Keterangan
GE IS200REBFH1ACA Positive Logic Output Module
The GE IS200REBFH1ACA, also cataloged as the IS200REBFH1ACA Positive Logic Output Module, operates as a dedicated hardware component for discrete output execution within GE Series 90-30 PLC and Mark VIe control platforms. The module provides 32 isolated output channels for field device switching and industrial control signal distribution.
Hardware Specifications
Parameter
Specification
Model
IS200REBFH1ACA
Brand
GE
Origin
USA
Weight
0.3 kg
Dimensions
224 x 88 x 100 mm
Operating Temp
Not specified
Power Consumption
Not specified
Product Type
Positive Logic Output Module
Series
GE Series 90-30 PLC / Mark VIe
Voltage Range
12/24 VDC
Number of Outputs
32 discrete outputs
Output Configuration
4 isolated groups of 8 outputs
Output Current
0.5 A per point
Mounting Type
Rack-mounted in Series 90-30 PLC chassis
Protection
Overcurrent and short-circuit protection
I/O Density Scaling and Discrete Control Processing
The IS200REBFH1ACA provides digital output expansion through 32 positive logic channels arranged into four isolated groups. The isolated grouping structure supports I/O density scaling by allowing multiple field circuits to be controlled from a single module while maintaining electrical separation between output groups.
The module interfaces with GE control architectures through rack-mounted integration and executes discrete switching commands from the controller. Output protection functions monitor abnormal conditions such as overcurrent and short-circuit events to support diagnostic evaluation within the control system.
Frequently Asked Questions
Q: How are the outputs organized on the IS200REBFH1ACA? A: The module contains 32 discrete outputs arranged as four isolated groups of eight channels.
Q: What voltage range is supported by the output circuits? A: The module supports 12/24 VDC output circuits with a rated current of 0.5 A per output point.
Q: Which control platforms are associated with this module? A: The IS200REBFH1ACA is designed for integration with GE Series 90-30 PLC chassis and Mark VIe industrial control platforms.
Field Installation Guidelines
Install the IS200REBFH1ACA in the specified GE PLC rack position and verify chassis alignment before applying power. Confirm output channel assignments and field wiring connections according to the system configuration documentation.
Route discrete output cables separately from high-voltage power conductors and sensitive communication wiring where practical. Maintain proper cabinet grounding and use appropriate shielding methods for the installation environment.
After installation, verify each isolated output group, check controller diagnostics, and perform functional testing of connected field devices before placing the system into normal operation.
