ABB DSQC500 Main Computer Board
The ABB 3HAC3616-1, also cataloged as the DSQC500 Main Computer Board, provides direct physical processing execution for ABB robot controller computer functions, including internal monitoring, system coordination, and controller data handling.
Hardware Specifications
Parameter
Specification
Model
DSQC500
Full Order Number
3HAC3616-1
Brand
ABB
Product Type
Main Computer Board
Origin
Sweden
Weight
0.9 kg
Dimensions
21.0 cm x 20.3 cm x 2.5 cm
Controller Platform
ABB Industrial Robot Controller Systems
Hardware Function
Main processing and monitoring board
Industrial Controller Processing and Communication
The ABB DSQC500 operates as a main computer board within ABB robot controller architectures. It manages internal processing tasks, controller monitoring functions, and communication between system hardware sections.
Furthermore, ABB controller platforms depend on coordinated backplane communication and firmware compatibility to maintain correct module operation. The DSQC500 supports the controller's internal data exchange by executing programmed processing routines and hardware management functions.
The board follows ABB industrial control design principles, including backplane bus communication velocity management, I/O density scaling capability, and firmware flash compatibility requirements for controller maintenance activities.
Frequently Asked Questions
Q: What is the primary function of the ABB DSQC500? A: The DSQC500 functions as a main computer board that performs controller processing, monitoring, and internal system coordination tasks within ABB robot systems.
Q: Can the DSQC500 be installed in any ABB robot controller? A: No. Installation requires compatibility with the specific ABB controller architecture, hardware revision, and supported firmware configuration.
Q: Does the DSQC500 support hot-swapping during operation? A: The provided technical data does not specify hot-swap capability. Replacement should follow ABB controller maintenance procedures with the system powered down unless documented otherwise.
Field Installation Guidelines
Verify the controller model and hardware revision before installing the DSQC500 board.
Disconnect system power before removing or inserting the computer board.
Use proper electrostatic discharge protection when handling the PCB assembly.
Check connector alignment and ensure the board seats correctly in the controller chassis.
Maintain clean cable routing to prevent mechanical stress on board connectors.
Confirm firmware compatibility after hardware replacement according to ABB maintenance documentation.
