Keterangan
GE IS200VAICH1CBR Analog Input Module
The GE IS200VAICH1CBR, also cataloged as the IS200VAICH1CBR Analog Input Module, operates as a dedicated hardware component for analog signal acquisition within the GE Mark VI Turbine Control System. The module provides electrical input processing for turbine monitoring and control functions across VME-based control platforms.
Hardware Specifications
Parameter
Specification
Model
IS200VAICH1CBR
Brand
GE Fanuc
Origin
United States
Weight
0.3 kg
Dimensions
12 cm (W) x 15.3 cm (H) x 6.8 cm (D)
Operating Temp
-40 deg C to +85 deg C
Power Consumption
Not specified in available technical data
Module Type
Analog Input Module / VME Card
System Platform
Mark VI Turbine Control System
Functional Acronym
VAIC
Functional Revision
C
Processor
AMD Ryzen Embedded V1000 family
Memory
Up to 8 GB DDR4
Storage
64 GB eMMC
PCB Construction
Conformal coating
Certification
IEC 61508 compliant, SIL 3 certified
Firmware Flash Compatibility and I/O Processing Architecture
The GE IS200VAICH1CBR module operates within the Mark VI control architecture as an analog signal processing interface. Firmware compatibility defines the operational interaction between the module hardware, control application configuration, and VME communication environment. The conformal-coated PCB design supports operation in industrial turbine control installations where protection against environmental contamination is required.
The module provides analog input acquisition for turbine control loops, converting field-level analog signals into processed data values used by Mark VI control logic. The analog input density and scaling parameters are managed through system configuration rather than local user adjustment.
Frequently Asked Questions
Q: Is the IS200VAICH1CBR designed for hot-swap operation? A: The available technical data does not specify hot-swap capability. Installation and removal should follow Mark VI rack power isolation procedures.
Q: What type of signal processing function does the module provide? A: The module performs analog input acquisition and processing for turbine monitoring and control applications within the Mark VI system.
Q: What environmental protection feature is included on the circuit board? A: The module uses conformal coating on the PCB to provide additional protection against industrial environmental conditions.
Field Installation Guidelines
Verify that the VME rack power supply is isolated before module insertion or removal.
Install the module according to the Mark VI rack slot configuration and system hardware documentation.
Maintain proper field wiring separation between analog signal cables and high-voltage power conductors.
Use appropriate shielding and grounding practices for analog input wiring to reduce electrical interference.
Confirm connector seating and mechanical retention before restoring rack power.
Validate module recognition and input channel operation through the turbine control configuration tools after installation.
