GE IS200TBAIS1CED Analog Input/Output Terminal Board

Configured for analog field signal interfacing in GE Mark VIe control architecture, the GE IS200TBAIS1CED (IS200TBAIS1C Analog Input/Output Terminal Board) provides direct physical/electrical execution between field wiring and controller I/O processors through conditioned analog input and output channels.

Hardware Specifications

Parameter	Specification
Model	IS200TBAIS1CED
Brand	GE
Origin	United States
Weight	1 kg
Dimensions	10.16 cm (W) x 33.02 cm (H)
Operating Temp	-30 deg C to +65 deg C
Power Consumption	Not specified in available data
Product Type	Analog Input/Output Terminal Board
System Compatibility	GE Mark VIe Control Architecture
Configuration	Simplex and Triple Modular Redundant (TMR) configurations
Connectors	3 x DC-37 pin connectors
Signal Handling	Analog input signal distribution across R, S, T processors in TMR mode
Output Regulation	TMR driver current aggregation through precision shunt
Diagnostics	Onboard ID chip with serial number, revision, and connector information
Input Configuration	Current/voltage input selection through jumper settings
Input Ranges	Configurable 1 mA or 20 mA input ranges
Safety Compatibility	Mark VIeS SIS compliant

GE Mark VIe TMR Analog Signal Processing and Hardware Compatibility

The IS200TBAIS1CED terminal board supports GE Mark VIe distributed control signal architecture by providing analog field termination, signal conditioning, and processor interface functions. In TMR configurations, the board distributes analog input signals to the R, S, and T controller processors to maintain synchronized data acquisition.

The board uses GE firmware flash compatibility and onboard identification hardware to verify terminal board configuration data, including serial information, revision status, and connector assignments. This ID-based verification supports correct hardware recognition during Mark VIe system configuration.

The terminal board provides I/O density scaling within the Mark VIe platform by allowing multiple analog channels to interface with controller processors while maintaining defined signal routing and diagnostic monitoring. Output current monitoring functions detect hardware compatibility conditions and verify output circuit behavior.

Frequently Asked Questions

Q: What configuration modes are supported by the IS200TBAIS1CED terminal board?
A: The terminal board supports Simplex configuration through the JR1 connector and TMR configuration using JR, JS, and JT connectors.

Q: How does the board identify its hardware configuration?
A: An onboard ID chip stores serial number, revision information, and connector data for hardware identification and compatibility checking.

Q: What analog signal settings can be adjusted on the terminal board?
A: Jumper settings allow configuration of current or voltage input selection, return link options, and supported input ranges including 1 mA and 20 mA settings.

Field Installation Guidelines

Install the IS200TBAIS1CED according to GE Mark VIe panel assembly procedures. Confirm terminal board orientation, connector engagement, and field wiring termination before applying control power.

Use shielded instrumentation wiring for analog signal connections where required by the system grounding design. Connect cable shields according to the Mark VIe cabinet grounding scheme and separate low-level analog wiring from high-current switching conductors.

Verify jumper positions for current/voltage selection and input range configuration before commissioning. Confirm that connector assignments match the configured Simplex or TMR architecture to prevent signal routing errors.
