ABB DSQC679 Teach Pendant
The ABB 3HAC028357-001, also cataloged as the DSQC679 Teach Pendant, operates as a dedicated hardware component for operator command input and robot motion control within ABB IRC5 robot controller platforms.
Hardware Specifications
Parameter
Specification
Model
DSQC679
Spare Model
3HAC028357-001
Brand
ABB
Product Type
Teach Pendant
Function
Operator interface device for ABB robot programming and manual operation
Cable Length
32.5 ft
Connector Type
17 pin connector
Origin
Sweden
Weight
2.18 kg
Dimensions
30 x 20 x 12.5 cm (shipping size)
ABB Robot Interface and Operator Control Characteristics
The ABB DSQC679 provides a physical interface between the operator and the ABB robot controller. It transmits manual operation commands, programming inputs, and system navigation signals through the connected pendant cable and 17 pin interface.
Additionally, the teach pendant integrates with ABB IRC5 control architectures through dedicated communication and power connections. Therefore, the unit supports robot commissioning, program editing, axis jogging, and diagnostic access functions defined by the controller firmware.
For ABB industrial control platforms, firmware compatibility and interface communication depend on the connected controller generation. The DSQC679 uses the standard ABB teach pendant connection architecture and maintains compatibility with supported robot system configurations.
Frequently Asked Questions
Q: What is the primary function of the ABB DSQC679 teach pendant? A: The DSQC679 provides operator access for robot programming, manual axis movement, configuration adjustment, and diagnostic operations through ABB robot controller systems.
Q: What connection interface does the DSQC679 use? A: The DSQC679 uses a 17 pin connector interface with a 32.5 ft cable assembly for connection to compatible ABB robot controllers.
Q: Does the DSQC679 require separate configuration hardware? A: The teach pendant operates as a controller interface device. Configuration parameters are managed through the connected ABB robot controller software environment.
Field Installation Guidelines
Verify the controller compatibility before installation and confirm that the pendant interface matches the robot system configuration.
Inspect the 17 pin connector contacts before connection to prevent communication faults caused by contamination or mechanical damage.
Route the pendant cable away from high-current power lines and sources of electromagnetic interference.
Maintain proper cable bending radius during installation to avoid mechanical stress on the connector assembly.
Confirm operator control functions after installation by checking communication status, button response, and display operation through the robot controller.
