The Schneider AS8535000 is a robust high/low-density connector engineered for integration within industrial automation architectures, specifically compatible with the Modicon platform. This component facilitates reliable signal and data transmission for systems requiring up to 800 I/O points. Designed for versatility, it supports both high and low-density configurations, ensuring consistent performance in demanding industrial environments.
Features
- Designed for seamless integration with the Modicon series platform.
- Supports high and low-density I/O configurations.
- Maximum system capacity of 800 I/O points.
- Durable polycarbonate housing for industrial protection.
- Secure screw terminal interface for reliable connectivity.
Technical Specifications
| Model |
Schneider AS8535000 |
| Product Type |
High/Low Density Connector |
| Product Line |
Modicon Series |
| I/O Capacity |
800 I/O Points |
| Mounting Type |
DIN Rail |
| Housing Material |
Polycarbonate |
| Connection Interface |
Screw Terminal |
| Operating Temperature |
-20 degC to 70 degC |
| Storage Temperature |
-40 degC to 85 degC |
| Humidity Range |
5% to 95% (Non-Condensing) |
Installation Guidelines
- Ensure the control system is powered down before installing or removing the connector to prevent electrical damage.
- Mount the unit on a standard DIN rail, ensuring a secure click-in fit to maintain structural integrity.
- Verify that all screw terminals are tightened to the recommended torque to prevent loose connections and intermittent signal loss.
- Route signal cables away from high-voltage power lines and sources of electromagnetic interference (EMI) to maintain signal integrity.
- Maintain adequate ventilation around the module to ensure operating temperatures remain within the specified -20 degC to 70 degC range.
FAQ
What is the primary function of the AS8535000?
The AS8535000 serves as a high/low-density connector module for the Schneider Modicon series, designed to facilitate reliable I/O connectivity for up to 800 points.
Is this connector suitable for high-density applications?
Yes, the module is specifically engineered to handle both high and low-density I/O requirements within the Modicon platform.
What type of mounting does this module support?
The AS8535000 is designed for standard DIN rail mounting, allowing for efficient installation in industrial control cabinets.
