Honeywell TC-RPFM01 Fiber Module

Configured for ControlNet fiber-based communication interfacing in distributed industrial control networks, the Honeywell TC-RPFM01 (TCRPFM01 Fiber Module) provides direct physical/electrical execution of optical signal transmission between ControlNet nodes and system backplane interfaces. The module is designed as a discrete network media interface supporting 5 VDC backplane power and 4 A current class operation within modular automation architectures.

Suffix Breakdown & Model Matrix

The TC-RPFM01 is documented as a single orderable hardware identifier. No validated manufacturer-published suffix segmentation or functional subcode matrix is available. Internal code “TCRPFM01” is used as an alternate catalog reference.

Hardware Specifications

Parameter	Specification
Model	TC-RPFM01 / TCRPFM01
Brand	Honeywell
Origin	United States
Weight	0 lbs 4.8 oz (0.1 kg)
Dimensions	4.3 in x 4.3 in x 2.8 in (10.9 cm x 10.9 cm x 7.1 cm)
Operating Temp	Not specified
Power Consumption	5 VDC backplane, 4 A class (as stated)
Module Type	ControlNet Fiber Communication Module
Status	Discontinued by manufacturer

Fiber Communication & Channel Isolation Architecture

As part of Honeywell ControlNet-compatible architectures, the TC-RPFM01 implements optical fiber media conversion with inherent galvanic separation between network segments. The fiber interface design eliminates conductive path coupling between control nodes, providing channel-to-channel isolation at the physical transmission layer. Signal integrity is maintained through optical modulation rather than electrical continuity, reducing susceptibility to common-mode interference across distributed I/O and controller backplanes.

Frequently Asked Questions (FAQ)

Q: Can the TC-RPFM01 be hot-swapped during system operation?
A: Hot-swap capability is not explicitly documented. Removal during energized backplane operation may interrupt ControlNet segment synchronization depending on controller configuration.

Q: What is the backplane power dependency of the module?
A: The module operates on 5 VDC backplane supply with a 4 A class current requirement, depending on system load and node configuration.

Q: Does the module provide electrical isolation between network segments?
A: Yes. Optical fiber transmission inherently provides galvanic isolation between connected ControlNet segments.

Field Installation Guidelines

• Ensure backplane power is fully de-energized prior to module insertion or removal if hot-swap capability is not validated in the host system.
• Maintain fiber bend radius within manufacturer-specified limits to prevent signal attenuation.
• Clean optical connectors prior to mating to avoid insertion loss caused by particulate contamination.
• Verify ControlNet node addressing prior to commissioning to prevent network collision or token rotation faults.
• Install in grounded metallic enclosure to maintain EMC shielding integrity of surrounding I/O modules.
