The Woodward DTSC-200-55B is a specialized Automatic Transfer Switch (ATS) controller designed to manage power transitions between utility mains and backup generator sets. This unit provides reliable, automated switching logic, ensuring that critical loads remain powered during grid failures or instability. Built for demanding industrial environments, the DTSC-200-55B is widely utilized in sectors requiring high availability, such as telecommunications, healthcare facilities, and mission-critical data infrastructure.
Features
- Advanced three-phase voltage and frequency sensing for both utility and generator sources.
- Integrated HMI featuring a backlit LCD screen and status LEDs for immediate operational visibility.
- Programmable logic for transfer, re-transfer, and engine cool-down sequences.
- Support for Modbus RTU communication protocols for seamless integration with external SCADA or Building Management Systems (BMS).
- Robust construction designed to withstand electrical noise and harsh transient conditions.
Applications
This control panel is intended for use in automatic transfer switchgear applications where rapid and reliable power source switching is mandatory. It is suitable for oil and gas facilities, distributed power generation sites, and large-scale commercial backup power systems.
Technical Specifications
| Model |
DTSC-200-55B |
| Brand |
Woodward |
| Device Type |
ATS Control Panel |
| Display |
Backlit LCD with Status LEDs |
| Operating Temperature |
-20 to +70 deg C |
| Weight |
0.8 kg |
Installation Guidelines
- Ensure the controller is mounted in a location protected from excessive moisture and corrosive environments.
- Verify that all power sources are isolated before performing wiring connections.
- Use shielded communication cables for Modbus RTU connections to minimize electromagnetic interference (EMI).
- Maintain adequate clearance around the unit to ensure proper airflow and heat dissipation.
- Follow standard ESD (Electrostatic Discharge) precautions during handling and installation to prevent damage to internal microelectronics.
FAQ
Does the DTSC-200-55B support remote monitoring?
Yes, the unit supports Modbus RTU, which allows for integration with remote monitoring systems and building management platforms.
What is the primary function of this Woodward controller?
The DTSC-200-55B is designed to monitor utility and generator power parameters and automate the transfer process between these sources during a power failure, ensuring minimal downtime for critical loads.
