Configured for real-time regulatory control execution in Honeywell Experion PKS C300 control systems, the Honeywell CC-PCNT05 51308592-176 (CC-PCNT05 C300 Controller Module) provides direct processor-level execution for control algorithms, sequence logic, data processing, alarm management, and system communication functions.
Hardware Specifications
Parameter
Specification
Model
CC-PCNT05 51308592-176
Brand
Honeywell
Product Type
Experion C300 Controller Module
Controller Family
C300 Series
Origin
USA
Weight
0.4 kg
Dimensions
6.6 x 18 x 16.2 cm
Operating Temp
0 deg C to +60 deg C
Storage Temp
-40 deg C to +85 deg C
Relative Humidity
5% to 95% Non-Condensing
Power Supply
24 VDC
Operating Voltage Range
18 to 32 VDC
Power Consumption
15 W
Tariff Code
8537101190
System Platform
Honeywell Experion Process Knowledge System (PKS)
DCS Process Control and Field Communication Characteristics
The Honeywell CC-PCNT05 controller operates as the execution unit within the Experion PKS C300 architecture. It performs continuous control processing, including regulatory loops, sequential operations, alarm evaluation, and communication handling between field I/O modules and higher-level system components.
For process instrumentation integration, the C300 platform supports distributed I/O communication architectures commonly used with Honeywell process control modules. Signal management functions can include analog and digital field data processing, with support for industrial instrument interfaces such as 4-20 mA HART loop protocol and FOUNDATION Fieldbus / Profibus PA connectivity when configured through compatible I/O subsystems.
The controller architecture incorporates channel-to-channel isolation requirements at the I/O subsystem level to maintain separation between field signal circuits and control processing functions. These design characteristics allow integration with process measurement devices requiring stable signal conditioning and deterministic control execution.
Frequently Asked Questions
Q: What is the primary function of the Honeywell CC-PCNT05 controller module? A: The CC-PCNT05 is the main processing module for the Experion C300 controller platform. It executes configured control strategies, sequence programs, alarm processing, and communication tasks.
Q: What power input requirements apply to the CC-PCNT05? A: The module operates from a 24 VDC power supply and supports an operating voltage range of 18 to 32 VDC with a power consumption of 15 W.
Q: Is the CC-PCNT05 designed for redundant controller configurations? A: The CC-PCNT05 belongs to the Experion C300 controller family, which supports system-level controller redundancy configurations when installed according to Honeywell system architecture requirements.
Field Installation Guidelines
Install the CC-PCNT05 module in the designated Honeywell C300 controller mounting assembly and verify correct mechanical seating before system power application.
Confirm that the 24 VDC supply wiring follows industrial control panel practices, including correct polarity and appropriate protection devices.
Maintain separation between power wiring, communication cables, and field signal wiring to reduce electrical interference.
Use proper grounding and shielding methods for connected instrumentation networks according to site electrical standards.
Verify controller communication status after installation through the Experion PKS engineering tools before placing the process application into operation.
Firmware compatibility and controller configuration should be verified before replacement or module exchange operations.
