Honeywell CC-TP0X01 C300 I/O Termination Assembly

The Honeywell CC-TP0X01, also cataloged as the CC-TP0X01 I/O Termination Assembly, operates as a dedicated hardware component for field signal termination and electrical interface processing within the Honeywell Experion PKS C300 system.

Hardware Specifications

Parameter	Specification
Model	CC-TP0X01
Brand	Honeywell
Product Type	I/O Termination Assembly
System Compatibility	Honeywell Experion PKS C300
Origin	USA
Weight	Not specified
Dimensions	Standard C300 IOTA form factor
Operating Temp	-40 deg C to +70 deg C
Storage Temp	-40 deg C to +85 deg C
Relative Humidity	5% to 95% RH, non-condensing
Power Consumption	Passive termination interface, no independent power consumption specified
Mounting Type	DIN rail / C300 carrier assembly mounting
Wiring Connection	Terminal block field wiring interface
Wire Size Capacity	0.5 to 2.5 mm2 (24 to 12 AWG)
Coating Option	Standard non-conformal coated version
Function	Field wiring termination and I/O module electrical connection

4-20 mA HART Loop and Channel Isolation Interface

The Honeywell CC-TP0X01 is designed for use with Honeywell process control I/O architectures where field signals are routed through termination assemblies before connection to controller I/O modules. The termination interface supports process instrumentation wiring practices including 4-20 mA loop signal routing and instrument-level field connections.

Channel separation and wiring organization are implemented to reduce electrical interference between adjacent field circuits. Proper shield termination and cable segregation are required when connecting analog measurement loops, digital signals, or other process instrumentation circuits.

The assembly supports integration with Honeywell C300 I/O configurations requiring controlled signal routing between field devices and controller-side processing modules.

Frequently Asked Questions

Q: Is the CC-TP0X01 an active I/O processing module?
A: No. The CC-TP0X01 is an I/O termination assembly used as a field wiring interface. Signal processing functions are performed by the associated Honeywell I/O modules.

Q: Does the CC-TP0X01 support hot-swapping of connected I/O modules?
A: Hot-swap capability depends on the installed C300 I/O module configuration and system procedures. Field wiring should remain terminated while module replacement follows the applicable Honeywell maintenance procedure.

Q: What installation factors affect signal integrity on the CC-TP0X01?
A: Signal integrity depends on correct terminal wiring, cable shielding, grounding practices, and separation of low-level analog signals from high-voltage or high-noise circuits.

Field Installation Guidelines

• Install the CC-TP0X01 on the designated Honeywell C300 carrier or DIN rail mounting structure according to system hardware documentation.
• Verify terminal assignments before connecting field wiring to prevent incorrect signal routing.
• Use shielded instrumentation cable where required by the connected field device specification.
• Connect cable shields according to the site grounding design to reduce electromagnetic interference.
• Maintain separation between analog instrumentation wiring and power or high-frequency switching cables.
• Inspect terminal connections for proper mechanical tightness before system commissioning.
• Confirm compatibility between the termination assembly and the installed Honeywell C300 I/O module type before operation.
