The Honeywell TK-FTEB01 51309512-175, also cataloged as the TK-FTEB01 Fault Tolerant Ethernet Bridge Module, operates as a dedicated hardware component for Ethernet communication execution within the Honeywell Experion PKS FTE network.
Hardware Specifications
Parameter
Specification
Model
TK-FTEB01 51309512-175
Brand
Honeywell
Product Type
Fault Tolerant Ethernet Bridge Module
System Platform
Honeywell Experion PKS
Origin
USA
Weight
0.3 kg
Dimensions
3.5 x 13.8 x 14.5 cm
Operating Temp
Not specified
Power Consumption
24 VDC input, 5 A continuous output current capability
Communication Interface
Fault Tolerant Ethernet (FTE)
Network Standard
IEEE 802.3 Ethernet
Data Rate
100 Mbps
Installation Type
Series-A chassis module
Chassis Occupancy
2 chassis slots
Battery Capacity
7.0 Ah / 175 Wh typical
Backup Duration
Up to 4-8 hours
FTE Network Communication and DCS Integration
The TK-FTEB01 provides Ethernet communication between Experion PKS Servers, C200 controllers, and Fieldbus Interface Module (FIM) chassis. It installs into the Series-A chassis and connects control-level devices with the supervisory network through the Honeywell Fault Tolerant Ethernet architecture.
Furthermore, the module supports IEEE 802.3 Ethernet communication at 100 Mbps and manages network data exchange between redundant control components. The hardware design allows integration with Experion PKS systems requiring Ethernet-based controller communication and chassis-level networking.
The Honeywell FTE architecture uses redundant network paths to maintain communication availability during a single network path interruption. Therefore, the TK-FTEB01 operates as an Ethernet interface component for distributed control communication structures.
FOUNDATION Fieldbus and Process Network Interface Compatibility
For Honeywell process control platforms, network interface modules commonly support industrial communication environments including FOUNDATION Fieldbus and Profibus PA connectivity through compatible system components. The TK-FTEB01 focuses on Ethernet communication and provides the physical network interface required for Experion PKS control chassis communication.
The module does not directly process 4-20 mA HART signals or field analog measurements. Instead, it transfers digital communication traffic between control processors and higher-level system nodes through the FTE network.
Frequently Asked Questions
Q: What communication protocol does the TK-FTEB01 support? A: The TK-FTEB01 supports Honeywell Fault Tolerant Ethernet communication based on IEEE 802.3 Ethernet at 100 Mbps.
Q: How many chassis slots does the TK-FTEB01 occupy? A: The TK-FTEB01 occupies two slots in a Honeywell Series-A chassis configuration.
Q: What power input does the module require? A: The module requires a 24 VDC power input and provides a maximum continuous output current specification of 5 A.
Field Installation Guidelines
Install the TK-FTEB01 only in the designated Honeywell Series-A chassis slot positions according to system configuration requirements.
Verify the 24 VDC power supply polarity before connecting field wiring.
Use shielded Ethernet cabling where required by the installation environment and connect cable shields according to site grounding standards.
Maintain separation between Ethernet communication cables and high-voltage power wiring to reduce electrical interference.
Confirm FTE network redundancy connections before placing the controller network into operation.
Check chassis seating, connector engagement, and module status indicators after installation.
Follow Honeywell Experion PKS hardware manuals for firmware compatibility and system commissioning procedures.
