GE IS200VPWRH1AHD Redundant Power Supply Module

Configured for redundant DC power conversion in GE Mark VI turbine control systems, the GE IS200VPWRH1AHD (IS200VPWRH1AHD Redundant Power Supply Module) provides direct electrical power execution for control modules, I/O boards, and communication interfaces.

Hardware Specifications

Parameter	Specification
Model	IS200VPWRH1AHD
Brand	GE
Origin	United States of America
Weight	1.2 kg
Dimensions	200 x 160 x 80 mm
Operating Temp	-20 deg C to +65 deg C
Power Consumption	24 VDC output: 10 A; 5 VDC output: 3 A
Product Type	Redundant Power Supply Modules
System Platform	GE Speedtronic Mark VI Turbine Control System
Input Voltage	120/240 VAC, 50/60 Hz, dual isolated inputs
Output Voltage	24 VDC +/-2% main output, 5 VDC +/-2% auxiliary output
Efficiency	>=85% at full load
Protection Features	Overvoltage, overcurrent, short-circuit, overtemperature protection
Mounting Method	35 mm DIN rail mounting
Certifications	UL 508, CE, IEC 61010-1

Backplane Bus Communication and Power Architecture

The IS200VPWRH1AHD integrates into the GE Mark VI control architecture as a redundant DC power source for controller assemblies and I/O hardware. The module converts dual 120/240 VAC inputs into regulated 24 VDC and 5 VDC outputs for connected control electronics.

The power module supports dual input redundancy with automatic source transfer functions. The design incorporates electrical protection circuits to isolate abnormal conditions and maintain stable power delivery to connected modules. Compatibility with Mark VI rack power distribution allows integration with turbine control cabinets requiring coordinated power management.

Frequently Asked Questions

Q: What output voltages are provided by the IS200VPWRH1AHD?
A: The module provides regulated 24 VDC and 5 VDC outputs for GE Mark VI control modules, I/O boards, and communication assemblies.

Q: Does the IS200VPWRH1AHD support redundant input operation?
A: Yes. The module uses dual isolated AC input channels to support redundant power source configurations.

Q: What protection functions are included in the power module?
A: The module includes overvoltage, overcurrent, short-circuit, and overtemperature protection circuits.

Field Installation Guidelines

Install the IS200VPWRH1AHD on the specified DIN rail location with sufficient mechanical retention and proper airflow clearance around the module enclosure. Verify AC input wiring polarity, voltage range, and grounding connections before energizing the power supply.

Route AC power cables separately from low-level signal wiring to reduce electromagnetic interference. Ensure protective earth connections follow cabinet grounding practices and that output DC wiring is correctly assigned to the connected Mark VI control modules.

Before replacement or maintenance, isolate incoming power sources according to site electrical procedures. Confirm output voltage levels and module status indicators after installation through the approved GE control system diagnostics.

Spesifikasi

• Merek: General Electric
•
  :


Keuntungan

• Keandalan tinggi di lingkungan industri


• Mendukung operasi berkelanjutan
• Kompatibel dengan sistem PLC/DCS utama
