Description
The General Electric IC660CBB902G is a Series Six Genius I/O Bus Controller designed to manage communication between the Series Six PLC and the Genius I/O network. This module acts as a critical interface, allowing the PLC to exchange data with remote I/O devices, thereby extending the control capabilities of the automation system across the plant floor.
Features
- Supports connection for up to 31 individual Genius I/O devices.
- Configurable via CPU or handheld monitor for flexible system integration.
- Supports a maximum communication distance of 2000 feet (approx. 609 meters).
- Selectable baud rates to accommodate various network speed requirements (excluding the 153.6 Kilobaud standard rate).
- Phase B hardware revision for compatibility with established Series Six architectures.
Applications
This bus controller is primarily utilized in industrial automation environments where distributed I/O is required. It is commonly found in manufacturing plants, process control systems, and heavy industrial machinery where the Series Six PLC platform is employed to manage complex I/O arrays over long distances.
Technical Specifications
| Product Model |
IC660CBB902G |
| Manufacturer |
General Electric |
| Series |
Genius I/O |
| Max I/O Capacity |
31 Devices |
| Max Connection Distance |
2000 Feet |
| Phase Type |
B |
| Weight |
0.58 kg |
| Compatible I/O |
Genius I/O Blocks (>64 I/O bits) |
Installation Guidelines
- Ensure the PLC rack is powered down before inserting or removing the bus controller module to prevent electrical damage.
- The module is designed for installation in a standard CPU slot, remote I/O rack, or high-capacity I/O rack.
- Verify that the backplane connector pins are clean and free of debris before seating the module.
- Use shielded communication cabling for the Genius I/O bus to minimize EMI interference, especially when running at maximum distances.
- Ensure proper grounding of the rack assembly to maintain signal integrity across the bus.
FAQ
What is the primary function of the IC660CBB902G?
The IC660CBB902G serves as a bus controller for the GE Series Six PLC, enabling the system to communicate with and control remote Genius I/O blocks.
Can this module be configured using a handheld device?
Yes, the module supports configuration via either the host CPU or a compatible handheld monitor.
What is the maximum distance for the Genius I/O bus?
The controller supports a maximum communication distance of 2000 feet, provided appropriate cabling and termination standards are followed.
