Schneider Electric TSXMAP1074 Communication Module

Configured for industrial data exchange within Modicon TSX Series 7 PLC architectures, the Schneider Electric TSXMAP1074 (TSXMAP1074 Mapway Communication Module) provides direct physical/electrical execution for multi-protocol communication bridging across MAPWAY, Modbus RTU, and Modbus ASCII networks.

Hardware Specifications

Parameter	Specification
Model	TSXMAP1074
Brand	Schneider Electric
Origin	France
Weight	1.16 kg (2.56 lbs)
Dimensions	Not specified
Operating Temp	-20 degC to 60 degC
Storage Temp	-40 degC to 85 degC
Humidity Range	5% to 95% non-condensing
Power Consumption	Not specified
Communication Protocols	MAPWAY, Modbus RTU, Modbus ASCII
Network Interface	Ethernet
Network Role	Master/Slave
Mounting Type	DIN Rail
Protection Class	IP20
PLC Compatibility	TSX Series 7 Modular PLCs

Schneider Electric PLC Backplane and Deterministic Network Execution

The TSXMAP1074 integrates into Modicon TSX Series 7 architectures using backplane bus communication mechanisms that coordinate cyclic data exchange between communication modules and CPU racks. Ethernet-linked MAPWAY and Modbus frames are scheduled through deterministic scan cycles, ensuring bounded latency under master/slave arbitration. Firmware-level compatibility is aligned with legacy TSX rack addressing, supporting mixed-protocol routing without altering PLC task execution timing or I/O scan sequencing.

Frequently Asked Questions

Q: Does TSXMAP1074 support simultaneous MAPWAY and Modbus operation?
A: Yes. The module supports concurrent protocol handling through internal channel multiplexing, with arbitration controlled by PLC scan cycle timing.

Q: Is hot-swap supported during operation?
A: No hot-swap behavior is defined for TSX Series 7 racks. Module replacement requires power isolation of the rack backplane.

Q: What is the role of Ethernet in this module?
A: Ethernet is used as a physical transport layer for MAPWAY communication encapsulation and Modbus gateway routing within the PLC network structure.

Field Installation Guidelines

The module shall be mounted on a standard DIN rail within a TSX Series 7 rack enclosure. Ensure correct seating on the backplane connector to maintain signal integrity across communication lanes. Shielded Ethernet cabling must be grounded at a single-point earth reference to minimize loop impedance. Maintain separation between communication wiring and high-voltage conductors to reduce induced noise coupling. Verify terminal torque and rack alignment before energization.
