ABB CI853K01 Dual RS232-C Interface

Configured for serial communication in ABB AC 800M control systems, the ABB CI853K01 3BSE018103R1 (CI853K01 Dual RS232-C Interface) provides two RS232-C communication channels through the CI853 communication interface and TP853 baseplate. The module operates from 24 VDC power and consumes up to 6 W.

Hardware Specifications

Parameter	Specification
Model	CI853K01 3BSE018103R1
Base Model	CI853K01
Brand	ABB
Product Type	Dual RS232-C Interface
Spare Model	3BSE018103R1
Communication Interface	2 x RS232-C
Communication Ports	2 x RS232-C
Baseplate	TP853
Power Supply	24 VDC +/- 20%
Power Consumption	6 W max
Isolation Voltage	500 VAC, input/power
Weight	0.44 kg
Dimensions	18.7 x 6.7 x 12.7 cm estimated shipping size
Operating Temp	-20 deg C to +60 deg C
Storage Temp	-40 deg C to +85 deg C
Humidity	5-95% RH, non-condensing
Vibration	5-150 Hz, 1 G, IEC 60068-2-6
Origin	Sweden

ABB AC 800M Communication Interface

The CI853K01 provides serial communication through two RS232-C interfaces. Therefore, the physical interface is intended for equipment requiring RS232-C electrical signaling rather than Ethernet-based communication.

The CI853 communication interface mounts with the TP853 baseplate. The assembly receives 24 VDC power within the specified +/- 20% range and has a maximum stated power consumption of 6 W.

For controller-side communication, the module operates as part of the ABB AC 800M hardware architecture. Consequently, installation should maintain the specified environmental conditions and provide appropriate electrical separation from high-voltage or high-noise wiring.

Frequently Asked Questions

Q: How many RS232-C communication channels does the CI853K01 provide?
A: The CI853K01 provides two RS232-C communication interfaces.

Q: What power supply does the CI853K01 require?
A: The specified power supply is 24 VDC with an allowable range of +/- 20%. Maximum power consumption is 6 W.

Q: What environmental conditions apply to the CI853K01 during operation?
A: The specified operating temperature is -20 deg C to +60 deg C. Humidity is 5-95% RH, non-condensing.

Field Installation Guidelines

• Install the CI853 communication interface with the specified TP853 baseplate and verify mechanical engagement before energizing the assembly.
• Confirm that the supplied power remains within the specified 24 VDC +/- 20% range.
• Route RS232-C communication cables separately from high-current power conductors and switching circuits where practical.
• Maintain cable shielding and grounding practices consistent with the connected serial equipment and the site EMC requirements.
• Verify RS232-C signal wiring and connector assignments before connecting external equipment.
• Do not exceed the specified operating temperature, humidity, or vibration conditions.
• Inspect the module and baseplate for mechanical damage before installation.
• Apply power only after confirming correct wiring, connector seating, and protective grounding arrangements.
