The Siemens 6DS1703-8AB is a specialized MS point extension module designed for integration within the Teleperm industrial control system architecture. This printed circuit board (PCB) module serves as a critical component for expanding signal handling capabilities, specifically engineered to support 14 channels of input/output connectivity. As a legacy component of the Teleperm series, this unit is essential for maintaining and extending the operational lifespan of existing control infrastructure where specific point expansion is required.
Features
- Designed for seamless integration with Siemens Teleperm control systems.
- Provides 14 channels for multi-point signal extension.
- Compact PCB-based design for efficient rack or chassis mounting.
- Reliable performance for legacy industrial automation environments.
Technical Specifications
| Manufacturer |
Siemens |
| Model Number |
6DS1703-8AB |
| Module Type |
MS Point Extension / PCB |
| Channel Capacity |
14 Channels |
| System Compatibility |
Teleperm |
| Weight |
0.3 kg |
| Tariff Code |
8538903000 |
Installation Guidelines
- Ensure the system power is completely disconnected before inserting or removing the module from the chassis.
- Handle the PCB using proper ESD (Electrostatic Discharge) protection protocols to avoid damage to sensitive components.
- Verify that the module is correctly seated in the designated slot to ensure proper backplane communication.
- Ensure that all signal wiring is routed securely and kept away from high-voltage cables to prevent electromagnetic interference (EMI).
- Maintain adequate airflow within the cabinet to prevent thermal accumulation during operation.
FAQ
What is the primary function of the 6DS1703-8AB module?
The 6DS1703-8AB is a point extension module designed to increase the channel capacity of the Siemens Teleperm system, allowing for 14 additional signal points.
Is this module still in production?
No, this specific model has been discontinued by the manufacturer. It is typically sourced for maintenance and replacement in existing legacy systems.
What should I do if the module is not recognized by the control system?
Verify that the module is fully seated in the rack and that the physical connections are secure. If the issue persists, check the system diagnostics for specific error codes related to the slot or channel configuration.
