Keterangan
Honeywell TC-FPCXX2 Power Supply
Configured for AC power conversion and regulated supply distribution in Honeywell control hardware platforms, the Honeywell TC-FPCXX2 (TC-FPCXX2 Power Supply) provides direct physical/electrical execution for system power input and output regulation.
Hardware Specifications
Parameter
Specification
Model
TC-FPCXX2
Brand
Honeywell
Product Type
Power Supply
Origin
USA
Weight
0.98 kg
Dimensions
11 x 14.2 x 13.8 cm
Operating Temp
0 deg C to 60 deg C
Power Consumption
95 W input, 92 W rated input power
Input Voltage Range
85-132 VAC or 170-265 VAC
Input Frequency Range
47-63 Hz
Input Power Rating
150 VA
Maximum Inrush Current
15 A
Total Power Output
Maximum 70 W at 60 deg C
Fuse Protection
4 non-replaceable soldered fuses
Wiring Requirement
#14 AWG (1.4 mm)
Input Configuration
AC input, 120/240 VAC selectable range
System Frequency
50/60 Hz
Process Control Power Distribution Characteristics
The TC-FPCXX2 provides AC input conversion and regulated power delivery for Honeywell control system hardware. The power supply accepts dual-range AC input levels and maintains a controlled output capacity for connected modules.
Moreover, Honeywell power supply hardware is designed for integration with process control platforms where stable electrical distribution supports controller, I/O, and interface module operation. The unit uses fixed fuse protection and defined wiring specifications to maintain circuit protection during operation.
The module operates as a dedicated electrical component rather than a signal processing device. Therefore, installation focuses on AC input compatibility, load calculation, grounding practices, and cabinet power segregation.
Frequently Asked Questions
Q: What AC input voltage ranges does the TC-FPCXX2 support? A: The TC-FPCXX2 supports 85-132 VAC and 170-265 VAC input ranges with 47-63 Hz operating frequency.
Q: Does the TC-FPCXX2 use replaceable fuses? A: No. The module contains 4 non-replaceable fuses soldered directly on the power supply assembly.
Q: What is the maximum output capability of the TC-FPCXX2? A: The power supply provides a maximum total output of 70 W at 60 deg C operating conditions.
Field Installation Guidelines
Install the TC-FPCXX2 inside a compatible control cabinet with appropriate AC power isolation before wiring operations.
Verify that the incoming AC voltage matches the specified input range before energizing the module. Use the recommended wire size and maintain separation between AC power wiring and low-level signal cables.
Connect protective grounding according to the cabinet grounding design. Avoid routing power conductors near communication or analog measurement circuits to reduce electrical interference.
Confirm the connected load remains within the power supply output rating before system startup. Inspect fuse status and terminal connections during routine maintenance activities.
