The Woodward 5417-027 is a 10-foot Netcon Low Density Analog Cable engineered for high-fidelity signal transmission within industrial control networks. Designed specifically for the Netcon series control systems, this cable provides the critical physical link between analog I/O modules and field termination assemblies. It is utilized in demanding environments such as oil refineries, gas turbine power plants, and offshore mining platforms. By ensuring electromagnetic interference (EMI) shielding and maintaining signal integrity over its 10-foot span, the 5417-027 plays a vital role in preventing signal drift and communication errors, thereby reducing unscheduled system downtime.
Features
- Optimized for precise analog voltage and current loops (4-20 mA or 0-5 VDC).
- High-grade industrial conductors with integrated shielding to protect against cross-talk and external noise.
- Secure locking connector mechanisms designed for stable contact in high-vibration turbine control environments.
- 10-foot length facilitates clean cable management within standard Netcon control racks.
Applications
This cable is intended for use in Woodward Netcon control systems, specifically for interfacing analog I/O modules with field termination points. It is suitable for mission-critical applications including gas turbine control, power generation management, and industrial process automation where signal integrity is paramount.
Technical Specifications
| Model |
5417-027 |
| Brand |
Woodward |
| Cable Type |
Netcon Low Density Analog Cable |
| Length |
10 ft (3.05 m) |
| Operating Temperature |
-40 to 85 deg C |
| Shielding |
Individual and overall braided shield |
| Connector Type |
Low-density industrial multi-pin |
Installation Guidelines
- Ensure the control system is powered down before connecting or disconnecting the cable.
- Route the cable away from high-voltage power lines and sources of significant electromagnetic interference (EMI) to maintain signal integrity.
- Ensure the locking mechanisms on the connectors are fully engaged to prevent intermittent connections due to vibration.
- Avoid sharp bends or excessive tension on the cable during installation to prevent internal conductor damage.
- Check for proper grounding of the cable shield at the designated termination points to ensure effective noise suppression.
FAQ
Is this cable compatible with other Woodward control systems?
The 5417-027 is specifically engineered for the Netcon series. Please verify your system hardware documentation to ensure compatibility with your specific I/O module and termination assembly.
What is the primary purpose of the shielding in this cable?
The shielding is designed to minimize electromagnetic interference and cross-talk, which is essential for maintaining the accuracy of sensitive analog signals (such as 4-20 mA loops) in high-noise industrial environments.
