GE IS200AEPAH1BPR5 Analog Expansion Power Amplifier Board

Configured for amplified actuator signal execution in GE Mark VIe Speedtronic control systems, the GE IS200AEPAH1BPR5 (IS200AEPAH1BPR5 Analog Expansion Power Amplifier Board) provides direct physical/electrical execution for high-current analog output control of proportional valves and field actuators.

Hardware Specifications

Parameter	Specification
Model	IS200AEPAH1BPR5
Brand	GE
Origin	United States
Weight	0.8 kg
Dimensions	263 mm x 58 mm x 28 mm
Operating Temp	0 deg C to +60 deg C
Power Consumption	Not specified
Module Type	Analog Expansion Power Amplifier (AEPA) Board
System Compatibility	GE Mark VIe Speedtronic Control System
Output Channels	High-power analog outputs
Output Signal Types	+/-50 mA, 4-20 mA, +/-10 VDC
Load Capacity	Direct drive of proportional valves and actuators
Isolation Rating	1500 Vrms channel-to-backplane isolation
Power Supply	Backplane powered via Mark VIe rack
Communication Interface	VMEbus / PDH network
Protection Components	MOV surge suppressors, onboard relays
Relay Quantity	12 relays
Plug Connectors	19 connectors for I/O and power distribution
Redundancy Support	Simplex and Triple Modular Redundancy (TMR)

Firmware Flash Compatibility and I/O Density Scaling

The IS200AEPAH1BPR5 provides analog signal amplification by converting controller-level commands into higher-current outputs for proportional valves, servo actuators, and other field devices. The module operates as an output interface within the GE Mark VIe architecture, supporting isolated analog drive circuits for turbine control loops.

The board supports I/O density scaling by integrating amplified output channels, relay interfaces, and protection components within a single rack-mounted assembly. The 1500 Vrms channel-to-backplane isolation design separates field output circuits from controller backplane electronics and reduces electrical coupling between signal domains.

The module supports simplex and TMR configurations within compatible Mark VIe systems. Firmware flash compatibility and hardware revision matching should be confirmed before installation into an existing control rack.

Frequently Asked Questions (FAQ)

Q: What output formats are supported by the IS200AEPAH1BPR5?
A: The module supports high-current analog outputs including +/-50 mA, 4-20 mA, and +/-10 VDC formats for actuator control applications.

Q: How is the IS200AEPAH1BPR5 powered?
A: The module receives power through the GE Mark VIe rack backplane interface.

Q: What protection functions are integrated into the module?
A: The board includes MOV surge suppressors and onboard relays for field circuit protection and interface control.

Field Installation Guidelines

Install the IS200AEPAH1BPR5 in the designated GE Mark VIe rack position and verify proper mechanical alignment before connecting the backplane interface.

Confirm analog output wiring, actuator polarity, and field device connections before energizing the module. Use shielded cables for analog signal circuits and apply cabinet grounding practices according to GE installation procedures.

Route actuator wiring separately from high-current switching conductors to reduce electromagnetic interference. Verify communication interface configuration, rack identification, and module diagnostics before enabling control outputs.

For redundant system installations, confirm module configuration, synchronization status, and hardware compatibility through the Mark VIe controller interface before returning actuator loops to operational service.
