CN uses a non-armored construction with a FluidLoc cable and miniature coaxial ClickLoc connector. Field Installation Guidelines Install the 330905-00-25-05-12-CN probe with the specified M10 x 1 thread engagement and maintain correct mechanical alignment with the rotating target surface. Route the probe cable away from high-current power conductors and electromagnetic interference sources. Use proper cable support to prevent mechanical stress at the connector interface. Connect the cable shield according to the monitoring system grounding practice. Avoid grounding methods that create additional ground loops between the probe system and machinery monitoring equipment. During commissioning, verify probe clearance, gap voltage, and signal response through the connected Proximitor Sensor. Confirm that the measured displacement signal remains within the expected operating range before enabling machine protection functions.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330905-00-25-05-12-CN 3300 NSv Proximity Probe
Bently Nevada 330905-00-25-05-12-CN 3300 NSv Proximity Probe The Bently Nevada 330905-00-25-05-12-CN, also cataloged as the 330905 3300 NSv Proximity Probe, operates as a dedicated hardware component for shaft displacement measurement within Bently Nevada 3300 XL NSv Transducer System platforms. Hardware Specifications Parameter Specification Model 330905-00-25-05-12-CN Brand Bently Nevada Product Type 3300 NSv Proximity Probe Origin USA Weight 0.05 kg Dimensions 1.8 x 1.6 x 66 cm estimated shipping size Power Consumption Supplied through compatible Proximitor Sensor, not specified Thread Type M10 x 1 metric thread Armor Configuration Without armor Unthreaded Length 0 mm Overall Case Length 250 mm Total Length 0.5 meter (20 in) Connector Type Miniature coaxial ClickLoc connector Cable Type FluidLoc cable Agency Approval Multiple Approval Average Scale Factor 7.87 V/mm (200 mV/mil) Measurement Principle Eddy-current displacement sensing Eddy-Current Probe Scaling and Rotor Dynamics The 330905-00-25-05-12-CN uses an eddy-current measurement principle to convert shaft position changes into electrical displacement signals. Therefore, the probe provides a 7.87 V/mm (200 mV/mil) average scale factor for compatibility with the 3300 XL NSv Proximitor Sensor. The compact M10 x 1 mechanical design supports installation where standard 3300 and 3300 XL 5 mm or 8 mm transducer systems cannot be installed. In addition, the probe geometry supports rotor dynamics monitoring applications by measuring radial vibration, axial position, and shaft movement characteristics. The system configuration requires proper gap voltage validation during commissioning. Furthermore, Bently Nevada monitoring systems typically verify probe operating range through gap voltage measurements, including -10 VDC target reference conditions for correct eddy-current probe operation. Frequently Asked Questions Q: What monitoring system is compatible with the 330905-00-25-05-12-CN probe?A: The probe operates as part of the 3300 XL NSv Transducer System and requires a compatible 3300 XL NSv Proximitor Sensor and extension cable configuration. Q: Can this probe replace older 3300 RAM or 3000-series systems directly?A: The 3300 XL NSv system can replace 3300 RAM and 3000-series or 7000-series 190 Transducer Systems. However, upgrades may require replacement of the probe, extension cable, and Proximitor Sensor depending on the original system configuration. Q: Does the probe include armor protection?A: No. The 330905-00-25-05-12-CN uses a non-armored construction with a FluidLoc cable and miniature coaxial ClickLoc connector. Field Installation Guidelines Install the 330905-00-25-05-12-CN probe with the specified M10 x 1 thread engagement and maintain correct mechanical alignment with the rotating target surface. Route the probe cable away from high-current power conductors and electromagnetic interference sources. Use proper cable support to prevent mechanical stress at the connector interface. Connect the cable shield according to the monitoring system grounding practice. Avoid grounding methods that create additional ground loops between the probe system and machinery monitoring equipment. During commissioning, verify probe clearance, gap voltage, and signal response through the connected Proximitor Sensor. Confirm that the measured displacement signal remains within the expected operating range before enabling machine protection functions.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330905-06-14-10-02-00 3300 NSv Proximity Probe
Bently Nevada 330905-06-14-10-02-00 3300 NSv Proximity Probe The Bently Nevada 330905-06-14-10-02-00, also cataloged as the 330905 3300 NSv Proximity Probe, operates as a dedicated hardware component for shaft displacement measurement within the 3300 XL NSv Proximity Transducer System. Hardware Specifications Parameter Specification Model 330905-06-14-10-02-00 Brand Bently Nevada Product Type 3300 NSv Proximity Probe Origin USA Weight 0.14 kg Dimensions Estimated shipping size: 20.3 x 22 x 3.5 cm Operating Temp -52 deg C to +177 deg C Power Consumption Powered through compatible Proximitor Sensor, -17.5 VDC to -26 VDC supply range Probe Thread Type M10 x 1 metric thread Probe Construction Without stainless steel armor Transducer System 3300 XL NSv Proximity Transducer System Measurement Principle Eddy-current non-contact displacement measurement Unthreaded Length 60 mm Overall Case Length 140 mm Total Cable Length 1.0 m Connector Type Miniature coaxial ClickLoc connector Target Material AISI 4140 steel target Linear Range 1.5 mm Average Scale Factor 7.87 V/mm nominal Linearity Deviation +/- 38 um or better Eddy-Current Probe Scaling and Rotor Dynamics Monitoring The 330905-06-14-10-02-00 uses eddy-current probe scaling technology to convert shaft displacement into proportional electrical signals. Therefore, the connected Proximitor Sensor can process vibration and position measurements through the calibrated probe gap relationship. The probe system supports rotor dynamics analysis by providing shaft relative displacement data for vibration monitoring applications. Additionally, the measurement output depends on correct probe installation, target surface condition, and gap voltage validation. Bently Nevada systems commonly verify probe operation through gap voltage targets around -10 VDC during commissioning procedures. The 3300 NSv design reduces installation limitations in restricted mounting locations. Furthermore, the narrow side-view construction supports applications where standard probe body dimensions cannot meet mechanical clearance requirements. Frequently Asked Questions Q: What measurement technology does the 330905-06-14-10-02-00 use?A: The probe uses eddy-current sensing technology to measure relative shaft displacement without physical contact with the rotating target. Q: Does this probe include stainless steel armor protection?A: No. The 330905-06-14-10-02-00 configuration specifies a probe without stainless steel armor. Q: What electrical device processes the probe signal?A: The probe connects to a compatible 3300 XL NSv Proximitor Sensor, which provides signal conditioning and displacement output. Field Installation Guidelines Install the probe with the specified M10 x 1 mounting thread and maintain correct mechanical alignment with the shaft target surface. Verify the probe gap voltage after installation to confirm proper operating range before machine operation. Route the coaxial cable away from high-current power conductors to reduce electrical interference. Maintain proper cable shielding and grounding practices according to the monitoring system installation requirements. Confirm the target surface condition before commissioning because surface damage or contamination can affect eddy-current measurement accuracy. Avoid excessive cable bending near the miniature coaxial ClickLoc connector to prevent mechanical stress on the connection point.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330905-07-17-05-02-05 3300 NSv Proximity Probe
Bently Nevada 330905-07-17-05-02-05 3300 NSv Proximity Probe The Bently Nevada 330905-07-17-05-02-05, also cataloged as the 330905 3300 NSv Proximity Probe, operates as a dedicated hardware component for eddy-current shaft displacement measurement within the 3300 XL NSv Transducer System. Hardware Specifications Parameter Specification Model 330905-07-17-05-02-05 Brand Bently Nevada Product Type 3300 NSv Proximity Probe System Platform 3300 XL NSv Proximity Transducer System Origin USA Dimensions M10 x 1 thread; 70 mm unthreaded length; 170 mm overall case length Operating Temp -34 deg C to +177 deg C Storage Temp -51 deg C to +177 deg C Power Consumption Passive probe element; powered through compatible Proximity System interface Thread Type M10 x 1 metric thread Armor Type Without armor Total Cable Length 0.5 m Cable Type 75 ohm coaxial FEP insulated standard cable Connector Type Miniature coaxial ClickLoc connector Probe Case Material AISI 304 stainless steel Probe Tip Material Polyphenylene sulfide (PPS) Linear Range 1.5 mm (60 mils) Average Scale Factor 7.87 V/mm (200 mV/mil) Target Material AISI 4140 steel calibration target Frequency Response 0 to 10 kHz (-3 dB) Agency Approval Multiple approvals including CSA, ATEX, IECEx options Eddy-Current Measurement and Rotor Dynamics Monitoring The Bently Nevada 330905-07-17-05-02-05 uses eddy-current probe scaling to convert shaft displacement into proportional electrical output signals. The probe works with compatible 3300 XL NSv Proximitor modules to provide radial vibration and position measurement data. Additionally, the system requires gap voltage validation during commissioning. Technicians normally verify probe operation against the -10 VDC target gap voltage condition to confirm correct probe-to-shaft spacing. The narrow side-view construction supports rotor dynamics monitoring applications where installation clearance limits standard probe mounting. Furthermore, the probe design reduces installation interference when measuring small shafts below 51 mm or flat targets below 15 mm. Frequently Asked Questions Q: What measurement principle does the 330905-07-17-05-02-05 use?A: The probe uses eddy-current technology to measure relative shaft displacement through electromagnetic field variation between the probe tip and conductive target surface. Q: Does this probe include an armored cable design?A: No. The 330905-07-17-05-02-05 configuration uses a standard cable without armor protection. Q: What connector type does this proximity probe use?A: The probe uses a miniature coaxial ClickLoc connector designed for secure connection with compatible 3300 XL NSv system components. Field Installation Guidelines Install the probe with the correct M10 x 1 threaded mounting arrangement and maintain proper mechanical alignment between the probe tip and the measured shaft surface. Route the coaxial cable separately from high-current power conductors and variable frequency drive output cables to reduce electrical interference. Maintain proper cable bending practices to prevent damage to the FEP insulation and connector assembly. During commissioning, verify probe polarity, signal output, and gap voltage before placing the monitoring channel into service. Confirm that the probe tip faces the target surface without mechanical contact during machine operation. Connect the ClickLoc connector securely and verify that the cable shield follows the system grounding requirements specified for the 3300 XL NSv installation.
$200.00 $100.00
-
Bently Nevada 330908-12-31-10-02-00 Bently Nevada 3300 NSv Proximity Probe
Bently Nevada 330908-12-31-10-02-00 3300 NSv Proximity Probe The Bently Nevada 330908-12-31-10-02-00, also cataloged as the 330908 3300 NSv Proximity Probe, operates as a dedicated hardware component for eddy-current displacement measurement within the 3300 NSv Proximity Transducer System. The probe converts shaft target position changes into proportional voltage signals for vibration, position, and Keyphasor monitoring applications. Hardware Specifications Parameter Specification Model 330908-12-31-10-02-00 Brand Bently Nevada Product Type 3300 NSv Eddy Current Proximity Probe Origin USA Dimensions 3/8-24 UNF thread; 1.2 in unthreaded length; 3.1 in overall case length Operating Temp -34 deg C to +177 deg C Power Consumption Powered by compatible 3300 NSv Proximity Transducer System driver Thread Type 3/8-24 UNF-2A Armor Configuration Without armor Cable Length 1.0 m Cable Type 75 ohm coaxial cable with FEP insulation Connector Type Miniature coaxial ClickLoc connector Measurement Principle Eddy current displacement sensing Linear Range 1.5 mm (60 mils) Recommended Gap Setting 1.0 mm (40 mils) Incremental Scale Factor 7.87 V/mm (200 mV/mil) +/- 12.5% Output Voltage Range Approximately -1 VDC to -13 VDC Probe Tip Material Polyphenylene sulfide (PPS) Probe Body Material AISI 304 stainless steel Standard Target Material AISI 4140 steel Mounting Torque 11.3 N m (100 in lb) Eddy Current Probe Scaling and Rotor Dynamics Monitoring The 3300 NSv probe uses eddy-current sensing technology to measure shaft displacement relative to the probe tip. Therefore, the probe output follows a defined voltage displacement relationship with an incremental scale factor of 7.87 V/mm. The system supports rotor dynamics analysis by providing continuous shaft vibration and position feedback. In addition, the narrow side-view probe structure reduces side-wall interference when installed near small diameter targets, counterbores, and restricted bearing housings. Gap voltage validation remains a key installation procedure for accurate measurement. The 3300 NSv system typically verifies probe gap voltage near the -10 VDC target position to confirm correct operating clearance and signal linearity. Frequently Asked Questions Q: What measurement signals does the 330908-12-31-10-02-00 provide?A: The probe provides proportional voltage output related to shaft displacement and supports vibration, radial position, and Keyphasor measurement when connected to a compatible 3300 NSv driver system. Q: Can the probe operate without an extension cable?A: Yes. This model includes a 1.0 m integrated cable length. The final system configuration depends on the required distance between the probe and monitoring electronics. Q: What installation factors affect measurement accuracy?A: Proper probe gap adjustment, target material compatibility, cable routing, and electrical shielding practices directly affect displacement measurement accuracy. Field Installation Guidelines Install the probe with the specified 3/8-24 UNF mounting thread and maintain proper mechanical alignment with the rotating shaft target surface. Verify the probe gap voltage after mechanical installation. Adjust the probe position until the operating voltage falls within the intended range for the 3300 NSv system. Route the coaxial cable away from high-current power conductors and strong electromagnetic interference sources. Maintain proper cable shielding practices and connect the shield according to the monitoring system grounding requirements. Avoid excessive cable bending near the ClickLoc connector area. Confirm that the probe tip faces the target material directly and that the mounting structure does not introduce mechanical movement during operation.
$200.00 $100.00
-
Bently Nevada 330910-00-15-10-02-00 3300 NSv Proximity Probe Bently Nevada
Bently Nevada 330910-00-15-10-02-00 3300 NSv Proximity Probe Configured for shaft displacement and vibration signal measurement in the 3300 XL NSv Proximity Transducer System, the Bently Nevada 330910-00-15-10-02-00 (330910 3300 NSv Proximity Probe) provides direct eddy-current sensing execution for rotating machinery monitoring circuits. Hardware Specifications Parameter Specification Model 330910-00-15-10-02-00 Brand Bently Nevada Product Type 3300 NSv Proximity Probe System Compatibility 3300 XL NSv Proximitor Sensor and 3300 NSv Extension Cable Origin USA Dimensions 1.5 in case length, M10 x 1 metric thread Operating Temp -52 deg C to +177 deg C Storage Temp -52 deg C to +177 deg C Power Consumption 12 mA maximum current drain through Proximitor Sensor Probe Structure Flexible stainless steel armored proximity probe Thread Type M10 x 1 metric mounting thread Case Material AISI 304 stainless steel Probe Tip Material Polyphenylene sulfide (PPS) Cable Type 75 ohm triaxial FEP insulated cable with AISI 302/304 stainless steel armor Connector Type Gold-plated brass/beryllium copper miniature coaxial ClickLoc connector Scale Factor 7.87 V/mm (200 mV/mil) Average Scale Factor Linear Range 1.5 mm (60 mils) Frequency Response 0 to 2.7 kHz (+0, -3 dB typical) Power Supply Requirement -17.5 VDC to -26 VDC supplied by 3300 XL NSv Proximitor Sensor Mounting Torque Recommended 11.3 N m; maximum rated 33.9 N m Humidity Limit 100% condensing, non-submerged when connectors are sealed Eddy-Current Measurement and Rotor Dynamics Characteristics The 330910-00-15-10-02-00 uses eddy-current probe scaling to convert shaft-to-probe gap variations into proportional electrical output signals. Therefore, the probe supports dynamic vibration measurement and static shaft position monitoring within the 3300 XL NSv signal chain. The probe requires gap voltage validation during system commissioning. Engineers typically verify the probe operating point near the -10 VDC target condition to confirm correct mechanical installation and measurement range. Furthermore, the NSv sensing structure supports rotor dynamics analysis on compact rotating equipment. The probe geometry allows installation where standard proximity probes cannot fit, including small-diameter shafts and restricted side-view mounting locations. Frequently Asked Questions Q: What transducer components are required for operation with the 330910-00-15-10-02-00 probe?A: The probe requires a complete 3300 XL NSv Proximity Transducer System, including the 3300 NSv Extension Cable and 3300 XL NSv Proximitor Sensor. Q: Can the 330910 probe measure both vibration and axial position signals?A: Yes. The probe supports radial vibration measurement on shafts smaller than 51 mm and axial position measurement on targets smaller than 15 mm when installed within specified mechanical conditions. Q: Does the probe require special installation considerations for signal accuracy?A: Yes. Installation requires correct probe gap setting, proper cable routing, and connector sealing to maintain electrical signal integrity and environmental protection. Field Installation Guidelines Install the M10 x 1 threaded probe body with the specified mounting torque to prevent mechanical loosening or thread damage. Maintain proper probe tip clearance from the target surface before connecting the extension cable and Proximitor Sensor. Route the armored cable away from high-current power conductors and strong electromagnetic interference sources. Verify connector engagement and ensure the ClickLoc connector remains properly secured during operation. Confirm the probe gap voltage during commissioning and validate the signal output before placing the monitoring channel into service. Avoid sharp cable bending near the probe body and connector interface to protect the triaxial cable structure.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330910-00-18-10-02-00 3300 NSv Proximity Probe
Bently Nevada 330910-00-18-10-02-00 3300 NSv Proximity Probe The Bently Nevada 330910-00-18-10-02-00, also cataloged as the 330910 3300 NSv Proximity Probe, operates as a dedicated hardware component for shaft displacement measurement and vibration monitoring within the 3300 XL NSv Proximity Transducer System. Hardware Specifications Parameter Specification Model 330910-00-18-10-02-00 Brand Bently Nevada Product Type 3300 NSv Eddy Current Proximity Probe Origin USA Dimensions M10 x 1 thread, 180 mm overall case length, 1.0 m system length Operating Temp -51 deg C to +177 deg C Power Consumption Supplied by compatible 3300 XL NSv Proximitor system System Technology Eddy current displacement measurement Thread Type Metric M10 x 1 Cable Protection Flexible stainless steel armor Probe Tip Material Polyphenylene sulfide (PPS) Case Material AISI 304 stainless steel Connector Type Gold-plated miniature coaxial ClickLoc connector Target Material AISI 4140 steel standard calibration Linear Range 1.5 mm nominal Scale Factor 7.87 V/mm (200 mV/mil) Cable Resistance 75 ohm coaxial FEP insulated cable Relative Humidity 100% condensing, non-submerged Eddy Current Probe Scaling and Rotor Dynamics Monitoring The 330910-00-18-10-02-00 uses eddy-current probe scaling to convert shaft position changes into proportional electrical signals. The system maintains a nominal scale factor of 7.87 V/mm (200 mV/mil) for displacement measurement. Furthermore, the probe supports rotor dynamics analysis by providing shaft vibration and axial position data to compatible monitoring modules. The ClickLoc connector design maintains the coaxial signal path during mechanical vibration conditions. The armored cable construction reduces mechanical damage risks in restricted installation areas. The 3300 XL NSv system requires correct gap voltage validation during commissioning. Engineers typically verify probe operating conditions against the -10 VDC gap voltage target range used for standard Bently Nevada proximity measurement calibration. Frequently Asked Questions Q: What measurement principle does the Bently Nevada 330910-00-18-10-02-00 use?A: The probe uses eddy-current technology to measure the distance between the probe tip and conductive shaft surface, generating proportional displacement signals. Q: Can this probe replace a standard 8 mm proximity probe?A: No. The 330910 series uses a Narrow Side View design for applications requiring reduced installation clearance and is configured specifically for 3300 XL NSv systems. Q: What connector type does this probe use?A: The probe uses a miniature coaxial ClickLoc connector with a gold-plated contact design for connection to compatible extension cables and Proximitor systems. Field Installation Guidelines Install the probe with the M10 x 1 threaded body fully secured according to the mechanical drawing requirements of the application. Maintain correct probe tip orientation toward the measurement target surface. Avoid mechanical contact between the probe tip and rotating components during installation and operation. Route the armored coaxial cable away from high-current power conductors to reduce electromagnetic interference. Connect the cable shield according to the monitoring system grounding practice. Before operation, verify probe gap voltage, signal polarity, and system calibration using compatible Bently Nevada diagnostic equipment. Confirm that the probe, extension cable, and Proximitor module form a matched electrical system.
$200.00 $100.00
-
Bently Nevada 330910-07-23-10-02-00 | Bently Nevada | 3300 NSv Proximity Probe
Bently Nevada 330910-07-23-10-02-00 3300 NSv Proximity Probe The Bently Nevada 330910-07-23-10-02-00, also cataloged as the 330910 3300 NSv Proximity Probe, operates as a dedicated hardware component for eddy-current displacement measurement within the 3300 NSv Proximity Transducer System. Hardware Specifications Parameter Specification Model 330910-07-23-10-02-00 Brand Bently Nevada Product Type 3300 NSv Proximity Probe Origin USA Dimensions 70 mm unthreaded length, 230 mm overall case length Operating Temp -51 deg C to +177 deg C Power Consumption Supplied through 3300 XL NSv Proximitor Sensor, -17.5 VDC to -26 VDC Thread Size M10 x 1 Probe Series 3300 NSv Narrow Side View Proximity System Cable Length 1.0 meter (39 in) Connector Type Miniature coaxial ClickLoc connector Connector Material Gold-plated brass Probe Case Material AISI 304 stainless steel Armor Material AISI 302 stainless steel flexible armor Probe Tip Material Polyphenylene Sulfide (PPS) Linear Range 1.5 mm (60 mils) Target Scale Factor 7.87 V/mm (200 mV/mil) average Frequency Response 0 to 10 kHz (+0, -3 dB typical) Recommended Target Material AISI 4140 steel Target Compatibility Shaft diameter less than 51 mm (2 in), axial target diameter less than 15 mm (0.6 in) Eddy-Current Measurement and Rotor Dynamics Characteristics The 330910-07-23-10-02-00 uses eddy-current probe scaling to convert shaft displacement into proportional electrical output signals. The probe maintains a nominal scale factor of 7.87 V/mm for vibration and axial position monitoring applications. Furthermore, the 3300 NSv system supports gap voltage validation through the Proximitor Sensor output, where technicians verify probe operating position near the typical -10 VDC target condition. This measurement confirms proper probe gap adjustment before machinery operation. The narrow side view construction reduces installation restrictions in compact assemblies. Therefore, the probe supports rotor dynamics monitoring where limited radial clearance prevents installation of standard proximity probe designs. The shielded miniature coaxial connection helps reduce signal interference during high-frequency vibration measurement. Frequently Asked Questions Q: What measurement principle does the 330910-07-23-10-02-00 use?A: The probe uses an eddy-current sensing principle to measure shaft displacement and provide dynamic vibration or axial position signals through the 3300 NSv Proximity Transducer System. Q: Can the probe operate directly without a Proximitor Sensor?A: No. The probe requires a compatible 3300 XL NSv Proximitor Sensor to provide excitation and process the eddy-current measurement signal. Q: What installation factor must technicians verify during commissioning?A: Technicians should verify probe gap voltage, mechanical alignment, target material compatibility, cable routing, and connector installation condition before system operation. Field Installation Guidelines Install the M10 x 1 threaded probe into the prepared mounting location while maintaining correct mechanical alignment with the measurement target. Verify the unthreaded probe length and case dimensions before installation to prevent interference with surrounding machine components. Maintain proper separation between probe cable routing and high-current power conductors to reduce electrical noise coupling. Connect the miniature coaxial ClickLoc connector securely and inspect the cable armor for mechanical damage before commissioning. Confirm the probe gap voltage through the connected Proximitor Sensor and adjust the mounting position according to the required operating range. Use compatible target materials, such as AISI 4140 steel, to maintain specified eddy-current measurement characteristics. Ground cable shielding according to the machinery monitoring system installation requirements and avoid unnecessary shield loops.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330930-040-00-00 3300 NSv Extension Cable
Bently Nevada 330930-040-00-00 3300 NSv Extension Cable The Bently Nevada 330930-040-00-00, also cataloged as the 3300 NSv Extension Cable, operates as a dedicated hardware component for signal transmission between proximity probes and proximitor sensors within the 3300 NSv Eddy Current Proximity Transducer System. Hardware Specifications Parameter Specification Model 330930-040-00-00 Brand Bently Nevada Product Type 3300 NSv Extension Cable Origin USA Weight 0.05 kg Dimensions 17 x 17 x 1.5 cm estimated shipping size Operating Temp -52 deg C to +177 deg C Storage Temp -52 deg C to +177 deg C Power Consumption Passive cable, no external power consumption Cable Length 4.0 meters (13.1 feet) Cable Material 75 Ohm coaxial cable with FEP insulation Connector and Cable Option Without stainless steel armor Agency Approval Option Not required Tariff Code 8537101190 Place of Shipment Xiamen, China System Compatibility Bently Nevada 3300 NSv Eddy Current Proximity Transducer System Eddy-Current Signal Scaling and Rotor Monitoring Characteristics The Bently Nevada 330930-040-00-00 extension cable maintains the electrical characteristics required for 3300 NSv eddy-current measurement circuits. Therefore, it supports accurate probe signal transfer between the proximity probe and proximitor module without altering the calibrated measurement relationship. The 3300 NSv system uses eddy-current probe scaling technology to convert shaft displacement into electrical output signals. Additionally, the cable construction supports stable gap voltage transmission and measurement validation, including standard proximity system checks around -10 VDC gap voltage targets. The 3300 NSv extension cable supports rotor dynamics monitoring applications by preserving vibration and position signal integrity. Moreover, the 75 Ohm coaxial design and FEP insulation provide controlled impedance characteristics for rotating machinery monitoring circuits. Frequently Asked Questions Q: What equipment uses the Bently Nevada 330930-040-00-00 cable?A: The cable connects components within the Bently Nevada 3300 NSv Eddy Current Proximity Transducer System, typically between an NSv probe and its associated proximitor sensor. Q: Does the 330930-040-00-00 extension cable require external power?A: No. The extension cable is a passive signal transmission component and does not consume external electrical power. Q: What environmental temperature range does this cable support?A: The cable supports operating and storage temperatures from -52 deg C to +177 deg C. Field Installation Guidelines Install the 330930-040-00-00 cable according to the 3300 NSv system installation requirements. Keep the cable routing away from high-voltage power conductors and strong electromagnetic interference sources to reduce signal disturbance. Maintain the specified connector engagement between the probe, extension cable, and proximitor interface. Inspect connector surfaces before installation and prevent contamination on signal contacts. Use proper shielding and grounding practices for the proximity measurement circuit. Avoid sharp bends, mechanical stress, and excessive pulling force on the coaxial cable during installation. Verify the complete probe-extension cable-proximitor assembly after installation. Confirm correct gap voltage behavior and signal output before placing the monitored machinery into operation.
$200.00 $100.00
Anda telah melihat 120 dari 693 produk
