Description
The Schneider Electric A.F.038.5/02 is a dedicated driver board component designed for the Lexium 17D servo series. This advanced control module serves as a critical interface for motor control, providing precise current regulation and signal processing within the Lexium 17D drive architecture. It is engineered to maintain high-performance motion control standards in industrial automation applications.
Features
- Optimized for Lexium 17D servo drive systems
- High-resolution current control (12-bit)
- Supports PWM frequency of 16 kHz for efficient motor operation
- Compact design for integration into existing drive assemblies
Technical Specifications
| Product Model |
A.F.038.5/02 |
| Manufacturer |
Schneider Electric |
| DC Bus Voltage |
24 – 75 V dc |
| Continuous Output Current |
6 A rms |
| PWM Frequency |
16 kHz |
| Current Resolution |
12-bit |
| Operating Temperature |
0 degC to +45 degC |
| Storage Temperature |
-25 degC to +70 degC |
| Humidity |
5 – 95 % RH (non-condensing) |
Installation Guidelines
- Ensure the drive system is fully powered down and capacitors are discharged before attempting to install or remove the driver board.
- Handle the module using ESD-safe practices to prevent damage to sensitive electronic components.
- Verify that the board is correctly seated in the Lexium 17D chassis and that all internal connectors are securely fastened.
- Ensure the installation environment meets the specified temperature and humidity ranges to prevent thermal stress or condensation-related faults.
- Maintain proper ventilation around the drive unit to ensure heat dissipation during operation.
FAQ
What is the primary function of the A.F.038.5/02 board?
The A.F.038.5/02 is a driver board specifically for the Lexium 17D series, responsible for managing the power stage and current control signals required for servo motor operation.
Can this board be used in environments with high humidity?
The module is rated for 5 to 95% relative humidity, provided it is non-condensing. It should be installed in an enclosure that protects it from direct moisture or environmental contaminants.
