Honeywell TC-FPCXX2 Power Supply
The Honeywell TC-FPCXX2, also cataloged as the TC-FPCXX2 Power Supply, operates as a dedicated hardware component for AC power conversion and electrical supply distribution within Honeywell control system platforms.
Hardware Specifications
| Parameter |
Specification |
| Model |
TC-FPCXX2 |
| Brand |
Honeywell |
| Product Type |
Power Supply |
| Origin |
USA |
| Weight |
0.98 kg |
| Dimensions |
11 x 14.2 x 13.8 cm estimated shipping size |
| Operating Temp |
Maximum output rating at 60 deg C |
| Power Consumption |
Input power 150 VA, 92 W |
| Input Voltage Range |
85-132 VAC or 170-265 VAC |
| Frequency Range |
47-63 Hz |
| Maximum Inrush Current |
15 A |
| Total Power Output |
70 W maximum at 60 deg C |
| Fuse Protection |
Four non-replaceable soldered fuses |
| Wiring Specification |
#14 AWG (1.4 mm) |
| Tariff Code |
8537101190 |
| Place of Shipment |
Xiamen, China |
Process Control Power Conversion Characteristics
The Honeywell TC-FPCXX2 provides regulated AC input power conversion for Honeywell process control hardware assemblies. Moreover, the module accepts dual-range AC input voltage conditions, allowing integration into different industrial power distribution environments.
The power supply supports electrical isolation and controlled output delivery through internal protection components. In addition, the four soldered non-replaceable fuses protect internal circuits against abnormal current conditions during operation.
For Honeywell control architectures, power supply modules maintain stable electrical availability for connected hardware. Therefore, installation requires correct voltage selection, appropriate wiring practices, and compliance with system grounding requirements.
Frequently Asked Questions
Q: What AC input voltage ranges does the Honeywell TC-FPCXX2 support?
A: The TC-FPCXX2 supports an input voltage range of 85-132 VAC or 170-265 VAC with a frequency range of 47-63 Hz.
Q: Does the TC-FPCXX2 use replaceable fuses?
A: No. The module contains four non-replaceable fuses that are soldered directly in place.
Q: What wiring specification is required for the TC-FPCXX2 power connection?
A: The module specifies #14 AWG (1.4 mm) wiring for electrical connections.
Field Installation Guidelines
Install the TC-FPCXX2 in a clean industrial enclosure with sufficient airflow around the power supply assembly. Verify the selected AC input voltage range before energizing the module.
Use wiring that matches the specified connection requirements and maintain proper separation between AC power lines and low-level signal cables. Furthermore, connect protective grounding according to the control cabinet electrical design.
Inspect terminal connections for mechanical tightness before startup. Avoid modifying internal fuse components because the protection devices are factory-installed and soldered.
