GE IS220PAOCH1A Mark VIe Analog Output I/O Module

Configured for actuator current signal generation in the GE Mark VIe Turbine Control System, the GE IS220PAOCH1A (IS220PAOCH1A Analog Output I/O Module) provides direct physical/electrical execution through eight isolated 0-20 mA output channels with digital conversion and current feedback monitoring.

Hardware Specifications

Parameter	Specification
Model	IS220PAOCH1A
Brand	GE
Origin	United States
Weight	0.5 kg
Dimensions	8.26 cm high x 4.19 cm wide x 12.1 cm
Operating Temp	-30 to 65 deg C
Power Consumption	Approx. 10-15 W depending on load
Product Type	Analog Output I/O Module
Series	Mark VIe
Output Channels	8 independent current output channels
Analog Output Range	0-20 mA
Load Capacity	Up to 900 ohm per channel
Compliance Voltage	18 V
Digital Conversion	16-bit DAC with 16-bit ADC feedback
Accuracy	+/-0.5% over -30 to 65 deg C
Communication Interface	Dual 10/100Base-TX Ethernet ports
Processor	BPPB processor board with dedicated AO hardware
Power Supply	27.4-28 V DC nominal
Isolation	Reinforced galvanic isolation, 2500 Vrms
Connectors	Dual RJ-45 Ethernet, DC-37 pin terminal board, 3-pin power
Protection Rating	IP51 enclosure, conformal coating
Certifications	Class I Div 2 / ATEX Zone 2

Deterministic Ethernet and I/O Density Scaling Characteristics

The IS220PAOCH1A operates within the GE Mark VIe control architecture using dual Ethernet communication paths for controller data exchange. The module receives digital output commands and converts them into isolated analog current signals through eight dedicated output channels.

The 16-bit DAC output stage and ADC-based current feedback circuit provide closed-loop verification of actual output current values. The module incorporates I/O density scaling through multi-channel analog output processing, allowing multiple actuator command loops to be managed within a single Mark VIe I/O package.

The BPPB processor performs internal diagnostics including RAM, flash memory, processor status, and Ethernet communication checks. Firmware compatibility is managed according to the installed Mark VIe system configuration.

Frequently Asked Questions

Q: What type of output signals are generated by the IS220PAOCH1A?
A: The module provides eight isolated 0-20 mA analog current outputs for actuator control applications.

Q: Does the module support hot installation?
A: The module includes a soft-start circuit designed to support hot-plugging within compatible Mark VIe hardware configurations. Installation procedures must follow system maintenance requirements.

Q: How is output accuracy maintained during operation?
A: The module uses 16-bit DAC conversion with ADC current feedback sensing to monitor actual loop output values.

Field Installation Guidelines

Install the IS220PAOCH1A in the designated Mark VIe I/O carrier position and verify correct mechanical seating before system operation.

Connect output wiring according to the applicable terminal board documentation. Use shielded signal cables for analog current loops where required and terminate shields according to site grounding practices.

Route analog output wiring separately from high-current switching conductors and excitation power cables to reduce electromagnetic interference. Verify channel assignment, loop polarity, and actuator input compatibility before commissioning.

Confirm Ethernet connections, terminal board compatibility, and controller configuration before applying system power. Perform output loop verification using appropriate measurement equipment after installation.
