Keterangan
Honeywell CC-HCN911 Series C Control Module
The Honeywell CC-HCN911 51307206-175, also cataloged as the 51307206-175 Series C Control Module, operates as a dedicated hardware component for control signal processing and module-level execution within Honeywell Series C control system platforms.
Hardware Specifications
Parameter
Specification
Model
CC-HCN911 51307206-175
Brand
Honeywell
Product Type
Series C Control Module
Origin
USA
Weight
0.44 kg
Dimensions
6.1 x 16.2 x 14.6 cm
Operating Temp
-20 deg C to +70 deg C
Power Consumption
10 W output power
Operating Voltage
24 VDC
Input Current
1.5 A
Output Frequency
1 kHz
Humidity Range
5% to 95% non-condensing
Tariff Code
8537101190
HART Loop and DCS Signal Interface Characteristics
The Honeywell CC-HCN911 Series C Control Module is designed for integration within Honeywell process control architectures. The module operates with a 24 VDC supply and provides hardware-level control execution functions for Series C systems.
For Honeywell DCS environments, module integration principles include compatibility with process instrumentation signal architectures such as 4-20 mA HART loop protocol, FOUNDATION Fieldbus / Profibus PA connectivity, and channel-to-channel isolation requirements where applicable. These interface characteristics support structured field signal acquisition, conditioning, and controller communication within distributed control configurations.
Frequently Asked Questions
Q: What is the operating power requirement of the CC-HCN911 module? A: The module operates with a 24 VDC supply input and has an input current specification of 1.5 A. The listed output power rating is 10 W.
Q: Can the CC-HCN911 be installed in environments with high temperature variation? A: The specified operating temperature range is -20 deg C to +70 deg C. Installation should maintain proper enclosure protection and environmental control according to system requirements.
Q: What installation considerations apply for this Series C Control Module? A: Installation should follow Honeywell Series C system hardware guidelines, including correct backplane connection, proper grounding, signal cable separation, and compliance with applicable cabinet wiring practices.
Field Installation Guidelines
Install the module in the designated Honeywell Series C hardware rack or control assembly using the specified mounting interface.
Verify that the 24 VDC power supply wiring polarity and grounding arrangement comply with system requirements before energizing the module.
Maintain separation between power wiring and low-level instrumentation signal cables to reduce electrical interference.
Use appropriate shield termination methods for connected field signal wiring where required by the control system design.
Confirm backplane connections are fully seated before system startup and perform module status verification through the host control environment.
