GE IS200WCSAS1ADB Servo Amplifier Board

The GE IS200WCSAS1ADB, also cataloged as the IS200WCSAS1ADB Servo Amplifier Board, operates as a dedicated hardware component for servo actuator signal amplification within GE Mark VIe wind turbine control system platforms. It converts analog command signals into controlled servo motor drive outputs for pitch and yaw mechanisms.

Hardware Specifications

Parameter	Specification
Model	IS200WCSAS1ADB
Brand	GE
Origin	United States
Weight	0.6 kg
Dimensions	150 mm x 180 mm x 95 mm
Operating Temp	-40 deg C to +70 deg C
Power Consumption	Not specified in available technical data
Product Type	Servo Amplifier Boards
Series	GE Mark VIe Wind Turbine Control System
Functional Type	WCSA Wind Control Servo Amplifier Board
Servo Outputs	4 independent channels
Output Voltage	+/-15 VDC
Output Current	Up to 2 A per channel
Control Input	+/-10 V analog command
Resolution	12-bit DAC
Accuracy	+/-0.1% of full scale
Isolation	Channel-to-channel and channel-to-ground isolation
Power Supply	24 VDC from backplane
Storage Temperature	-40 deg C to +85 deg C
Humidity Range	5%-95% non-condensing
Status Indicators	Power, Fault, and Channel Activity LEDs

GE Mark VIe Servo Control Characteristics

The IS200WCSAS1ADB applies GE Mark VIe industrial control architecture for closed-loop servo actuator control. The board receives analog command signals and provides amplified drive outputs for servo motor positioning applications including blade pitch and yaw control.

The module incorporates GE control platform features including deterministic network behavior through the Mark VIe control architecture, I/O density scaling for multi-channel actuator control, and firmware flash compatibility with the configured controller revision.

The servo output section provides four independent channels with isolated output paths. The analog command interface and DAC conversion function allow the controller to execute proportional actuator positioning based on configured control algorithms.

Frequently Asked Questions

Q: How many servo output channels are available on the IS200WCSAS1ADB?
A: The board provides four independent servo output channels.

Q: What type of input command signal does the module accept?
A: The module accepts +/-10 V analog command signals for servo control execution.

Q: Is channel isolation provided between servo outputs?
A: Yes. The available specifications indicate channel-to-channel and channel-to-ground isolation.

Field Installation Guidelines

Install the IS200WCSAS1ADB into the designated GE Mark VIe rack position and verify correct mechanical seating before applying power. Connect servo actuator wiring through the specified terminal block connections.

Use shielded cables for analog command and servo output wiring where required by the system grounding design. Route actuator cables separately from high-current switching circuits to reduce electrical interference.

Configure servo parameters and calibration settings through ToolboxST software. Verify LED status indicators and perform actuator response checks after installation.
