Bently Nevada 1800/20-XX-90-02-00 Thrust Position Proximity Transmitter

The Bently Nevada 1800/20-XX-90-02-00, also cataloged as the 1800/20 Thrust Position Proximity Transmitter, operates as a dedicated hardware component for converting eddy-current probe signals into 4-20 mA position monitoring outputs within machinery protection systems.

Hardware Specifications

Parameter	Specification
Model	1800/20-XX-90-02-00
Brand	Bently Nevada
Product Type	Thrust Position / Proximity Transmitter
Origin	USA
Weight	Approx. 0.5 kg
Dimensions	Approx. 75 mm x 115 mm x 100 mm
Operating Temp	-40 deg C to +85 deg C
Power Consumption	24 VDC supply input
Measurement Type	Axial displacement / proximity position monitoring
Sensing Technology	Eddy-current non-contact measurement
Input Interface	Proximity probe and extension cable connection
Signal Output	4-20 mA current loop output
Accuracy	+/-0.5% of full scale
Repeatability	+/-0.2% of full scale
Maximum Load Resistance	750 ohms at 24 VDC
Mounting Type	DIN rail or panel mounting
Humidity Rating	Up to 93% non-condensing
Certifications	CE, UL, CSA depending on configuration

Eddy-Current Probe Scaling and Rotor Dynamics Monitoring

The 1800/20 transmitter processes displacement signals generated by eddy-current proximity probes and converts probe voltage characteristics into proportional engineering outputs. The signal chain is configured around probe gap measurement, linearization, and 4-20 mA transmission for thrust position monitoring.

During installation, the probe gap voltage is commonly validated against Bently Nevada measurement practices, including verification of approximately -10 VDC target gap conditions for compatible eddy-current systems. Correct scaling between probe output voltage and mechanical position is required for accurate rotor axial movement analysis.

The transmitter architecture supports monitoring of rotor dynamics parameters where axial shaft movement, thrust bearing position, and mechanical displacement trends are evaluated through continuous analog measurement.

Frequently Asked Questions

Q: What type of sensor input does the 1800/20 transmitter accept?
A: The unit accepts signals from compatible eddy-current proximity probes and extension cable assemblies used for non-contact displacement measurement.

Q: Does the 1800/20 require a Bently Nevada monitor rack for operation?
A: The transmitter provides a direct 4-20 mA output signal, allowing connection to PLC, DCS, or other analog input systems without requiring a separate monitor rack.

Q: What installation factors affect measurement accuracy?
A: Probe mounting position, cable routing, electromagnetic interference, probe gap setting, and proper signal grounding affect measurement accuracy.

Field Installation Guidelines

• Install the transmitter in a location protected from excessive vibration, moisture, and contamination.
• Connect the eddy-current probe and extension cable according to the approved wiring configuration.
• Maintain separation between sensor signal wiring and high-voltage power cables to reduce electrical interference.
• Apply proper shield termination and grounding practices according to plant instrumentation standards.
• Verify probe gap voltage and transmitter output scaling before placing the monitoring loop into service.
• Confirm the 4-20 mA loop signal corresponds with the expected mechanical displacement range.
