Honeywell TC-CCN012 ControlNet Interface Module
The Honeywell TC-CCN012, also cataloged as the TC-CCN012 ControlNet Interface Module, operates as a dedicated hardware component for single-media ControlNet communication within Honeywell C200 controller platforms.
Hardware Specifications
Parameter
Specification
Model
TC-CCN012
Brand
Honeywell
Product Type
ControlNet Interface Module
Function
Single Media ControlNet Interface
Communication Network
ControlNet
Media Type
Single Media
Controller Compatibility
Honeywell C200 Controller Platform
Origin
USA
Weight
Approximately 0.25 kg
Dimensions
2.2 cm x 12.4 cm x 12.6 cm
Operating Temp
-40 deg C to +70 deg C
Storage Temp
-40 deg C to +85 deg C
Relative Humidity
0% to 95% RH, non-condensing
Power Supply
24 VDC
Power Consumption
Less than 5 W
Mounting Type
Control System Rack Installation
Network Interface
ControlNet Single Media Connection
Product Status
Discontinued / Replaced by newer models
Process Control Network Communication Interface
The Honeywell TC-CCN012 provides ControlNet network access between the Honeywell C200 controller platform and connected industrial communication nodes. The module processes network data exchange through the ControlNet architecture and supports controller-to-device communication within configured control racks.
For Honeywell process control installations, the communication design typically separates field measurement channels from controller network functions. However, the TC-CCN012 itself functions as a network interface device and does not provide analog input, analog output, HART loop processing, FOUNDATION Fieldbus, Profibus PA connectivity, or cold junction compensation (CJC) functions.
The module supports rack-based installation and integrates with Honeywell control system hardware through the defined controller communication structure. Network cable routing, termination, and grounding practices must follow the ControlNet installation requirements.
Frequently Asked Questions
Q: What communication function does the Honeywell TC-CCN012 provide? A: The TC-CCN012 provides a single-media ControlNet communication interface for data exchange between Honeywell C200 controller systems and connected network devices.
Q: Does the TC-CCN012 provide field signal processing functions? A: No. The TC-CCN012 is a communication interface module and does not perform analog measurement, 4-20 mA HART processing, or digital field I/O signal conversion.
Q: Can the TC-CCN012 be installed in any Honeywell control rack? A: Installation requires compatibility with the supported Honeywell C200 controller rack configuration and the corresponding ControlNet network architecture.
Field Installation Guidelines
Verify that the control rack configuration supports the TC-CCN012 module before installation.
Confirm the availability of the required 24 VDC power supply connection.
Install ControlNet cables according to network topology and termination requirements.
Maintain separation between communication cables and high-voltage power wiring to reduce electrical interference.
Connect cable shields and grounding points according to Honeywell control system installation practices.
Check controller configuration parameters after installation to confirm network communication status.
