The ProSoft 2150-AGA is a dedicated communication interface module engineered for integration within Allen-Bradley SLC 500 rack systems. This module serves as a reliable bridge for serial connectivity, allowing the SLC backplane to communicate effectively with external peripheral devices. It is frequently deployed in legacy industrial control environments to facilitate data exchange with HMIs, SCADA systems, or other serial-based field instrumentation. By providing a stable interface, the 2150-AGA supports continued operation and data acquisition in critical infrastructure sectors including power generation and water management.
Features
- Direct backplane mounting within the SLC 500 chassis for seamless system integration.
- Supports RS-232 and RS-422 serial communication standards.
- Integrated diagnostic LEDs providing real-time status monitoring of backplane activity and serial port data traffic.
- Robust industrial construction designed for long-term reliability in high-interference environments.
- Protocol support tailored for DF1 serial interface logic, ensuring compatibility with standard industrial communication requirements.
Technical Specifications
| Model |
2150-AGA |
| Brand |
ProSoft Technology |
| Platform Compatibility |
Allen-Bradley SLC 500 |
| Product Type |
Serial Interface Module |
| Communication Ports |
RS-232 / RS-422 |
| Protocol Support |
DF1 |
| Backplane Current Load |
500 mA at 5 VDC |
| Operating Temperature |
0 to 60 deg C |
| Storage Temperature |
-40 to 85 deg C |
| Relative Humidity |
5 to 95 percent (non-condensing) |
Installation Guidelines
- Ensure the SLC 500 rack power is disconnected before installing or removing the 2150-AGA module.
- Slide the module into an available slot in the SLC 500 chassis, ensuring the backplane connector is fully seated and aligned.
- Secure the module using the built-in chassis fasteners to ensure proper grounding and mechanical stability.
- Use properly shielded serial cabling to minimize electromagnetic interference (EMI) in high-noise industrial environments.
- Verify that the serial communication settings (baud rate, parity, stop bits) on the module match the requirements of the connected external device.
FAQ
What is the primary function of the 2150-AGA module?
The 2150-AGA acts as a serial communication bridge for the SLC 500 platform, allowing the processor to exchange data with external serial devices via RS-232 or RS-422 protocols.
Is this module compatible with all SLC 500 processors?
The 2150-AGA is designed for the SLC 500 series backplane architecture; however, always verify your specific processor firmware and rack configuration to ensure compatibility with your system revision.
How is the module powered?
The module draws its operating power directly from the SLC 500 backplane, requiring 500 mA at 5 VDC.
