GE IS200WETBH1BBA Mark VI Signal Conditioning Interface Board
Configured for analog signal conditioning and interface routing in Mark VI turbine control systems, the GE IS200WETBH1BBA (IS200WETBH1BBA Signal Conditioning Interface Board) provides direct electrical execution for feedback signal conversion, isolation, and communication between CABP and BICH interface modules.
Hardware Specifications
Parameter
Specification
Model
IS200WETBH1BBA
Brand
GE
Origin
United States
Weight
0.5kg
Product Type
Signal Conditioning Interface Boards
Series
Mark VI
Analog Conversion
16-bit A/D conversion
Measurement Accuracy
0.1%
Isolation
2500 Vrms channel isolation
Interface Connection
CABP to BICH module interface
Signal Conditioning
Programmable current source with 1000 levels
Connector Type
P1/P2/P3 graded connectors
Protection Components
Metal film resistors, varistors, electrolytic capacitors
Calibration Method
Real-time calibration via GE CIMPLICITY software
Industrial Control and Mark VI Signal Interface Features
The IS200WETBH1BBA performs signal conditioning and interface conversion functions within the GE Mark VI turbine control architecture. The board processes analog feedback signals through 16-bit A/D conversion and provides electrical isolation between control logic circuits and field interface signals.
The module follows GE industrial control hardware design practices including backplane bus communication compatibility, I/O density scaling, and firmware flash compatibility within supported Mark VI system configurations. The CABP and BICH interface connection provides signal routing between controller backplane resources and gate drive related interface hardware.
The board incorporates EMI protection components and galvanic isolation methods for operation in high electrical noise environments. Signal conditioning functions include programmable current source adjustment and software-based calibration support through compatible GE control software tools.
Frequently Asked Questions
Q: What type of signal conversion is provided by the IS200WETBH1BBA? A: The board provides 16-bit analog-to-digital conversion for processed feedback signals.
Q: What isolation capability is specified for the IS200WETBH1BBA? A: The board provides up to 2500 Vrms isolation between supported signal channels.
Q: Which Mark VI interfaces are connected through this board? A: The board provides interface routing between the CABP control backplane and BICH interface modules.
Field Installation Guidelines
Install the IS200WETBH1BBA in the designated Mark VI rack position and verify connector alignment before applying power. Ensure P1, P2, and P3 connectors are installed according to the system wiring documentation.
Route analog signal cables separately from high-current switching conductors to reduce electromagnetic interference. Maintain proper shielding and grounding practices for feedback signal wiring.
Verify board compatibility with the installed Mark VI hardware configuration before commissioning. Check connector seating, signal polarity, and calibration status during system startup procedures.
