GE DS200STBAG1ACB Signal Terminal Board

Configured for field signal termination and electrical interfacing in GE Mark V Speedtronic turbine control systems, the GE DS200STBAG1ACB (DS200STBA Signal Terminal Board) provides direct physical connection between analog, digital, and drive-related field wiring circuits and processor control modules.

Suffix Breakdown & Model Matrix

Segment	Description
DS200	GE Mark V Speedtronic control board family
STBA	Signal Terminal Board functional acronym
G1	Board group / hardware configuration identifier
A	Functional revision 1
C	Functional revision 2
B	Artwork revision

Hardware Specifications

Parameter	Specification
Model	DS200STBAG1ACB
Brand	GE
Origin	United States
Weight	0.73 lbs
Dimensions	280 x 200 x 30 mm
Operating Temp	-30 to +65 deg C
Power Consumption	Not specified; powered from Mark V control rack supply
Product Type	Signal Terminal Boards
Functional Acronym	STBA
Application Platform	GE Mark V Speedtronic turbine control system
Signal Inputs	Analog 4-20 mA, 0-10 V signals and digital 24 VDC signals
Signal Outputs	Relay and analog output termination interfaces
Terminal Interface	Field wiring terminal blocks and ribbon cable connectors
Isolation	2500 VAC field-to-logic isolation
Power Supply	+5 VDC logic and +/-15 VDC analog supply rails
PCB Coating	Normal coating
Indicators	LED signal activity indicators

GE Mark V Signal Interface and Network Integration

The DS200STBAG1ACB functions as a field termination interface within GE Mark V control architecture. It provides terminal access for multi-input and multi-output signal circuits, including analog measurement channels, digital status signals, and drive-related wiring connections.

The board supports GE industrial control integration through dedicated terminal connections and processor board interfaces. The terminal design separates field wiring from internal control electronics, while the 2500 VAC field-to-logic isolation specification defines the electrical separation between external circuits and controller logic domains.

For GE Mark V systems, firmware and hardware compatibility must match the installed control configuration. Board revision identifiers, including functional revision and artwork revision, define the applicable hardware configuration.

Frequently Asked Questions

Q: What type of signals can the GE DS200STBAG1ACB terminate?
A: The DS200STBAG1ACB provides termination interfaces for analog signals such as 4-20 mA and 0-10 V, as well as digital 24 VDC field signals.

Q: Does the DS200STBAG1ACB provide electrical isolation between field wiring and control logic?
A: Yes. The board specification includes 2500 VAC field-to-logic isolation between external signal circuits and internal control electronics.

Q: Is the DS200STBAG1ACB compatible with non-GE control platforms?
A: No. The board is designed for GE Mark V Speedtronic turbine control systems and requires the corresponding GE rack, processor modules, and wiring configuration.

Field Installation Guidelines

Install the DS200STBAG1ACB in the designated GE Mark V rack assembly and verify terminal block assignments before connecting field wiring.

Separate low-level analog signal cables from high-current power conductors to reduce electrical noise coupling. Use shielded instrumentation cables where required, with cable shields terminated according to site grounding practices.

Inspect terminal contacts, ribbon cable connectors, and PCB surfaces before installation. Handle the board using ESD protection procedures to prevent damage to logic components. Confirm board revision compatibility with the existing Mark V hardware configuration before system startup.
