The GE Fanuc QPI21100E2P is a high-performance 8.9-inch touch screen operator interface designed for the QuickPanel series. This robust HMI module utilizes a high-intensity Electroluminescent (EL) amber display to provide clear, reliable visual feedback in mission-critical industrial environments, such as power generation facilities, chemical processing plants, and large-scale manufacturing lines. By facilitating intuitive human-machine interaction and rapid system status reporting, this interface optimizes operator response times and enhances diagnostic efficiency, which is essential for minimizing unplanned equipment downtime and maintaining continuous production throughput in complex automation architectures.
Features
- 8.9-inch high-intensity amber Electroluminescent (EL) display.
- 640 x 400 pixel resolution for clear process visualization.
- Durable NEMA 4X/12 and IP65-rated housing for protection against dust, moisture, and chemical exposure.
- 2 MB Flash EPROM memory for application storage.
- Integrated serial I/O and download ports for flexible PLC and network connectivity.
Applications
This unit is designed for industrial operator interface applications, including monitoring and control of programmable logic controllers (PLCs) in manufacturing, chemical processing, and energy infrastructure sectors.
Technical Specifications
| Model |
QPI21100E2P |
| Brand |
GE Fanuc Total Control |
| Series |
QuickPanel |
| Display Type |
EL Touch Screen |
| Display Size |
8.9 inch |
| Resolution |
640 x 400 pixels |
| Input Voltage |
120 VAC |
| Operating Temperature |
0 to 50 degC |
| Relative Humidity |
5 to 90 percent (non-condensing) |
| Ingress Protection |
IP65 / NEMA 4X/12 |
| Interface |
Serial I/O and Download Port |
Installation Guidelines
- Ensure the panel cutout is prepared according to the manufacturer's mounting specifications to maintain the NEMA 4X/12 seal.
- Verify that the power supply is 120 VAC and properly grounded before connection.
- Use shielded communication cables for serial connections to minimize EMI interference in industrial environments.
- Ensure adequate ventilation around the unit to maintain operating temperatures within the 0 to 50 degC range.
- Handle the unit with care to avoid damage to the touch screen overlay and EL display components.
FAQ
What is the display technology used in the QPI21100E2P?
This model uses an Electroluminescent (EL) amber display, known for its high contrast and durability in industrial settings.
Is this unit suitable for washdown environments?
Yes, the unit features an IP65 and NEMA 4X/12-rated enclosure, providing protection against dust and water ingress when properly mounted.
