Honeywell MC-PLAM02 51304362-150 Low Level Analog Multiplexer Processor

The Honeywell MC-PLAM02 51304362-150, also cataloged as the MC-PLAM02 Low Level Analog Multiplexer Processor, operates as a dedicated hardware component for low level analog signal acquisition within Honeywell Process Manager and Experion PKS I/O systems. This 32 input LLMux IOP performs analog input scanning and multiplexing functions with configurable line frequency synchronization.

Hardware Specifications

Parameter	Specification
Model	MC-PLAM02 51304362-150
Brand	Honeywell
Product Type	Low Level Analog Multiplexer Processor
IOP Type	Low Level Multiplexer (LLMux)
Input Channels	32 Inputs
Input Scan Rate	32 samples per second
Input Impedance	2 MOhm minimum at 100 mV
Crosstalk, DC to 60 Hz	120 dB
Line Frequency Synchronization	Configurable to 50 Hz or 60 Hz
Software Only Accuracy	+/- 0.1 deg C typical, +/- 0.5 deg C maximum at 23.5 deg C +/- 2 deg C
Origin	USA
Weight	0.6 kg
Dimensions	Estimated shipping size: 3 x 31.8 x 28 cm
Tariff Code	8537101190
Product Configuration	LLMux IOP conformally coated

Process Control Signal Multiplexing Characteristics

The Honeywell MC-PLAM02 51304362-150 processes low level analog inputs through a multiplexing architecture designed for precise signal measurement. The module scans 32 analog input channels at 32 samples per second and provides high input impedance for low voltage signal sources.

The module provides 120 dB crosstalk suppression from DC to 60 Hz, which reduces interference between adjacent analog input channels. In addition, configurable 50 Hz or 60 Hz line frequency synchronization allows operation in different electrical environments.

For Honeywell process control systems, the module architecture supports analog measurement applications where signal integrity, channel separation, and stable acquisition are required. The LLMux design focuses on direct analog signal routing before controller-level processing.

Frequently Asked Questions

Q: What type of signals does the Honeywell MC-PLAM02 51304362-150 process?
A: The MC-PLAM02 is designed for low level analog input multiplexing. It handles 32 analog input channels through the Low Level Multiplexer IOP architecture.

Q: Does the MC-PLAM02 support configurable power frequency synchronization?
A: Yes. The module supports configurable synchronization settings for 50 Hz or 60 Hz line frequency environments.

Q: How does the module reduce interference between input channels?
A: The module provides 120 dB crosstalk performance from DC to 60 Hz to minimize signal coupling between multiplexed analog input channels.

Field Installation Guidelines

• Install the MC-PLAM02 module according to Honeywell I/O cabinet configuration requirements and approved hardware installation procedures.
• Verify the module slot assignment before connecting field wiring to prevent incorrect channel mapping.
• Use shielded signal wiring for low level analog inputs and terminate shields according to the plant grounding standard.
• Keep analog signal cables separated from high voltage power wiring and switching circuits to reduce electrical interference.
• Confirm connector seating and mechanical retention before system power application.
• Validate input channel assignments through system configuration software after installation.
• Check grounding continuity and cabinet environmental conditions before placing the module into operational service.
