Honeywell TC-ODK161 Digital AC Output Module
Configured for discrete output switching in industrial I/O rack assemblies, the Honeywell TC-ODK161 (TC-ODK161 Digital AC Output Module) provides direct physical/electrical execution of 120/220 VAC load control across distributed control backplane architectures.
Suffix Breakdown & Model Matrix
No structured suffix decomposition is defined for TC-ODK161. The designation is treated as a fixed-order catalog identifier without documented hierarchical segmentation.
Hardware Specifications
Parameter
Specification
Model
TC-ODK161
Brand
Honeywell
Origin
USA (Ships from Webster, NY, USA)
Weight
0.26 kg (approx. 0 lbs 8.0 oz)
Dimensions
3.5 x 14.2 x 14.5 cm (shipping envelope)
Operating Temp
Not specified (system-dependent enclosure rating)
Power Consumption
Backplane powered; DC input 24 VDC isolated (as stated)
Output Type
Digital AC output
Channel Count
16 points
Output Voltage
120 / 220 VAC
Frequency
50 / 60 Hz
Output Current
2 A per channel
Status
Discontinued by manufacturer
Honeywell Process I/O Electrical Isolation Characteristics
Within Honeywell distributed I/O architectures, channel-to-channel electrical separation is implemented to reduce cross-conduction between output drivers under mixed AC load conditions. Backplane interfacing typically supports isolated 24 VDC logic supply domains, maintaining separation between field switching elements and controller-level communication buses. In legacy module families such as TC-ODK series, output staging is aligned with deterministic scan cycles rather than analog loop protocols such as 4-20 mA HART, while still maintaining structured isolation boundaries consistent with process control rack design practices.
Frequently Asked Questions (FAQ)
Q: Is the TC-ODK161 hot-swappable within a powered rack backplane? A: Hot-swap capability is not explicitly defined for this module. In standard implementations of similar Honeywell I/O systems, insertion and removal are typically performed under de-energized rack conditions unless the backplane architecture explicitly supports live replacement.
Q: What is the backplane power requirement for logic operation? A: The module references a 24 VDC isolated supply domain for internal logic and driver control, with field switching handled separately at AC output stages.
Q: Can mixed 120 VAC and 220 VAC loads be used simultaneously? A: Yes, channel groups are designed to switch AC loads within the rated voltage envelope, provided current per channel does not exceed 2 A and wiring segregation standards are maintained.
Field Installation Guidelines
