GE IS200TRLYS1BGG Relay Output Terminal Board
The GE IS200TRLYS1BGG, also cataloged as the IS200TRLYS1B Relay Output Terminal Board, operates as a dedicated hardware component for relay signal switching and external device control within GE Mark VI and Mark VIe Speedtronic control systems. It provides isolated relay outputs for actuators, alarms, trip circuits, and auxiliary equipment interfaces.
Hardware Specifications
Parameter
Specification
Model
IS200TRLYS1BGG
Brand
GE
Origin
United States
Weight
0.8 kg
Dimensions
220 mm x 160 mm x 50 mm
Operating Temp
-40 deg C to +70 deg C
Power Consumption
Not specified in available data
Product Type
Relay Output Terminal Board
System Compatibility
GE Mark VI / Mark VIe Speedtronic Control Systems
Relay Channels
12-16 independent Form C (SPDT) relay outputs depending on revision
Relay Type
Magnetic plug-in relays with transparent protective covers
Contact Rating
Up to 5 A at 250 VAC resistive load; 2 A at 30 VDC
Switching Voltage
125 VDC nominal; 250 VAC maximum
Coil Voltage
24 VDC with coil diagnostics enabled
Response Time
<=10 ms activation; <=5 ms release
Isolation
Optical and physical relay isolation; channel-to-channel withstand >=500 V RMS
Circuit Protection
MOV surge suppression per channel
Hardware Filtering
Approx. 2 ms switching filter
Certifications
UL/cUL Class I Div 2, IEC 61010, ATEX Zone 2
GE Mark VIe Relay Output Isolation and Control Interface
The IS200TRLYS1BGG provides relay-based output execution within GE turbine control architectures by converting controller commands into isolated electrical switching signals. The terminal board supports relay outputs for trip circuits, solenoids, alarms, and auxiliary equipment control.
The relay output architecture supports simplex, dual, and TMR system configurations. The board incorporates channel-level diagnostics for coil condition monitoring, contact status evaluation, and voltage verification. Communication of diagnostic information is performed through GE ToolboxST configuration and maintenance software.
The board uses firmware flash compatibility and Mark VIe hardware identification procedures to maintain correct configuration matching between terminal boards and controller assemblies. MOV-based surge suppression and relay isolation structures provide switching protection against transient electrical disturbances.
The relay interface supports deterministic output execution within GE Speedtronic systems, while the isolated relay channels provide separation between controller logic circuits and external field devices.
Frequently Asked Questions
Q: What type of relay outputs are provided by the IS200TRLYS1BGG? A: The terminal board provides independent Form C (SPDT) magnetic relay outputs for switching external field devices.
Q: Does the terminal board support redundant control configurations? A: Yes. The IS200TRLYS1BGG supports simplex, dual, and TMR configurations within compatible Mark VI and Mark VIe architectures.
Q: How are relay output circuits protected from electrical transients? A: Each relay channel includes MOV surge suppression components to reduce transient voltage effects during switching operations.
Field Installation Guidelines
Install the IS200TRLYS1BGG according to GE Mark VI or Mark VIe cabinet installation procedures. Verify terminal board connector placement, relay module seating, and field wiring termination before applying power.
Use appropriate field wiring separation between relay output circuits and low-level signal cables. Maintain shield grounding practices according to the cabinet grounding design and avoid routing relay conductors adjacent to sensitive analog communication wiring.
Confirm relay contact ratings match the connected external load characteristics before commissioning. Verify coil voltage configuration, diagnostic settings, and ToolboxST hardware identification data before placing the control system into operation.
