GE DS200LDCCG1ADA LAN Drive Control Card

The GE DS200LDCCG1ADA, also cataloged as the DS200LDCC LAN Drive Control Card, operates as a dedicated hardware component for LAN communication and drive control processing within GE Mark V Speedtronic turbine control system platforms. It executes controller data exchange, motor interface processing, and drive-related signal handling through integrated processors.

Hardware Specifications

Parameter	Specification
Model	DS200LDCCG1ADA
Brand	GE
Origin	United States
Weight	0.8 kg
Operating Temp	-10 to +60 deg C
Power Consumption	20 W
Product Type	Drive Control LAN Communication Boards
Series	Mark V Speedtronic
Functional Acronym	LDCC
Functional Description	Drive Control/LAN Communications Board
Power Supply	+5 VDC, +/-15 VDC via backplane
Additional Supply	24 VDC
Current Rating (Exciter Control)	10 A to 30 A
Input Voltage	90-264 VAC
Output Voltage	0-10 VDC
Frequency	50/60 Hz
Isolation Voltage	1500 VAC
Microprocessors	LCP, DCP, MCP, CMP
Memory	6 PROMs and EEPROM
Diagnostics	RESET button, LED keypad display, bar graph LEDs
PCB Coating	Normal coating
Mounting Type	GE Mark V rack backplane installation

GE Mark V Processor Communication and Drive Interface

The DS200LDCCG1ADA integrates multiple processor sections for GE Mark V drive control and LAN communication tasks. The LAN Control Processor (LCP) manages communication exchange and bus conversion, while the Drive Control Processor (DCP), Motor Control Processor (MCP), and Co-Motor Processor (CMP) handle I/O processing, motor control functions, and subsystem data operations.

The board supports deterministic controller communication through the Mark V backplane architecture. Its processor-based design enables coordinated handling of drive reset functions, operator interface processing, and exciter control communication.

Firmware Flash Compatibility and Backplane Communication

The DS200LDCCG1ADA uses programmable memory devices including PROM storage for configuration and EEPROM storage for field parameters. Firmware compatibility depends on the installed GE Mark V controller revision and drive system configuration.

The LDCC hardware supports I/O density scaling through distributed processor handling rather than direct field Ethernet control. Revision identifiers A, D, and A define functional, hardware, and artwork configuration states for system matching.

Frequently Asked Questions

Q: What processor functions are included on the DS200LDCCG1ADA?
A: The board contains LAN Control Processor (LCP), Drive Control Processor (DCP), Motor Control Processor (MCP), and Co-Motor Processor (CMP) sections.

Q: What power connections are required for the DS200LDCCG1ADA?
A: The board receives controller power through GE Mark V interfaces including +5 VDC, +/-15 VDC, and 24 VDC supply circuits depending on system configuration.

Q: Does the DS200LDCCG1ADA provide onboard diagnostics?
A: Yes. The board includes a RESET button, LED keypad display, and status indication LEDs for hardware monitoring.

Field Installation Guidelines

Install the DS200LDCCG1ADA into the assigned GE Mark V rack position and verify the backplane connector is fully seated before energizing the system.

Confirm that firmware revision, board configuration, and memory settings match the installed drive control architecture. Maintain correct grounding between the rack assembly and cabinet structure.

Route LAN, control, and feedback wiring separately from high-current power conductors. Apply proper cable shielding and grounding practices to reduce electrical interference.

Inspect connectors, PCB surfaces, and mounting points during installation and maintenance procedures.
